Motion Control Engineering, Inc.

11380 White Rock Road

Rancho Cordova, CA 95742

voice 916 463 9200

fax 916 463 9201

www.mceinc.com

User Guide,

iControl with DC Drive

Release 3 Software

Manual # 42-02-7223, Rev A3, December 2012

Table of Contents

Troubleshooting

Need help?

Do you have a question about the iControl and is the answer not in the manual?

Questions and answers

Summary of Contents for MCE iControl

Page 1 Motion Control Engineering, Inc. 11380 White Rock Road Rancho Cordova, CA 95742 voice 916 463 9200 fax 916 463 9201 www.mceinc.com User Guide, iControl with DC Drive Release 3 Software Manual # 42-02-7223, Rev A3, December 2012...
Page 2 Copyright Copyright 2012, Motion Control Engineering. All Rights Reserved. This document may not be reproduced, electronically or mechanically, in whole or in part, without written permission from Motion Control Engineering. Trademarks All trademarks or registered product names appearing in this document are the exclusive property of the respective owners.
Page 3 End User License Agreement This End User License Agreement (“Agreement”) grants you the right to use the software con- tained in this product (the “Software”) subject to the following restrictions: You may not: (i) copy the Software, except for archive purposes consistent with your standard archive procedures; (ii) transfer the Software to a third party apart from the entire product;...
Page 4 Important Precautions and Useful Information This preface contains information that will help you understand and safely maintain MCE equipment. We strongly recommend you review this preface and read this manual before installing, adjusting, or maintaining Motion Control Engineering equipment. This preface dis- cusses: •...
Page 5 resistance to ground by using the shortest possible routing. See National Electrical Code Article 250 or the applicable local electrical code. Before applying power to the controller, physically check all the power resistors and other components located in the resistor cabinet and inside the controller. Components loosened during shipment may cause damage.
Page 7: Table Of Contents
Overview ........
Page 8 Basic Safety String and Associated Wiring ......2-28 Cartop Safety Switches ........... . . 2-28 Hoistway Safety Switches .
Page 9 Initial Drive Settings (Quattro DC Drive) ........2-71 iControl Parameter Settings (Quattro DC Drive) ....... . 2-72 Automated Drive Setup (Quattro DC Drive) .
Page 10 Serial Connection ........
Page 11 Pattern Scaling (System 12 SCR Drive) ........4-9 Armature Voltage (System 12 SCR Drive).
Page 12 Ethernet Overview ........
Page 13 Final Calibration with iControl ........
Page 14 Circuit Board Removal and Replacement ........6-80 iControl Circuit Board Quick References ......6-81 ICE-COP-2 Serial Car Operating Panel Board .
Page 15 Section 7. iBox Front Panel Controls About the iBox Front Panel ......... . 7-1 LCD Display and Keypad .
Page 16 System - Diagnostic Tabs ..........8-31 Additional Windows .
Page 17 Configuration - Brake Tab ......... .9-25 Brake - Control Tab - Voltage .
Page 18 Configuration - Floor Heights ........9-116 Configuration - General .
Page 19 Sending Changes to iControl ........
Page 20 DC Specifications ........
Page 21: Icontrol Overview
Description iControl Overview This section provides: • A general description of the iControl system, page 1-2 • System interconnect diagrams, page 1-4 • Installation Specifications, page 1-7...
Page 22: General Description
Depth = 16 inches (41 cm) Measurements are approximate Component Assemblies • iControl enclosure containing iBox elevator control, AC or DC drive, and expansion circuit boards as required for the specific job • Landing system, per job requirements • iLand: Rail face encoder wheel, rail mounted floor magnets, roller guided sensors •...
Page 23: Group Dispatching
DC General Description • Load weighers (optional) • Rope Tension (LW-EMCO) • Isolated Platform (LW-MCEIP) • Cross Head Deflection (K-Tech International) Figure 1.2 Single Car Component Assembly Illustrations iDC Controller iLink cartop box iLand Compact landing system Group Dispatching For multiple car installations requiring centralized dispatching and parking control: •...
Page 24: System Interconnect Diagrams
Description System Interconnect Diagrams It can be helpful to have a general understanding of the way the entire iControl system is inter- connected. • System Interconnection: Basic car control and dispatcher interconnections. • iControl Interconnection: More detail for car controller interconnections.
Page 25 Sensor Board Landing Zone Discrete Car Calls Rear (option) magnet (if not Serial Car Call) Field Inputs Inputs Sensor Board Landing Zone Serial links to iControl Front magnet Cartop Board Load Weigher (ICE-CTP) Signal Board (LS-IPH) Serial Link Serial Car Call...
Page 26 Description Figure 1.6 Central Dispatcher (iCentral) Interconnection iMonitor or iReport DISPATCHER Monitor iView Switch To Cars Keyboard LAN: iView, iMonitor, iReport iCue connectivity. General Field Inputs to Dispatcher SYSTEM Hall Calls To Cars SYSTEM: Hall calls, Parking, Serial Special operating modes...
Page 27: Installation Specifications
DC Installation Specifications Installation Specifications This section contains specifications pertinent to installing the controller. Table 1.1 Topic Description Controller dimensions NEMA 1: (floor mount) Height = 62 inches (157.5 cm) Width = 42 inches (107 cm) Depth = 16 inches (41 cm)
Page 28 Description 1-8 Manual # 42-02-7223...
Page 29: In This Section
Construction Mode In This Section This section provides the information you need to install iControl and get the elevator running in Construction Mode: • Machine Room Preparation (see page 2-4). • About MCE Job Prints (see page 2-6). • Controller Cabinet Installation (see page 2-8).
Page 30: Before You Begin
Construction Mode Before You Begin Review the warnings and information in this section. Danger This equipment contains voltages up to 1000V, rotating motor parts, and driven machinery that can cause serious or fatal injury. Only qualified personnel who are familiar with this manual and driven machinery should attempt to start up or troubleshoot this equipment.
Page 31 DC In This Section Required Connections The following connections are necessary to run the car on Con- struction Mode: • Motor, Brake, and Drive • Velocity Encoder or Tachometer • SAFH, GOV, ESC, Rope Gripper (if enabled) • SAFC (provide temporary Emergency stop switch between SAFH and SAFC if iLink is not yet installed) •...
Page 32: Machine Room Preparation
Construction Mode Machine Room Preparation When preparing the machine room for elevator controller installation, consider: • Equipment location • Machine room environment • Ethernet and internet access Equipment Location When choosing equipment location, consider: • Adequate working space for comfort and efficiency. •...
Page 33: Ethernet And Internet Considerations
DC Machine Room Preparation Ethernet and Internet Considerations The iBox supports three Ethernet connections: • The 3 = PC port is for direct local connection of a laptop or desktop PC for elevator control configuration, program uploading, system diagnosis, or parameter adjustment using MCE iView software.
Page 34: About Mce Job Prints
Construction Mode About MCE Job Prints MCE Job Prints are technical drawing and instruction sets specifically generated for and accompanying each MCE installation. The job prints provide technical information and instruc- tion specific to the installation using the survey information collected when the job was speci- fied.
Page 35: Symbols
ICE-CTP iLink (Cartop) primary microprocessor board. ICE-EB Emergency Brake Board ICE-MIAC Input expansion board. Used as needed in iControl and the iLink cartop box to support equipment inputs. ICE-MOT Output expansion board (not currently used). ICE-MOR Output expansion board. Used as needed in iControl and the iLink cartop box to support equipment outputs.
Page 36: Controller Cabinet Installation
Construction Mode Controller Cabinet Installation Note Review the wiring guidelines in this section before bringing wires into the controller. Caution When drilling or cutting access holes or during other machining, do not allow any metal chips to fall into the electronics. Keep drive or other covers in place while wiring to prevent damage to components.
Page 37 DC Controller Cabinet Installation Figure 2.1 Cable Access Resistors Input / Output boards System 12 SCR Drive (Note: Quattro DC Drive is supplied in a separate cabinet) Contactor iPower box Preferred cable access hole locations Note PC boards can be easily damaged by electrostatic dis- charge (ESD).
Page 38: Overview Of Typical Connection Locations
