AVG-HDE1
HDE1 is a high quality HDMI Audio splitter/de-embedder,
with 1 HDMI and 1 split stereo audio output. HDCP
compliant and HDTV compatible.
Features
De-embed and split the HDMI
audio to an analogue output
(1 video output, 1 audio output).
HDCP compliant, uses HDMI 1.3
standard.
HDTV compatible with High
Definition Transmission up to
1920*1200@60Hz resolution (max).
Antistatic case design to provide
good long protection and stable
performance.
Advertisement
Table of Contents
Related Manuals for AVGear AVG-HDE1
Summary of Contents for AVGear AVG-HDE1
- Page 1 AVG-HDE1 Features De-embed and split the HDMI audio to an analogue output (1 video output, 1 audio output). HDCP compliant, uses HDMI 1.3 standard. HDTV compatible with High Definition Transmission up to 1920*1200@60Hz resolution (max). Antistatic case design to provide good long protection and stable performance.
- Page 2 AVG-HDE1 PLEASE READ THIS PRODUCT MANUAL CAREFULLY BEFORE USING THIS PRODUCT. This manual is only for operation instruction only, and not to be used in a maintenance capacity. The functions described in this version are current till March 2015. Any changes of functions and operational parameters will be updated in future manual versions.
- Page 3 AVG-HDE1 SAFETY OPERATION GUIDE In order to guarantee the reliable operation of the equipment and safety of the user, please abide by the following procedures in installation, use and maintenance: 1. The system must be earthed properly. Please do not use two blade plugs and ensure the alternating power supply ranges from 100v to 240v and from 50Hz to 60Hz.
-
Page 4: Table Of Contents
AVG-HDE1 TABLE OF CONTENTS Introduction ......................1 Features ....................... 1.1 What’s in the Box ..................... 2 Connecting ....................... 3 System Diagram ................... 3.1 Usage Precautions ..................3.2 Specifications ......................4 Trouble Shooting and Maintenance ................ 5... -
Page 5: Introduction
AVG-HDE1 1. Introduction HDE1 is a high-quality HDMI audio splitter/de-embedder, with 1 HDMI and 1 split stereo audio output, HDCP compliant and HDTV compatible. The antistatic case design of the HDE1 provides good electrical protection for stable performance, and a transmission resolution up to 1920*1200@60Hz. -
Page 6: What's In The Box
AVG-HDE1 2. What’s in the Box 1 x HDE1 1 x Power Adapter (DC 5V) 2 x Mounting Ears (Separated from HDE1) 4 x Screws 1 x User Manual Note: : : : Please confirm that the product and the accessories are all included, if not,... -
Page 7: Connecting
AVG-HDE1 3. Connecting the HDE1 ① HDMI IN: HDMI input port, used to connect to a HD video source device, such as a DVD player, a computer etc. ② 5V DC: Unit Power Supply Connector. ③ Power Indicator: Indicates red when power on. -
Page 8: Usage Precautions
AVG-HDE1 3.2 Usage Precautions In order to guarantee the reliable operation of the equipment and safety of the user, please abide by the following proceedures for installation and maintenance: 1. The system must be earthed properly. Do not use two blades plugs and ensure the AC power supply is in range from 100v to 240v and from 50Hz to 60Hz. -
Page 9: Specifications
AVG-HDE1 4. Specification Video Input Video Output 1 HDMI, 1 Stereo Input 1 HDMI Output Audio HDMI 1.3, 3.5mm Input Connector HDMI 1.3 Output Connector jack T.M.D.S. Input Level Output Level T.M.D.S. 2.9V/3.3V 2.9V/3.3V Input 50Ω Output 50Ω Impedance Impedance Video General 340 MHz(10.2... -
Page 10: Trouble Shooting And Maintenance
AVG-HDE1 5. Troubleshooting & Maintenance 1. If Image output is ghosting, this may be caused by an incorrect setting on the projector or a bad quality cable. Please check the projector’s setting or try another high quality HDMI cable. 2. When there is a loss of color or no video signal output, please check the input and output end connections of the cables.
