AVGear AVG-UDATP4 User Manual

Hdbaset splitter hdbt 1x4 + hdmi
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AVG-UDATP4
The AVG-UDATP4 is an HDBaseT Splitter
accepting 1 HDMI input and distributing it to 4
HDBT outputs, plus 1 HDMI local output.
Features
Compliant with HDMI 1.4 & 3D
Transmit 4K x 2K signal up to 40m
and 1080p signal up to 60m
Supports PoC
Supports IR control and cascade
control
Supports RS232 control and
cascade control
Real-time display of working status
via LED indicators
Supports EDID configuration, 5
types in total
Supports cascading via HDMI OUT,
IR Loop and RS232 Loop

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVG-UDATP4 and is the answer not in the manual?

Questions and answers

Related Manuals for AVGear AVG-UDATP4

Summary of Contents for AVGear AVG-UDATP4

  • Page 1 Supports RS232 control and cascade control Real-time display of working status via LED indicators The AVG-UDATP4 is an HDBaseT Splitter accepting 1 HDMI input and distributing it to 4 Supports EDID configuration, 5 HDBT outputs, plus 1 HDMI local output.
  • Page 2 AVG-UDATP4 PLEASE READ THIS PRODUCT MANUAL CAREFULLY BEFORE USING THIS PRODUCT. This manual is only for operational instruction only, and not to be used for maintenance. The functions described in this version are current as at March 2015. Any changes of functions and operational parameters will be updated in future manual versions.
  • Page 3 AVG-UDATP4 SAFETY OPERATION GUIDE In order to guarantee the reliable operation of the equipment and safety of the user, please abide by the following procedures in installation, use and maintenance: 1. The system must be earthed properly. Please do not use two blade plugs and ensure the AC power supply ranges from 100v to 240v and from 50Hz to 60Hz.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS Introduction ......................1 Introduction to the AVG-UDATP4 ..............1.1 Features ....................... 1.2 Package List ....……………………………………………………………………2 Product Appearance of the AVG-UDATP4 ............. 3 Front Panel ....................3.1 Rear Panel....................3.2 System Connection ....................4 System Applications ..................4.1 Usage Precautions ..................

  • Page 5: Introduction

    1. Introduction 1.1. Introduction to the AVG-UDATP4 The AVG-UDATP4 is an HDBaseT Splitter accepting 1 HDMI input and distributing it to 4 HDBaseT outputs, plus 1 HDMI local output. The HDMI output socket can be used to monitor local devices or cascade with an additional splitter.

  • Page 6: Package List

    AVG-UDATP4 2. Package List 1 x AVG-UDATP4 2 x Mounting ears (6 x Screws) 8 x Screws 1 x 3.5mm Male-male Audio cable (used for IR signal cascade) 1 x RS232 cable (3-pin captive connector to DB9) 1 x RS232 cable (connect 2 3-pin captive connectors for cascading)

  • Page 7: Product Appearance Of The Avg-Udatp4

    AVG-UDATP4 3. Product Appearance of the AVG-UDATP4 3.1. Front Panel Name Description ① Power Illuminates red once powered on ② FIRMWARE USB port, used for firmware updates. ③ INPUT Illuminates green when there is input signal. HDMI: illuminates green when the HDMI source signal...
  • Page 8 ③ connecting to its IR IN socket OUT: Connect with IR emitter to emit the IR signal received from the receiver side. Assign ID for the AVG-UDATP4 to identify every unit, the value may vary from 0~F. ④ ID PRESET After assigning ID, restart th eAVG-UDATP4 for stable performance.

  • Page 9: System Connection

    AVG-UDATP4 4. System Connection 4.1. System Applications Reliable performance for control and transmission makes the AVG-UDATP4 ideal in residential installations, signal monitoring, large screen displays, conference systems, television broadcast, education, banking and security institutions etc. 4.2. Usage Precautions 1. System should be installed in a clean environment with temperature and humidity maintained to within equipment specifications.