The following diagram provides a general overview of component and connection locations inside iControl. Because circuit boards in iControl are connected along a common bus, they may be arranged differently or different boards may be used in different installations. This is only a general overview.
Page 39: Quattro Drive Component Locations
DC Controller Cabinet Installation Quattro Drive Component Locations Optional Low Voltage Field Supply or optional Field Filter Control 3-Phase Power Fuses Input Power (F1 & F2) Motor Contactor (1M) Motor Field Controller (A24) Control Power EMI Filter Electrical Control Board...
Page 40: Peripheral Inputs And Outputs
In every installation, there are different requirements for accepting inputs from or providing outputs to various kinds of peripheral equipment. iControl handles this generic need using ICE- MIAC input boards, ICE-MOR output boards, and ICE-COP and SC-ION serial I/O boards.
Page 41 DC Controller Cabinet Installation Input/Output Terminals Input/Output assignment may be changed in the iView application but, the job prints specify, and the system is shipped supporting, a logical configura- tion. For example, the #1 floor button in the car operating panel is connected to the #1 input to the cartop ICE-MIAC board.
Page 42: Equipment Grounding
Construction Mode Equipment Grounding For good grounding, quality materials and methods must be used. Grounding must conform to all applicable codes. Proper grounding is essential to safety and reduces noise-induced prob- lems: • Provide equipment grounding in accordance with NEC Article 250 and/or the local electri- cal code, as applicable.
Page 43 DC Equipment Grounding Figure 2.6 Isolation Transformer, Drive, and DC Motor Ground Wiring Note: Grounding of the WYE secondary of the Drive Isolation Transformer should be accomplished according to the drive Drive Isolation Transformer manufacturer recommendation. Delta SCR Drive...
Page 44: Check For Shorts To Ground
Construction Mode Check for Shorts to Ground Check for shorts to ground before powering up the system. Power must be OFF at the main disconnect. If any shorts to ground are discovered, they must be corrected before proceeding. A short to ground is defined as having a resistance of less than 20 ohms between the 1 bus (Common) and the terminal being tested.
Page 45: Ac Voltage Verification And Wiring
AC Voltage Verification and Wiring AC Voltage Verification and Wiring Instructions in this section describe wiring from commercial power to iControl. Most of the technical information is in the MCE job prints and referenced here as necessary. As shown in the job prints, an isolation transformer may be used to clean up “dirty”...
Page 46: Verifying Main Line Power And Wiring The Controller
Construction Mode Verifying Main Line Power and Wiring the Controller 1. Consult the job prints. Check the line side of the main disconnect to see that all three legs are at the correct voltage. Compare this voltage with the primary voltage on the data plate for the drive isolation transformer (must be within 10% of this value).
Page 47: Initial Controller Power Up
DC AC Voltage Verification and Wiring Initial Controller Power Up After AC power is connected, temporarily power up the controller and check to see that power buses inside the controller cabinet are providing proper outputs. Caution This procedure assumes that no field wiring has been connected to the controller. If field wiring has been connected, disconnect it before beginning this procedure.
Page 48 Construction Mode 2. Power up the controller. The system will take about 60 seconds to boot. 3. If the controller fails to power up, refer to the job prints and check supply connections and fuses. Inside the controller cabinet, 120VAC and 110VDC output buses are presented at the lower left corner of the iBox as shown in the illustration below.
Page 49: Dc Hoist Motor, Brake, And Encoder/Tachometer
DC DC Hoist Motor, Brake, and Encoder/Tachometer DC Hoist Motor, Brake, and Encoder/Tachometer This section describes: • Checking the hoist motor for insulation breakdown or shorts • Wiring the hoist motor to the controller • Wiring the iField motor field module •...
Page 50: Verifying Brake Current Resistance
Construction Mode Verifying Brake Current Resistance High current brake systems use a brake (iField) module. 1. With brake leads disconnected from the controller, measure resistance through the brake coil. 2. Inside the controller cabinet, locate the screws, one at the top and one at the bottom right corner of the iPower box (the enclosure the iBox is mounted to).
Page 51: Wiring The Brake
DC DC Hoist Motor, Brake, and Encoder/Tachometer Wiring the Brake • Refer to job print drawing D2. Connect brake wires to terminals B1 and B2 located just below the iPower box. Note Brake wires must not be routed in the same conduit with DC motor wires or velocity encoder wires.
Page 52 Construction Mode Typical Tachometer Mounting The following illustration shows a typical tachometer mounting arrangement. Mounting without a hinged assembly is all right as long as the tach wheel can be turned by hand at any point in the machine rotation and does not become too loose or too tight at any point.
Page 53 DC DC Hoist Motor, Brake, and Encoder/Tachometer Tachometer Wiring Note The tachometer wiring must use a separate grounded conduit. Inside the controller cabinet, if control wires must cross power wires, they must cross at right angles to reduce the possibility of interference.
Page 54: Velocity Encoder Installation And Wiring
Construction Mode Velocity Encoder Installation and Wiring (If you are using a tachometer, please see the preceding topic.) The encoder must be mounted and wired according to the drawings. When installed, the encoder must be electrically isolated from the motor or any other ground. (Resistance between the encoder casing and the motor or other ground should be “infinite.”) Do not mount the encoder or its wiring close to a magnetic field (the motor or brake coils).
Page 55 DC DC Hoist Motor, Brake, and Encoder/Tachometer Encoder Isolation The encoder housing must be electrically isolated from the machine (ground). To check this: 1. Measure the resistance between the encoder case and the frame of the motor. The mea- sured value must be “infinite”...
Page 56: Basic Safety String And Associated Wiring
Construction Mode Basic Safety String and Associated Wiring This section contains wiring instructions for basic safety string switches (in Construction Mode, before the iLink cartop interconnect is installed). A safety string is essentially a number of nor- mally-closed switches connected in series such that, should any one of the switches open, power to the motor and brake will immediately drop to stop the car.
Page 57: Temporary Cts Relay Bypass
1. Refer to the job prints (MRW- machine room wiring sheets). 2. Connect the rope gripper to iControl RG1, RG2, RG5, and RG7 terminals as shown. Temporary Rope Gripper Bypass If a Rope Gripper will be installed later, you may temporarily bypass the input by installing a jumper between RG5 and RG7.
Page 58: Applying Power
Construction Mode 3. Connect a Safe push button switch between the #3 bus and the direction push buttons. 4. Connect a Down push button switch between the Safe switch and the iControl ICTD ter- minal as shown (active high). 5. Connect an Up push button switch between the Safe switch and the iControl ICTU ter- minal as shown (active high).
Page 59 DC Setting Initial Operating Parameters Caution Before connecting the “System” ethernet cable to the iBox: 1. Verify that the Car ID, in the upper right corner of the iBox display, is correct. Press the iBox “Computer Reset” button and when the display returns, verify that Car ID is still correct.
Page 60 Construction Mode Figure 2.11 Controller and Group Ethernet Examples GROUP 1 ETHERNET ADDRESS EXAMPLES CAR A CAR B CAR C CAR D CAR E 192.168.193.001 192.168.193.001 192.168.193.001 192.168.193.001 192.168.193.001 192.168.192.001 192.168.192.002 192.168.192.003 192.168.192.004 192.168.192.005 192.168.191.001 192.168.191.002 192.168.191.003 192.168.191.004 192.168.191.005 Swing Car Additional System Hub Connections for Serial Hall Call Hall Calls Group 1...
Page 61 DC Setting Initial Operating Parameters iView, Direct PC used for Direct Connection 192.168.193.2 255.255.255.0 Subnet Mask iCue Group Controller 0.0.0.0 ( . . . ) Gateway iCue LAN 192.168.191.201 255.255.255.0 Subnet Mask 192.168.191.254 Gateway ORANGE CABLES SYSTEM HUB iCue SYSTEM 192.168.192.201...
Page 62 Construction Mode Figure 2.12 Simplex Controller Ethernet Example SIMPLEX ETHERNET ADDRESS EXAMPLE iView, Direct PC used for Direct Connection 192.168.193.2 255.255.255.0 Subnet Mask 0.0.0.0 ( . . . ) Gateway 192.168.193.001 iView, LAN PC used for LAN Connection BLUE CABLES LAN HUB 192.168.191.001 192.168.191.101...
Page 63: Direct Connections
