LEM Amp 2.4 Service Manual

Stereo power amplifier

Advertisement

Quick Links

SERVICE MANUAL

Index
2
4
5

Warnings

Address
L CODE: 270232M
Technical Specifications, Introduction, Test Procedures & Adjustments
Schematic Diagrams
Layout & Spare Part List
Notice
Service must be carried out by qualified personnel only.Any tampering carried out by unqualified personnel during the guarantee period
will forfeit the right to guarantee.
For a correct operation of the instrument, after having switched off, be careful to wait at least 3 seconds before switching on again.
To improve the device's specifications, the schematic diagrams may be subject to change without prior notice.
All components marked by this symbol have special safety characteristics, when replacing any of these components use only
manufacturer's specified parts.
The (µ) micro symbol of capacitance value is substituted by U.
The (Ω) omega symbol of resistance value is substituted by E.
The electrolytic capacitors are 25Vdc rated voltage unless otherwise specified.
All resistors are 1/8Ω unless otherwise specified.
All switches shown in the "OFF" position. All DC voltages measured to ground with a voltmeter 20KOhm/V.
Soldering point.
Supply voltage.
Male connector.
Test point.
Female connector.
Flag joined with one or more flags
M/F faston connector.
with the same signal name inscribed.
