DYS MAGIC User Manual

User Manual
（Plug and play option）
Disclaimer
Thanks for purchasing DYS products. Please use the product strictly in
accordance with this manual.
Please read this instruction manual carefully before using the product. By using
this product, you hereby agree to this disclaimer and signify that you have read it
in full.
Please do not calibrate the gimbal or change the structure without prior notice. As
DYS has no control over use, setup, final assembly, modification or misuse, no
liability shall be assumed nor accepted for any resulting damager or injury.By the
act of use, setup or assembly, the user accepts all resulting liability. DYS
assumes no liability for damages or injuries incurred directly or indirectly from the
use of this product.
Any problems while mounting or using this product, please contact with the
authorised agent or the customer service of DYS.
Description
For Gopro4/ Gopro3+/ Gopro3 and same size sport camera.
Full aluminum handle with comfortable holding feeling as well as easy- to- use by one
hand.
Light weight, portable, friendly use and plug and play. Fast moving, chasing or turning,
low angle shooting can be achieved easily. Life time more than 2 hours .
Contents
Disclaimer
Description
Contents
Bill of Material
Gopro camera mount
Battery installation
Function keys usage
Axis rotation sketch
Characteristic
Attentions
（V1.0 / 2015.01）
Bill of Material
3 axis stabilizer x1
R123A/16340 3.7Vx4（exclude）
Gopro camera mount
Camera fixed bracket
Gopro3 camera
Frame fixed screw
2
2
2
3
3
4
Finished display
4
5
5
Above unmounted screen, fixed with M2 x 12 inner-
6 hexagon screw。
2
Camera fixed bracket x1
Others
16340 charger x1
M2x12 screw x2
Frame fixed screw
3