DC Setting Initial Operating Parameters Direct Connections Unless a Local Area Network (Ethernet) hub has already been installed, you will find it easiest to connect a PC to the iBox using the #3 PC port on the iBox (direct connection). To make a direct connection: 1.
Page 64 Construction Mode 2. Start the PC. 3. From the Windows XP Start menu, click Control Panel. 4. Double-click Net- work and Internet Connections to open the Network and Internet Connections dialog. 5. Double-click Net- work Connections to open the Network Connections dialog.
Page 65 DC Setting Initial Operating Parameters 8. In the Local Area Connection Properties dialog, select Internet Protocol (TCP/IP). 9. Click Properties to open the Internet Protocol (TCP/IP) Properties dialog. 2-37...
Page 66 Construction Mode 10. Set the IP Address to match the iBox EXCEPT FOR the last set of numbers. The #3 iBox port is defaulted to 192.168.193.1. Typically, you can set your PC’s IP address to 192.168.193.2. 11. Set the Subnet Mask to 255.255.255.0. 12.
Page 67 DC Setting Initial Operating Parameters Creating a Direct Connection in iView Once you have set your computer TCP/IP as described previously, you need to create a connection in iView. 1. Double-click the iView icon on your computer screen to launch iView.
Page 68 Construction Mode 8. Enter a File name for this connection in the Save As dialog. The suggested file name will be the same as the one you entered in the Connection dialog. 9. The suggested (default) location for a connection is the Connections folder (My Docu- ments >...
Page 69 DC Setting Initial Operating Parameters Connecting to the iBox Once the connection is created and saved, you are ready to connect. 1. Click the Open Connection button 2. or click File on the menu bar, select Connection and click Open. The Open dialog appears.
Page 70 Construction Mode 5. When iView is communicating with a controller, this symbol is displayed in the bottom left corner of the iView screen. 6. When iView is not communicating with a controller, this symbol is displayed in the bottom left corner of the iView screen.
Page 71: Verifying Initial Parameter Settings
13. Edit and Send changes to iControl as needed. Note If you change the drive type, you must press Computer Reset on the iBox so that iControl can “detect” the change on power up. 14. Select the Safety tab. If the Safety tab is not displayed, select Safety from the View >...
Page 72 Construction Mode Table 2.5 Recommended Starting Parameter Values for Initial Operation iView Screen Settings Pattern > Common tab Position Encoder 348 if iLand-x-C Compact Landing system. 256 if iLand-x-H or LS- resolution EDGE. Otherwise, consult manufacturer documentation. Job Contract Speed 200 fpm 350 fpm 400 fpm...
Page 73 DC Setting Initial Operating Parameters Table 2.5 Recommended Starting Parameter Values for Initial Operation iView Screen Settings Drive > General tab Drive type Factory set. Verify drive type selected is System12 or Quattro. Speed Reference Tachometer, Encoder, or Internal (per job).
Page 74: Learning The Safety Configuration
Mode is also enabled before the controller is shipped. You should not have to make changes to the Safety screen until you exit Construction Mode. The safety configuration for the job is stored in two locations in iControl (FLASH and EEPROM on the SAF board). iControl constantly checks current safety information against stored data and also compares the data in the two stored locations to make certain they continue to match.
Page 75: Drive Startup (System 12 Scr Drive)
DC Drive Startup (System 12 SCR Drive) Drive Startup (System 12 SCR Drive) The following startup instructions pertain to the System 12 SCR Drive. For startup instructions for the Magnetek Quattro DC drive see “Drive Startup (Quattro DC Drive)” on page 2-71.
Page 76 Construction Mode 16. The controller is fully tested according to the connections shown in the job prints before being shipped from MCE, however, depending upon lighted LEDs noted in Step 15 above: • If Delta P.R., Wye P.R., and 30 P.R.
Page 77: Drive Offsets Calibration (System 12 Scr Drive)
DC Drive Startup (System 12 SCR Drive) Drive Offsets Calibration (System 12 SCR Drive) The iBox processes drive control voltages digitally. The digital signal is converted to its analog equivalent for output to the drive (DAC). Analog input control voltages are likewise converted from analog to digital for use by the iBox (ADC).
Page 78: Manual Drive Setup Procedure (System 12 Scr Drive)
Construction Mode 2. Follow the on-screen instructions, “To perform the drive offsets calibration, ...” (cali- brates Input ADC, Output DAC, Current Sensor, and Current Loop Integral Offset). 3. Once the calibration is Done, the offset values shown on the Setup > Drive tab should match those shown on the Drive Configuration tab (Configuration >...
Page 79 DC Drive Startup (System 12 SCR Drive) 2. Loosen the four captive screws securing the cover on the System 12 drive. Set the cover aside. The SCR-LGA board is visible at the top left of the drive enclosure. (The LEDs visible through the drive cover are mounted on a small PC board which is, in turn, mounted on the SCR-LGA board.) Refer to the following illustration for the location of test points referenced in this proce-...
Page 80 Construction Mode Note Note trim pot R376 and test point IZO (near jumper JP2). These components are used to set the “zero crossing” point if necessary. Trim pot R376 is set and locked at the factory and should not require adjustment. If, when adjusting the ride quality of the car in later steps, you notice a sharp bump when transitioning from acceleration to steady speed or from steady speed to deceleration, you may need to adjust zero crossing.
Page 81: Motor Field Calibration (System 12 Scr Drive)
DC Drive Startup (System 12 SCR Drive) Motor Field Calibration (System 12 SCR Drive) This topic includes: • Check default values • Calibrating the motor field • Check calibration results • (If necessary) Manual motor field gain adjustment — closed loop...
Page 82 Construction Mode 7. On the Setup > Motor Field tab, verify that the Ready indicator is lighted. If it is not, set the Learn switch to OFF for two seconds, then set it back to ON. (The Learn switch has a fifteen minute timer.
Page 83: Check Calibration Settings (System 12 Scr Drive)
DC Drive Startup (System 12 SCR Drive) Check Calibration Settings (System 12 SCR Drive) 1. On the Configuration > Motor Field > Control tab, note the Field standing voltage set- ting. 2. Set Field standing voltage to the same value as Field running voltage.
Page 84: Manually Adjusting Motor Field Gains — Closed Loop (Scr)
Construction Mode Manually Adjusting Motor Field Gains — Closed Loop (SCR) Note These manual adjustments are almost never necessary. They are useful only in instances of extremely poor motor field response. If, after calibration and settings checks are complete, there are still performance issues, e.g. the drive Current Limit LED lights at the beginning and/or end of runs or you feel spotting (hesita- tion) coming into a floor, the hoist motor response to control inputs may not be rapid enough.
Page 85: Brake Calibration
DC Drive Startup (System 12 SCR Drive) Brake Calibration This section describes brake calibration for DC systems using the iField Module advanced brak- ing system. The iField module electronically controls brake voltage output. Rollback Compensation In later adjustments, drive and motor settings will be adjusted to control rollback. Since that has not yet been done, we need to control rollback by adjusting Brake Pick Delay and offsetting Speed pick delay 1 so that the brake remains set until the motor builds sufficient torque.
Page 86: Calibration Procedure
Construction Mode Calibration Procedure Calibration allows iControl to learn the characteristics of the machine brake. 1. Verify that the iBox Safety OK LED is solidly on. 2. Set the iBox Learn switch to ON. 3. Place the iBox Inspection switch in the INSP position. Verify that the iBox displays Machine Room Insp.
Page 87 9. When iControl is ready to begin learning, the screen will display “The controller is wait- ing for a direction command in order to proceed. You may command either the Up or the Down direction.”...
Page 88: Verify Brake Picking
1. Verify that the iBox Safety OK LED is solidly on. Display the Pattern > Common tab (View > Configuration > Pattern > Common tab). 2. Set Pattern Scaling to 0% and click Send to send the changed parameter to iControl. 3. Display the Operational Status tab. Note that Brake voltage is charted in the Machine section of the Operational Status tab.
Page 89: Running On Machine Room Inspection
2. If you have not yet done so, select Acquire under the Write privilege menu and press the “Yes” softkey on the iBox to grant yourself write permission. In iView, click the Send button to send the changed value to iControl. 3. Reverse the motor field wires at MF1 and MF2.
