Summary of Contents for Halcyon Streamline P-Valve
- Page 1 Halcyon DIR Dive Systems Installation manual...
- Page 3 The Streamline design is the result of several years of testing and refinement; it is the culmination of a design process that draws inspi- ration from thousands of dives by Halcyon staff, test divers, and explorers around the world.
-
Page 4: Installation
Halcyon Streamline P-Valve Aquaseal (supplied) Applicator suitable to spread Aquaseal, such as a clean, thin rod etc. Halcyon P-Valve installation wrench (supplied) Device capable of creating a hole in your suit such as a 3⁄4” (19mm) punch or pencil soldering iron... - Page 5 The hose that comes with your Halcyon valve will be too long for most users, but is designed to allow individuals to trim the length in accordance with the dis- charge location.
- Page 6 If you choose not to use a punch, many divers have successfully used a variety of methods. Be certain that the method you choose gives you control over the size and shape of the hole. A hole may be burned into the suit with a pencil-style soldering iron, but great care should be taken not to burn any other areas of the suit.
- Page 7 After applying Aquaseal to the base of the valve (top left), work quickly to position the valve assembly in the desired direction within the suit and then press to seal the fabric on the base. Apply Aquaseal to the top seating surface, thread, then use the supplied wrench to hand-tighten valve.
-
Page 8: Valve Operation
The use of the norprene tubing has drastically reduced the likelihood of a kinked hose. The valve is best positioned to avoid sharp bends in the hose routing to further reduce the risk of kinking. Use only Halcyon P-Valve hose for any replace- ments. - Page 9 40.044.012 Streamline P-Valve umbrella “fl apper” valve 2.00 40.044.009 Streamline P-Valve duckbill check valve 5.00 40.044.002 P-Valve hose (cost per/ ft), for any Halcyon P-valve 7.00 P-Valve connector for catheter, for any Halcyon P- 40.044.003 valve 3.00 40.041.028 Medium 28mm condom catheter for P-Valve...
-
Page 10: Warranty Information
Warranty Information All warranty requests must be accompanied by proof of original purchase from an Autho- rized Halcyon Dealer. Be sure to save your sales receipt, and present it whenever return- ing your Halcyon gear for warranty service. HALCYON warrants, to the original purchaser only, that the HALCYON Streamline P-...
