Please file and use this manual together with the service manual for Model No. CS-E7PKEW CS-E9PKEWCS-E12PKEW
CS-E15PKEW CS-E18PKEW CS-E21PKEW CS-E24PKEW CS-XE7PKEW CS-XE9PKEW CS-XE12PKEW CS-XE15PKEW
CS-XE18PKEW
CS-XE21PKEW
CS-ME18PB4EA CS-ME21PB4EA CS-E9GFEW CS-E12GFEW CS-E18GFEW CS-E9GFEW-2 CS-E12GFEW-2 CS-E18GFEW-2,
Order No. PAPAMY1212045CEPAPAMY1301096CE PAPAMY1301095CE RAC0704001C2 MAC0804027A2
This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
service or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.
In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit.
AMP Air Conditioning
CS-ME9PD3EA
CS-ME12PD3EA
WARNING
PRECAUTION OF LOW TEMPERATURE
Order No: PAPAMY1303046CE

Air Conditioner

CS-ME18PD3EA
CS-ME9PB4EA
© Panasonic Corporation 2013
www.ampair.co.uk | sales@ampair.co.uk
Outdoor Unit
CU-4E27PBE
CU-5E34PBE
Destination
Europe
CS-ME12PB4EA