Page 90: Calibrating Actual Car Speed (System 12 Scr Drive)
Construction Mode Calibrating Actual Car Speed (System 12 SCR Drive) Car speed settings on the Configuration > Drive > General tab may be used to make initial adjustments to car speed if necessary. Note If iLand and iLink are already installed, use the landing system speed (Speed/Actual on the Operational Status tab) as the speed reference for calibration.
Page 91: Current Limit Adjustments (System 12 Scr Drive)
DC Drive Startup (System 12 SCR Drive) Current Limit Adjustments (System 12 SCR Drive) This section describes making current limit adjustments for the System 12 drive. Drive voltage and current capabilities are tai- lored to the needs of the job by placing a specific “header” in socket U81 on the drive SCR-LGA board.
Page 92: Armature Voltage Limit (System 12 Scr Drive)
Armature current limit in 5% increments until the LED stays off when the car is run. (Remember you must Send changes to iControl before they take effect.) You should not have to go above about 180% if the car is counter-balanced correctly.
Page 93: Car Response And Speed Loop Gain (System 12 Scr Drive)
DC Drive Startup (System 12 SCR Drive) Car Response and Speed Loop Gain (System 12 SCR Drive) Only if necessary, car response may be stiffened by increasing PID-Standard Integral error and/or Proportional error on the Configuration > Drive > Control tab. At this point, it is only necessary to prevent the car from sagging severely.
Page 94: Speed Loop Gains (System 12 Scr Drive)
Construction Mode Speed Loop Gains (System 12 SCR Drive) If there is oscillation while running: 1. On the Configuration > Drive > Control tab, slowly decrease PID-Standard Proportional error and Integral error until oscillation stops. Verify the Option-Start gain (normal) is not checked.
Page 95: Following Error Margin
DC Drive Startup (System 12 SCR Drive) Following Error Margin The Following error is used for fault detection purposes only. The Following error parameter (Configuration > Drive > Safety tab) sets the allowed margin of deviation from commanded speed, as a percentage. A Tach Error fault is generated when the difference between intended pattern speed and speed feedback exceeds the Following error margin.
Page 96: Tach Error Tripping Threshold Adjustment
6%, add that to 1/2 of 6 (3) and set Following error to 9%. Remember to send the change to iControl. 7. Repeat steps 1 through 4, verifying that Feedback and Limit traces remain separated. If they do not, recalculate and reset Following error.
Page 97: Tach Failure Calibration (System 12 Scr Drive)
5. Add 15% to 20% to the calculated value and set the Tach failure parameter to this value. For example, if the calculated percentage is 15%, add 15% to that and set Tach Failure to 30%. Remember to send the change to iControl. 2-69...
Page 98: Additional Adjustments And Checks
Construction Mode Additional Adjustments and Checks 1. On the Configuration > Pattern > Common tab, set Pattern scaling to 100%. 2. On the Configuration > Pattern > Modes tab, set Inspection/High Speed to the desired value (maximum Inspection speed is 150 fpm). Set the Inspection/Low Speed to 25 fpm. Note If the Terminal Switches (UNT5/DNT5) have been installed, and you wish to use the reduced inspection speed option, you may enable it by checking Reduced inspection speed on the Con-...
Page 99: Drive Startup (Quattro Dc Drive)
DC Drive Startup (Quattro DC Drive) Drive Startup (Quattro DC Drive) For Drive Startup instructions for the MCE System 12 SCR Drive see “Drive Startup (System 12 SCR Drive)” on page 2-47. Each iController is shipped with completed drive parameter sheets and a drive manual. Based on the field survey information, all drive unit, field-adjustable parameters are set and noted on the parameter sheets.
Page 100: Icontrol Parameter Settings (Quattro Dc Drive)
= No Fault • Relay Coil 2 (TB2-8/10/12)= Speed Reg Rls iControl Parameter Settings (Quattro DC Drive) Verify the following iControl parameter settings using iView: Drive Configuration (Controller > View > Configuration > General tab) • Options: • Drive type = Quattro •...
Page 101: Automated Drive Setup (Quattro Dc Drive)
DC Drive Startup (Quattro DC Drive) Automated Drive Setup (Quattro DC Drive) Before adjusting the drive, verify: • the iBox Safety OK LED is ON • the iBox Door Locked LED is ON • the iBox Fault LED is OFF 1.
Page 102: Manual Drive Setup Procedure (Quattro Dc Drive)
Construction Mode Manual Drive Setup Procedure (Quattro DC Drive) MCE recommends performing the Automated Drive Setup Procedure previously described. However, if the automated procedure is unsuccessful, the manual procedure may be used. The 1. Verify that Pattern scaling is set to 100% (Configuration > Pattern > Common tab). 2.
Page 103: Drive Response Adjustments (Quattro Dc Drive)
DC Drive Startup (Quattro DC Drive) Drive Response Adjustments (Quattro DC Drive) Please review the following description of Quattro DC Drive response adjustments: 1. For the initial setup, it is recommended to set Pick delay, Speed pick delay 1, and Speed pick delay 2 (Configuration >...
Page 104 Construction Mode Figure 2.15 Velocity and Acceleration Curves Velocity and acceleration: (a) profile at contract speed; (b) insufficient lag compensation with profile at less than contract speed; (c) excessive lag compensation with profile at less than contract speed; (d) optimum lag compensation with profile at less than contract speed 3.
Page 105: Brake Calibration
DC Drive Startup (Quattro DC Drive) Brake Calibration This section describes brake calibration for DC systems using the iField Module advanced brak- ing system. The iField module electronically controls brake voltage output. Rollback Compensation In later adjustments, drive and motor settings will be adjusted to control rollback. Since that has not yet been done, we need to control rollback by adjusting Brake Pick Delay and offsetting Speed pick delay 1 so that the brake remains set until the motor builds sufficient torque.
Page 106: Calibration Procedure
Construction Mode Calibration Procedure Calibration allows iControl to learn the characteristics of the machine brake. 1. Verify that the iBox Safety OK LED is solidly on. 2. Set the iBox Learn switch to ON. 3. Place the iBox Inspection switch in the INSP position. Verify that the iBox displays Machine Room Insp.
Page 107 9. When iControl is ready to begin learning, the screen will display “The controller is wait- ing for a direction command in order to proceed. You may command either the Up or the Down direction.”...
Page 108: Verify Brake Picking
1. Verify that the iBox Safety OK LED is solidly on. Display the Pattern > Common tab (View > Configuration > Pattern > Common tab). 2. Set Pattern Scaling to 0% and click Send to send the changed parameter to iControl. 3. Display the Operational Status tab. Note that Brake voltage is charted in the Machine section of the Operational Status tab.
Page 109: Running On Machine Room Inspection
DC Drive Startup (Quattro DC Drive) Running on Machine Room Inspection Once you are satisfied that the brake is picking properly, verify proper car movement and motor current. Troubleshoot movement if needed. Calibrate speed using a handheld tachometer. Verifying Motor Rotation and Control (Quattro DC Drive) 1.
Page 110: Calibrating Actual Car Speed (Quattro Dc Drive)
Construction Mode Calibrating Actual Car Speed (Quattro DC Drive) If iLand and iLink are already installed, use the landing system speed (Speed/Actual on the Operational Status tab) as the speed reference for speed calibration. If not, use a hand-held tachometer to obtain the value. If you are using a hand-held tachometer, hold it against the hoist or governor rope on the machine.
Page 111: Following Error Margin
DC Drive Startup (Quattro DC Drive) Following Error Margin The Following error is used for fault detection purposes only. The Following error parameter (Configuration > Drive > Safety tab) sets the allowed margin of deviation from commanded speed, as a percentage. A Tach Error fault is generated when the difference between intended pattern speed and speed feedback exceeds the Following error margin.
Page 112: Tach Error Tripping Threshold Adjustment
6%, add that to 1/2 of 6 (3) and set Following error to 9%. Remember to send the change to iControl. 7. Repeat steps 1 through 4, verifying that Feedback and Limit traces remain separated. If they do not, recalculate and reset Following error.
Page 113: Additional Adjustments And Checks
DC Drive Startup (Quattro DC Drive) Additional Adjustments and Checks 1. On the Configuration > Pattern > Common tab, set Pattern scaling to 100%. 2. On the Configuration > Pattern > Modes tab, set Inspection/High Speed to the desired value (maximum Inspection speed is 150 fpm).
