If you connect an optional wired NRX remote directly to the
stereo, and not through a NMEA 2000 network , additional
configuration is needed.
1 Select > > NMEA.
2
Select an option:
• If you connected both your stereo and your optional wired
remote to a NMEA 2000 network, make sure the NRX
POWER option is not selected. This enables the optional
remote to receive power from the NMEA 2000 network.
• If you connected the optional wired remote directly to the
stereo through the NMEA 2000 connector, select the NRX
POWER option. This enables the stereo to supply power
to the optional remote.

NMEA 2000 Information

NMEA 2000 is the most popular marine standard for data
communication within vessels. It has become the standard for
sending navigation and engine management data within
vessels. FUSION introduces an industry-first product by
incorporating NMEA 2000 functionality in its audio remote
control devices. This enables the user to monitor a series of
NMEA sentences available over the NMEA 2000 network on a
connected remote control.
Go to www.fusionentertainment.com
NMEA sentences.

Appendix

Registering Your Apollo RA770

Help us better support you by completing our online registration
today.
• Go to www.fusionentertainment.com.
• Keep the original sales receipt, or a photocopy, in a safe
place.

Troubleshooting

The stereo does not respond to key presses

• Turn off power to the stereo for two minutes to reset the
stereo.

My Bluetooth audio is interrupted by short breaks

• Ensure the media player is not covered or obstructed.
Bluetooth technology performs best with line-of-sight
operation.
• Bring the media player within 10 m (33 ft.) of the stereo.
• Turn off the DISCOVERABLE setting after pairing a
Bluetooth device to the stereo.
The stereo does not display all song information from
my Bluetooth source
The availability of song information such as song title, artist
name, track duration, and album cover artwork depends on the
capability of the media player and music application.

Network Troubleshooting

If you cannot see or connect to FUSION PartyBus devices on
the network, check the following:
• Verify that only one device, either a stereo or a router, is
configured as a DHCP server.
• Verify that all FUSION PartyBus devices, network switches,
routers, and wireless access points are connected to the
network and turned on.
• Verify that wireless FUSION PartyBus devices are connected
to a wireless router or wireless access point on the network.
10
for a full list of supported
• If you configured static IP addresses, verify that every device
has a unique IP address, that the first three sets of numbers
in the IP addresses match, and that the subnet masks on
every device are identical.
• If you have made configuration changes that might be
causing networking issues, reset all network settings to
factory defaults.

Network Status Icons

A network-status icon is shown on some screens of the stereo.
You can refer to this table to understand the appearance of the
icon and help diagnose issues with the FUSION PartyBus
network (Network Troubleshooting, page
The stereo is configured for a wired network connection and
connected correctly to a wired network using an Ethernet cable.
The stereo is configured for a wired network connection, but
cannot detect the wired network. An Ethernet cable may not be
connected or there may be other problems with the network.
The stereo is configured as a wireless access point.
The stereo is configured as a wireless client and connected to a
wireless access point. The number of bars indicates the signal
strength.
The stereo is configured as a wireless client, but is not connected
to a wireless access point. There may be a problem with the
connection settings or with the wireless access point.

Specifications

General
Weight
Water resistance
Operating temperature range
Storage temperature range
Input voltage
Current (max.)
Current (muted)
Current (off, standby mode
enabled)
Current (off, standby mode
disabled)
Fuse
NMEA 2000 LEN
Bluetooth wireless range
ANT wireless range
Wireless frequencies/protocols Wi‑Fi 2.4 GHz @ +15 dBm nominal
Compass-safe distance
On-board, Class D Amplifier
Output music power per
channel
Total output music power
Output power per channel
Line output level (max.)
Aux input level (typical)
*The stereo limits output power if a pulse lasts longer than 1
sec. to prevent the amplifier from overheating and to maintain
the audio dynamics.
10).
750 g (26.5 oz.)
IEC 60529 IPX7 (front), IEC 60529
IPX2 (rear)
From 0 to 50°C (from 32 to 122°F)
From -20 to 70°C (from -4 to 158°F)
From 10.8 to 16 Vdc
15 A
Less than 900 mA
110 mA
80 mA
15 A mini blade-type
1 (50 mA)
Up to 10 m (30 ft.)
Up to 3 m (10 ft.)
Bluetooth 2.4 GHz @ +10 dBm
nominal
ANT 2.4 GHz @ +4 dBm nominal
15 cm (5.9 in.)
70 W max. x 4 at 2 ohm
280 W max.
43 W (for < 1 sec) or 10 W (for > 1
sec) RMS x 4 at 2 ohm*
5.5 V (peak to peak)
1 V RMS