  • Page 10: Connection Procedure

    4.5.1. Cascade AV Signal HDMI source signals can be cascaded to several displays via HDMI OUT/ IN. Connect the HDMI OUT socket of the first AVG-UDATP4 to the HDMI IN socket of the next until all AVG-UDATP4 units have been connected.

  • Page 11: Twisted Pair Cable Connection

    Cascade connection diagram: Cascade through IR Loop Connect the IR LOOP socket of the first AVG-UDATP4 and the IR IN socket of the next until all th eAVG-UDATP4 units have been connected. Sending IR signals to the IR Receiver connected to the first AVG-UDATP4 will control all cascaded AVG-UDATP4’s.
  • Page 12 AVG-UDATP4 TIA/EIA T568A TIA/EIA T568B Pin Cable color green white orange white green orange orange white green white blue blue blue white blue white orange green brown white brown white brown brown 4--5 4--5 Ground Ground 3--6 1--2 Ground Ground...

  • Page 13: System Operations

    AVG-UDATP4 5. System Operations 5.1. IR Control By using IR & HDBaseT transmission technology, the AVG-UDATP4 has the following functions: 1. Control a far-end output device from local matrix location. 2. Control a local input/output device remotely. 3. Control the AVG-UDATP4 locally or remotely.
  • Page 14 AVG-UDATP4 5.1.2. Control a far-end device from remote location Control the AVG-UDATP4 or local display remotely via corresponding IR remote As RS232 can be transmitted bi-directionally between the AVG-UDATP4 and the AVG-HD402PR, it is able to control a third party RS232 device locally or control the AVG-UDATP4 from a remote location.

  • Page 15: Rs232 Control

    Removal Delete all the control software files in corresponding file path. 5.2.2. Basic Settings Firstly, connect the AVG-UDATP4 with an input device and an output device. Then, connect it with a computer which is installed with RS232 control software. Double- click the software icon to run this software.
  • Page 16 Of which port number stands for the HDBT port that the device to be controlled is connected to, the value varies from 1~4. For example, if the ID of the AVG-UDATP4 is 01, and the device to be controlled is connected to HDBT port 2, then send the command “1B1.” as “0121B1.”.

  • Page 17: Control Far-End Device From Remote

    AVG-UDATP4 5.2.4. Control a far-end device from remote location Connect the RS232 ports of the AVG-UDATP4 and AVG-HD402PR (See Figure Below), then it is able to control the AVG-UDATP4 or local display remotely by sending RS232 commands.
  • Page 18 AVG-UDATP4 The AVG-UDATP4 is designed with a 4-pin EDID DIP switch, “1” stands for “On”, “0” stands for “Off”. Select the switches to change EDID data with reference to the following table: Switcher Status EDID information pass through, auto 0000 (default)

  • Page 19: Specifications

    AVG-UDATP4 6. Specifications Items Description Video VESA and SMPTE 480p to 2160p(4K) With 3D Input/output Bit depth: 16, 20, 24 All HDMI audio formats including Dolby D (TrueHD)/ DTS (HD-Master Audio)/ PCM Audio Input/output Channel count: from 2-8 (2.0 to 7.1) Sample rates: 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz,...

  • Page 20: Panel Drawing

    AVG-UDATP4 7. Panel Drawing...

  • Page 21: Troubleshooting & Maintenance

    AVG-UDATP4 8. Troubleshooting & Maintenance Problems Causes Solutions The Connection of the Check whether the cables cabling may be incorrect are connected correctly Color loss or no video or faulty and in working condition. signal output Make sure the connection...
  • Page 22 AVG-UDATP4 Problems Causes Solutions Check to ensure the Wrong connection connection between the control device and the unit Type in correct RS232 Cannot control the device Wrong RS232 communication by control device (e.g. a communication parameters: Baud PC) through RS232 port parameters rate:9600;...