Page 114 Construction Mode 2-86 Manual # 42-02-7223...
Page 115: In This Section
Inspection Mode In This Section This section provides the information you need to complete field wiring and prepare the eleva- tor to operate in Inspection Mode: • iLand Landing System Installation (see page 3-2). • iLink Interconnect Installation (see page 3-13).
Page 116: Iland Landing System
DP2 leads DP1. Position During floor height “learn” operations, iControl counts the total number of pulses from the bot- tom to the top of hoistway travel and also stores the floor height position (pulse count) at each landing. During normal elevator operation, iControl uses the floor height information and the encoder pulse count to accurately track the elevator car position in the hoistway.
Page 117: Cartop Mounting
DC iLand Landing System Cartop Mounting The iLand Compact landing system is usually mounted on a pedestal on the elevator cartop such that the encoding wheel rides the center ridge of the hoistway rail. MCE offers a mounting pedestal designed to work in most installations, which can be purchased separately (LS-PED- ESTAL-BSE), or the pedestal may be provided by the installer.
Page 118: Pedestal Fabrication And Mounting
Inspection Mode Pedestal Fabrication and Mounting A pre-fabricated, universal mounting pedestal may be purchased from MCE. If built on site, the pedestal must be fabricated to: • Mount securely to the elevator car crosshead beam • Position the iLand Compact system acceptably both vertically and horizontally (vertically so that the landing system clears obstructions like the elevator guide wheels —...
Page 119: Installing Iland
DC Installing iLand Installing iLand 1. Attach the mounting pedestal securely to the elevator crosshead beam. 2. Place the iLand Compact on the mounting pedestal and slide it into position so that the Position Encoder Wheel is touching the front face of the rail. If necessary, loosen the screws that adjust the position of the Leveling Sensor Bracket(s) and slide the brackets back away from the rail.
Page 120 Inspection Mode 5. Place a magnet on the rail as shown in Figures 4 and 5. below. iLand Compact must be adjusted so that the Leveling Sensors are centered on the magnet with the face of the sensor board 1/4 inch (K 1/16 inch) from the surface of the magnet. Magnets may be stacked to increase height if needed.
Page 121 DC Installing iLand 6. For a front door only iLand Com- pact (iLand-1-C), adjust the guide rollers so that the Leveling Sensor is cen- tered on the magnet (see Fig- ures 4 and 5. Ensure that the Guide Rollers are snug against the rail.
Page 122 Inspection Mode Figure 6. iLand Compact Installation (rear view) Snug the Guide Rollers against the rail FACTORY ADJUSTMENT Guide Roller adjustment DO NOT ADJUST screws Leveling sensor centered on the magnet Position Encoder Wheel centered on the rail Position Encoder Wheel centering adjustment Carrier Arms centered 3-8 Manual # 42-02-7223...
Page 123: Floor Leveling Magnets
DC Installing iLand Floor Leveling Magnets In a typical, front-door only, installation, a single 6-inch strip magnet attached near the hollow of the rail curve (left side), See “Magnet position on the rail (side view)” on page 6., is used to indicate the level-with-floor position for each landing at which the elevator car will stop.
Page 124: Installing The Floor Leveling Magnets
Inspection Mode Installing the Floor Leveling Magnets 1. On Inspection mode, position the elevator car so that it is level with a landing. Inspec- tion speed may be reduced to help stop the car precisely at floor level (iView > Controller >...
Page 125: Cabling Connections
Sensor Board Landing Zone Discrete Car Calls Rear (option) magnet (if not Serial Car Call) Field Inputs Inputs Sensor Board Landing Zone Serial links to iControl Front magnet Cartop Board Load Weigher (ICE-CTP) Signal Board (LS-IPH) Serial Link Serial Car Call...
Page 126: Iland Status Leds
Inspection Mode iLand Status LEDs The iLand signal board enclosure reveals status LED sets for the front and rear floor leveling sensors and the position encoder sensor. Refer to the illustration below. Figure 9. iLand Status LEDs Rear floor leveling sensors: Front floor leveling sensors: Position Encoder quadrature pulse indicators.
Page 127: Installing Ilink
The serial link between iLink and iControl allows the bulk of the travelling cable to be reduced. The illustration below shows a view of iLink circuitry with the cover removed.
Page 128: Ilink Enclosure Installation
Inspection Mode iLink Enclosure Installation The iLink enclosure is typically mounted on the left side (as you face the car) of the cartop, opposite the iLand system. The enclosure has several partially-punched knockouts to accom- modate two-inch conduit connections. Mount the iLink enclosure on or between the crosshead beams.
Page 129: Ilink Wiring
Installing iLink iLink Wiring Like iControl, the iLink cartop box has an always-present, processor board (ICE-CTP) con- nected through a pluggable bus to input (ICE-MIAC), output (ICE-MOR), and other optional boards as required by the installation. A typical layout is shown below.
Page 130: Front And Rear Door And Leveling Signals
Leveling Signals 1. Refer to the -CT job print drawings. 2. Connect the DZ, DLM, and ULM signals between the iLink CTP board and iControl/ iBox for front and rear (if present) doors as shown. Level signals, Rear...
Page 131: Cartop Inspection Switches
Serial Connection The processors in the iLink cartop box and the iControl controller cabinet communicate serially through shielded, twisted pair, connections. 1. Refer to the -CT drawings in the job prints. Locate the TX+, TX-, RX+, RX-, and Shield connections.
Page 132: Ilink Power Connections
Inspection Mode iLink Power Connections The iLink cartop interconnect box receives operating power from iControl through the travel- ling cable. Typically, the power wires are connected to the terminal strip in the cartop box and distributed from there to the circuit boards. Connections between the terminal strip and the boards are made at MCE before shipment but must be verified during installation.
Page 133: Ilink Cartop Wiring Verification
DC Installing the Hoistway Limit Switches iLink Cartop Wiring Verification 1. Examine the -CT drawings in the job prints package. 2. Carefully verify that all connections have been correctly made and are clean and secure. Note Each job is different. The job prints accurately reflect the survey information and are the pri- mary source for installation and wiring information.
Page 134: Installing Brake Monitoring
Inspection Mode Installing Brake Monitoring Brake monitoring via an independent contact is required by code only for disc brakes. A spare iBox input (SP2D), or a programmable input (Brake Switch) on an ICE-MIAC board, may be used for the brake contact. The brake monitoring contact may be provided as part of the brake assembly.
Page 135: Installing The Earthquake Sensor
The counterweight derailment detector operates using a 24VDC “ring and string” circuit which will be grounded if excessive counterweight motion occurs. iControl also monitors the continu- ity of the “string” and will trigger a fault if the string breaks. The illustration below shows how the circuit operates.
Page 136: Installing The Serial Hall Call System
Inspection Mode Installing the Serial Hall Call System The MCE serial hall call system uses only two wires and is easier to install than traditional, multi-wire systems. The two wires provide both power and signal to hall calls. For simplex cars the hall call driver is located in the car controller cabinet.
Page 137: Verifying Cartop Voltages
If not, verify that the CARTOP LINK wiring is connected as speci- fied on the job prints. Additional troubleshooting information is available in Section 6. Please refer to “iControl Messages List - Numerical” on page 6-4.
Page 138: Verifying Door Operation
Inspection Mode Verifying Door Operation This section helps you verify that the door lock signal input is working properly. 1. Verify that the door related options required for this job are checked on the iView Safety screen. Please refer to “Setup - Safety - Configuration Tab” on page 9-175.
Page 139: Verifying Safety Configuration
DC Verifying Safety Configuration Verifying Safety Configuration Verify that the safety options required for this job are checked on the iView Safety screen. Please refer to “Setup - Safety - Configuration Tab” on page 9-175. Any options that are checked, but not operational, will require a jumper to allow the car to operate on Inspection (inputs must be high).
Page 140: Running On Machine Room Inspection
Inspection Mode Running on Machine Room Inspection When you are ready to run the elevator on Inspection: 1. Verify the iBox Computer, Safety A, Safety B, and Cartop status LEDs are lighted solidly green. 2. Move the Inspection switch to the INSP position. 3.
Page 141: Verifying Quadrature Pulse Sequence And Encoder Resolution
DC Running on Machine Room Inspection Verifying Quadrature Pulse Sequence and Encoder Resolution Position Encoder Resolution Verify that Position Encoder Resolution (Pattern Configuration/Common tab) is correct. When the iLand landing system is mounted on the car top with the encoder wheel against the hoistway rail, Position Encoder Resolution is 256 pulses/ft.
Page 142: Prepare For Final Adjustments
Inspection Mode Prepare for Final Adjustments This section describes preparation for final adjustment. Door Operator The door operator must be working properly before final adjustment. 1. Verify that the door fuses are properly installed. 2. Verify that the iBox Car Door Bypass and Hoistway Door Bypass switches are OFF. 3.
Page 143: Counterweight Balancing
DC Prepare for Final Adjustments Counterweight Balancing On modernizations, the weight of the car is often changed but compensating adjustments to the counterweight are sometimes overlooked. This adjustment is important for achieving desired performance and ride characteristics. The following are two ways in which the car / counter-...
Page 144: Run Testing
Inspection Mode Run Testing 1. Verify all landing system magnets are installed according to job prints and instructions. 2. On Inspection mode, run the car to the midpoint of the hoistway. 3. Set the iBox Test switch to the ON position. 4.
Page 145: Empty Car Tests
DC Prepare for Final Adjustments Empty Car Tests With the car on Machine Room Inspection and with test weights removed (empty car), the fol- lowing steps allow you to adjust the response of the car to reduce empty car rollback while avoiding the oscillations that can occur if too much gain is adjusted into the system.
Page 146 Inspection Mode 3-32 Manual # 42-02-7223...
Page 147: In This Section
Final Adjustment In This Section This section describes final adjustments to, and complete final inspection of, the elevator sys- tem. At this point, all steps in Sections 2 and 3 should have been completed. • Learning the Floor Heights (see page 4-2).
Page 148: Learning The Floor Heights
Final Adjustment Learning the Floor Heights Learning the floor heights allows iControl to determine the location of each floor relative to the bottom floor. iControl does this by counting pulses sent by the position encoder on the iLand landing system as the elevator travels the entire length of the hoistway from bottom to top. The iLand Compact position encoder produces 348 pulses per foot of travel.
Page 149: Verifying One Floor Run Operation
DC Verifying One Floor Run Operation 7. When Ready is lighted, click Learn. The In Progress indicator lights when the Learn button is clicked. • If Manual learn type was selected, you are prompted to press and hold the iBox Enable and Up buttons.
Page 150: If The Car Does Not Stop And Correct Properly
Final Adjustment If the Car Does Not Stop and Correct Properly • Check the iBox status display. Verify: • ULM, DLM, and DZ signals are working properly • Safety OK = ON - safety string is made up. • Doors Locked= ON - all doors are locked. •...
Page 151: Verifying A One Floor Run
DC Verifying One Floor Run Operation Verifying a One Floor Run During a one-floor run, observe the following: • When the car starts, note that on the Hoistway display, the position indicator changes to the next floor just before reaching the desired floor.
Page 152: Verify Releveling
Final Adjustment Verify Releveling 1. When the car is at a floor, simulate overrunning by temporarily changing the floor height Offset (Configuration > Floor Heights > Floor Offsets tab) to 0.50” and pressing the Send button. 2. Observe the releveling operation. (Return Offset to the proper setting and press Send.) 3.
Page 153: Reaching Contract Speed (System 12 Scr Drive)
DC Reaching Contract Speed (System 12 SCR Drive) Reaching Contract Speed (System 12 SCR Drive) For Quattro DC Drive Reaching Contract Speed see page 4-11. Note Be sure to read this entire section before performing the following procedure. The car must be on Test operation (iBox Test switch to ON) throughout the setup procedure.
Page 154: Determine The Armature Current Limit (System 12 Scr Drive)
Final Adjustment Determine the Armature Current Limit (System 12 SCR Drive) Armature current limit (Configuration > Drive > Safety tab) is a percentage of SCR drive maxi- mum output current rating and may range up to 276%. To determine the Armature current limit setting, first find the Maximum Full Load Output Current rating on page -D1 of the job prints.
Page 155: Speed Pick Delay (System 12 Scr Drive)
DC Reaching Contract Speed (System 12 SCR Drive) Speed Pick Delay (System 12 SCR Drive) To achieve proper starting, without rollback or snapping away from the floor, a variable delay in the application of the pattern signal is provided. Speed pick delay 1, on the Configuration >...
Page 156: Armature Voltage (System 12 Scr Drive)
Final Adjustment Armature Voltage (System 12 SCR Drive) While running the car, observe armature voltage by setting Virtual Oscilloscope Test point 1 to Armature Voltage Synthetic Feedback. Note The value show on the Virtual Oscilloscope Test point 1 and output to iBox test point STP1 is scaled.
Page 157: Reaching Contract Speed (Quattro Dc Drive)
DC Reaching Contract Speed (Quattro DC Drive) Reaching Contract Speed (Quattro DC Drive) For System 12 SCR Drive Reaching Contract Speed see page 4-7. Note Be sure to read this entire section before performing the following procedure. The car must be on Test operation (iBox Test switch to ON) throughout the setup procedure.
Page 158: Pattern Scaling (Quattro Dc Drive)
Final Adjustment Pattern Scaling (Quattro DC Drive) 1. Using Pattern scaling on the Configuration > Pattern > Common tab, increase con- tract speed in 10% increments until the car is running at 80% of contract speed. Moni- tor performance on the iView Virtual Oscilloscope.
Page 159: Learning Normal & Emergency Terminal Limit Switches
DC Learning Normal & Emergency Terminal Limit Learning Normal & Emergency Terminal Limit Switches The Normal Terminal Slowdown Limit (NTS) and Emergency Terminal Limit (ETS) switch Learn operation records car speed and position at the time each terminal switch is activated on a normal approach to either terminal landing.
Page 160 Final Adjustment 4. Refer to the job prints to determine which Normal Terminal Limit switches (UNTn and DNTn) are required for this installation and where they should be positioned in the hoistway. Verify that the Learned position on the Diagnostics > Terminal Switches Sta- tus tab corresponds to the job prints.
Page 161: Synthetic Speed Calibration (System 12 Scr Drive)
DC Synthetic Speed Calibration (System 12 SCR Drive) Synthetic Speed Calibration (System 12 SCR Drive) Calibration determines the value for the Voltage safety calibration and Current safety calibra- tion parameters (Configuration > Drive > Safety tab). These in turn determine synthetic speed.
Page 162: Feed Forward Gain Calibration (System 12 Scr Drive)
Final Adjustment Feed Forward Gain Calibration (System 12 SCR Drive) This calibration determines the baseline value for error compensation. Baseline value deter- mines the minimum value for the Error compensation parameter (Configuration > Drive > Control tab). The process requires the elevator to move in both directions and to reach at least 50% of con- tract speed in each.
Page 163: Fine Tuning The Speed Regulator (Quattro Dc Drive)
DC Fine Tuning the Speed Regulator (Quattro DC Fine Tuning the Speed Regulator (Quattro DC Drive) In order to properly tune the speed regulator of the Quattro drive, a valid inertia value must be determined. 1. With a balanced load in the elevator, bring the elevator to the top landing.
Page 164: Profile Parameters
Final Adjustment Profile Parameters • Initial jerk - defines the transition from zero speed to full acceleration. As Initial jerk increases, the profile transitions more quickly from starting to maximum acceleration. Values typically range from 4.0 to 8.0 ft/s (1.219 to 2.438 m/s ) with higher values result- ing in a sharper start.
Page 165: Profiles
DC Shaping the Speed Profile Profiles There are eight programmable profiles addressed on the Pattern Screen: • Standard - used under normal operating conditions. Unless otherwise specified, sug- gested profile parameter adjustments are assumed to refer to Standard profile parameters.
Page 166 Final Adjustment • Slope of Acceleration / Deceleration - Ideally, the slope of acceleration in volts per second should be equal to or slightly greater than the slope of deceleration as viewed on an oscilloscope connected to iBox test point STP1 and COM (Virtual Oscilloscope Test point 1 set to Speed Feedback Filtered).
Page 167: Controlling Initial Start Of Car Motion
DC Controlling Initial Start of Car Motion Controlling Initial Start of Car Motion Some gearless machines may exhibit rollback at the start of car motion. . Rollback control adjustments include: • Pre-torque implementation for systems with analog load weighers •...
Page 168: Pretorque Gain Adjustments
2. With the car in Test mode (iBox TEST switch ON) move the car to the top floor. 3. On the Configuration > Drive > Pre-Torque tab, enable the Pretorque option and send the new selection to iControl. 4. On the Virtual Oscilloscope, select Load Weigher Balanced on Test point 1. If necessary, adjust the windows so that you can see the oscilloscope and the Pre-Torque parameters at the same time.
Page 169 DC Controlling Initial Start of Car Motion 12. If rollback is detected, adjust the Pretorque gain parameter on the Drive > Pre-Torque tab, and again make a one-floor run down from one floor below the top landing. Repeat until rollback is no longer noticeable. Then verify that there is no rollback on a one-floor run going up from one floor below the top landing.
Page 170: Motor Control Adjustments (System 12 Scr Drive)
Final Adjustment Motor Control Adjustments (System 12 SCR Drive) If rollback is a problem and the installation does not use an analog load weigher (allowing Pre- torque rollback compensation), adjusting Drive > Control tab parameters as described below will help. The following illustration shows how normal gains are changed by Start gain (normal) adjustments.
Page 171: Drive Control Adjustments (Quattro Dc Drive)
DC Controlling Initial Start of Car Motion Drive Control Adjustments (Quattro DC Drive) Please refer to the Magnetek Quattro DC Drive Technical Manual for tuning and adjustment procedures. Brake Parameter Adjustments The iField braking module allows you to make some very refined brake adjustments for smooth picking to control rollback.
Page 172 Final Adjustment 6. Apply a maximum value of brake voltage, very briefly, at the start of movement. This gets the brake quickly to the point in the lifting process where a substantial amount of tension is released. This is done as follows: •...
Page 173 DC Controlling Initial Start of Car Motion Figure 4.4 Effect of Speed pick delay on the start of car motion Volts Speed Pick Delay just right Not enough Speed Pick Delay Time Too much Speed Pick Delay Brake Lifts Become familiar with the correlation between what is seen on the scope and what is felt in the car at the start of motion.
Page 174: Calibrating The Floor Offsets
Once the floor offsets have been entered, iControl is able to calculate the exact location of each hoistway landing sill using the known exact position of the car, known exact position of the tar- get magnet and the measured distance from the car sill to the hoistway sill.
Page 175 DC Controlling Initial Start of Car Motion To calibrate the floor offsets: 1. Display the Floor Offsets Setup tab by selecting Floor Heights from the View > Layouts menu and then clicking the Setup > Floor Offsets tab. 2. Move the car to the desired starting landing (e.g. top or bottom terminal landing). The Ready indicator should light.
Page 176 Final Adjustment Table 4.1 Floor Offset Calibration Record Car Above/ Fractional Decimal Car Above/ Fractional Decimal Floor Floor below landing inch inch below landing inch inch Table 4.2 Fractional inch to decimal inch conversion Fractional in. Decimal in. Fractional in. Decimal in.
Page 177: Adjusting Leveling And Final Stop
DC Adjusting Leveling and Final Stop Adjusting Leveling and Final Stop This section describes adjusting leveling into the floor and bringing the car to a final stop. Final Approach and Leveling Observe elevator operation by watching the hoist motor and observing car response on iBox test point STP1 to GND (with the Virtual Oscilloscope Test point 1 parameter = Speed Feedback).
Page 178 Final Adjustment • Dead zone - The purpose of the dead zone is to ensure that the elevator stops at the same point whether approaching a particular floor from above or below. The dead zone is a soft- ware-defined area at a floor, typically 0.25 inches (6 mm) to 0.75 inches (18 mm) in height.
Page 179 DC Adjusting Leveling and Final Stop • Brake Coordination for Smooth Stops - Proper operation and setting of the brake is very important to achieve a smooth stop: 1. Before starting, the brake must be operating properly. Geared machine brakes are usu- ally very simple, however, the brake on a gearless machine requires detailed adjustment to obtain proper operation.
Page 180: Releveling Operation
Final Adjustment Releveling Operation • Relevel dead zone distance — The Relevel dead zone distance is similar to Dead zone distance except that the Relevel dead zone distance applies only while the car is releveling. During releveling, the brake is partially set and the speed is very slow (usually 4 to 8 feet per minute).
Page 181: Ride Quality (System 12 Scr Drive)
DC Adjusting Leveling and Final Stop Ride Quality (System 12 SCR Drive) If you are experiencing a ride sensation that is not exactly oscillation, but might be described as a rough texture, it might be due to: • The encoder, attached to the motor shaft, may not be mounted securely, which may cause bouncing or a slight variation in the speed feedback signal once every revolution.
Page 182: Load Weigher Adjustment For Dispatching
The load in the car can then be determined by reading the value at a given floor and subtracting the learned empty value for that floor.
Page 183 DC Load Weigher Adjustment for Dispatching Example: Light Load Threshold=20%. If the measured load in the car is less than 20%, the con- troller will only allow a certain number of car calls to be registered (number of calls is set on the iView Configuration >...
Page 184: Load Weigher Configuration
Final Adjustment Load Weigher Configuration Once the load weigher is installed, you need to “tell” iControl what kind of load weigher you are using, set up some basic load threshold values, and learn the load values. You do this using iView.
Page 185: Learning Load Values
DC Load Weigher Configuration • Light load threshold (% of full load): Enter the percentage of full load weight below which the controller should consider the car to be in a light load condition. Typically set below 20% of full load. A setting of 00% = OFF.
Page 186: Load Weigher Learn Procedure
Final Adjustment Load Weigher Learn Procedure 1. Display the Load Weigher layout (View > Layouts > Load Weigher). 2. Enter the Start floor (floor at which the test weights are located) on the Setup > Load weigher tab. 3. Acquire “Write privilege” (Write privilege > Acquire) and place the iBox Learn switch in the ON position.
Page 187: Pre-Start Sequence
DC Pre-Start Sequence Pre-Start Sequence If the car is properly adjusted and running well, but the floor to floor times are not as quick as you would like, the Pre-Start Sequence parameters (Configuration > Drive > General tab) can be used to allow the brake and/or motor to be energized while the doors are closing, thereby allowing the elevator to leave the floor as soon after the doors are locked as possible.
Page 188: Allow Machine To Be Energized: After Doors Are Locked
Final Adjustment Allow machine to be energized: After doors are locked This is the default Pre-Start Sequence option. It specifies that the doors must be locked before energizing the motor and brake. The diagram below shows the parameters that affect this option and the resulting sequence of operation.
Page 189: Allow Machine To Be Energized: When Door Position Monitor Is Activated
DC Pre-Start Sequence Allow machine to be energized: When door position monitor is activated This Pre-Start Sequence option is much the same as the “After doors are locked” option except that Door Position Monitor status is used to determine when the machine may be energized rather than the Doors Locked sensors.
Page 190: Allow Machine To Be Energized: While Doors Are Closing With Motor Only
Final Adjustment Allow machine to be energized: While doors are closing with motor only This Pre-Start Sequence option allows the motor to be energized while the doors are closing so that when the doors are locked, the brake picking sequence can be started immediately. The diagram below shows the parameters that affect this option and the resulting sequence of oper- ation.
Page 191: Partially Picked Brake
DC Pre-Start Sequence Allow machine to be energized: While doors are closing with motor & partially picked brake This Pre-Start Sequence option allows the motor to be fully energized and the brake to be par- tially energized while the doors are closing, so that when the doors become locked, the car can begin moving as soon as the brake is fully picked.
Page 192: Brake
Final Adjustment Allow machine to be energized: While doors are closing with motor & fully picked brake This Pre-Start Sequence option allows the motor and brake to be fully energize while the doors are closing, so that the car can begin moving when the doors become locked and the Speed pick delay 1 timer expires.
Page 193: Calibration And Verification Of Safety Functions
DC Calibration and Verification of Safety Functions Calibration and Verification of Safety Functions Before performing the following adjustments and tests please do the following: 1. Verify that the car performs the releveling operation properly. Please refer to “Verify Releveling” on page 4-6 see “Releveling Operation ”...
Page 194: Verify Tach Error Does Not Trip On Emergency Stop
Final Adjustment Verify Tach Error Does Not Trip on Emergency Stop 1. Set the iBox Fault/Function Bypass switch to the OFF position. 2. Make sure the Tach Error fault is no longer bypassed (Diagnostics > Fault Bypass tab). 3. With a full load in the car, run the car up and down the hoistway to verify that the Tach Error fault is not generated.
Page 195 DC Calibration and Verification of Safety Functions Adjustment Procedure Use the following procedure to adjust the parameters on the Configuration > Drive > Safety tab used to generate the SCR Loop Over Current Fault. Rated loop over-current 1. With a full load in the car, run the car up. On the Operational Status tab, observe Arma- ture current while the car is traveling at steady speed (not accelerating or decelerating).
Page 196: Safety Tests
Final Adjustment Safety Tests iControl provides highly automated safety testing. Before running any tests, the car must be properly balanced and adjusted. From the iView Safety Tests screen (View > Safety Tests), the following tests may be run: • Car/Counterweight Safety Test •...
Page 197: Running A Test
DC Safety Tests Running a Test 1. Place the iBox in Test mode. 2. Select the desired test on the Safety Tests screen. 3. Set the speed which the car must attain to trigger the condition being tested. (All tests except Emergency Brake Test/Unintended Motion require a speed input.)
Page 198: Car/Counterweight Safety Test
Final Adjustment Car/Counterweight Safety Test This is a two-part test. Car safety testing verifies operation of the car safeties. The objective of the test is to set the safeties, causing the hoist motor to break traction. The over-speed must be sufficient in magnitude to cause the governor to trip mechanically and to set the car safeties.
Page 199: Car/Counterweight Buffer Test
DC Safety Tests Car/Counterweight Buffer Test This is a two-part test. The car buffer test verifies that the car striking the buffer will cause the hoist motor to break traction and that the car buffer will automatically return to its fully- extended state after having been fully compressed.
Page 200: Contract Overspeed Test
Final Adjustment Contract Overspeed Test This test verifies that moving the elevator at a speed greater than the programmed contract overspeed will result in an emergency stop. 1. Position the car in the middle of the hoistway. 2. On the iView > Safety Tests tab, set Speed to exceed the programmed contract over- speed value, but not high enough to cause the electrical or mechanical governor to acti- vate.
Page 201: Normal Terminal Switch Overspeed Tests
DC Safety Tests Normal Terminal Switch Overspeed Tests Per switch, this test verifies that either an emergency slowdown or emergency stop will be initi- ated if an elevator encounters an NTS switch and is moving at a speed greater than the pro- grammed overspeed value for that switch.
Page 202: Emergency Terminal Switch Overspeed Tests
Final Adjustment Emergency Terminal Switch Overspeed Tests Per switch, this test verifies that an emergency stop will be initiated if an elevator that is moving at a speed greater than 95% of the programmed contract speed encounters the ETS switch in the cars direction of travel (DETS if the car is moving in the down direction, UETS if the car is moving in the up direction).
Page 203: Terminal Switch Overspeed And Position Faults
DC Safety Tests Terminal Switch Overspeed and Position Faults The Overspeed Level 1, Level 2 and Position margins are calculated based on the speed and position values learned during the terminal learn procedure (see “Learning Normal & Emer- gency Terminal Limit Switches” on page...
Page 204 Final Adjustment The following illustration shows the car reaction to overspeed conditions at Normal and Emer- gency Terminal switches in the down direction. Figure 4.6 Normal and Emergency Terminal Overspeed Reaction 95% of contract speed Contract speed Overspeed 1 Overspeed 2 Normal Terminal Switch Car trips Terminal Switch Emergency Terminal Switch...
Page 205: Before Release To Passenger Operation
DC Before Release to Passenger Operation Before Release to Passenger Operation Danger Before the elevator can be turned over to normal passenger use, it is important that no safety func- tion or circuit remains bypassed. Items to check include, but are not limited to: •...
Page 206 Final Adjustment 4-60 Manual # 42-02-7223...
Page 207: About System Options
System Options About System Options This section contains supporting information for optional iControl system components: • iCentral - Central Dispatcher: Description, installation and setup instructions for the Central Dispatcher (see page 5-2). • Comm-Connect Cabinet - Local Dispatcher: Description of the cabinet used for the...
Page 208: Icentral - Central Dispatcher
System Options iCentral - Central Dispatcher iCentral is the central dispatching option for iControl, coordinating dispatching, parking, spe- cial operating modes, emergency power response, security, and interaction with existing (leg- acy) controls. iCentral is used for the most demanding systems.
Page 209: Icue Dispatching Capabilities
DC iCentral - Central Dispatcher Figure 5.1 iCentral Functional Diagram iControllers iCue iView PC connected though internet or LAN iView iCue Internet System User-defined Inputs/Outputs Serial Hall Call Nodes Serial Hall Call Driver iCue Dispatching Capabilities • To 96 landings •...
Page 210: System Interconnect
System Options System Interconnect It can be helpful to have a general understanding of the way the entire iControl system is inter- connected. This section contains high-level interconnection drawings for: • System Interconnection: Basic car control and dispatcher interconnections. • Dispatcher Interconnection: More detail for dispatcher interconnections.
Page 211 Sensor Board Landing Zone Discrete Car Calls Rear (option) magnet (if not Serial Car Call) Field Inputs Inputs Sensor Board Landing Zone Serial links to iControl Front magnet Cartop Board Load Weigher (ICE-CTP) Signal Board (LS-IPH) Serial Link Serial Car Call...
Page 212: Cabinet Installation
System Options Cabinet Installation Installation of the iCentral cabinet is similar to the installation of an iController cabinet. Please refer to “Machine Room Preparation” on page 2-4. MCE Job Prints MCE job print drawing numbers use the format “Job Number — Car Number —...
Page 213: Check For Shorts To Ground
DC iCentral - Central Dispatcher Check for Shorts to Ground Check for shorts to ground before powering up the system. Power must be OFF at the main disconnect(s). A short to ground is defined as having a resistance of less than 20 ohms between the #1 (Common) bus and the terminal being tested.
Page 214 System Options Figure 5.6 Elevator Controller to iCue Cabinet Wiring iController 1 iController 2 iController 3 iController 4 ST2A, ST2B, ST2C, ST2D, etc. iCue 5-8 Manual # 42-02-7223...
Page 215: Initial Power Up And Bus Verification
DC iCentral - Central Dispatcher Initial Power Up and Bus Verification After AC power is connected, you are ready to temporarily power up and check that power buses inside the cabinet are providing their proper outputs. Caution This procedure assumes that no field wiring has yet been connected. If field wiring has been con- nected, it must be disconnected before beginning this procedure.
Page 216: Icontrol Ethernet Overview
System Options iControl Ethernet Overview iControl uses two distinct Ethernet networks: • The MCE System hub/switch connects iCentral to other MCE equipment like the elevator controllers, Serial Hall Call systems, and input/output expansion boards (SC-ION boards). • The LAN hub/switch connects iCentral and elevator controllers to a PC running the MCE iView application (used to configure both iCentral and iControls).
Page 217: System Tcp/Ip
TCP/IP communications between connected devices are correctly connected. • iControls: Each car in the group is under the primary direction of its own iBox/iControl. iCue communicates with all the iControls in its group through the System TCP/IP bus.
Page 218: System Hub/Switch
System Options System Hub/Switch The System hub/switch connects iCue to the iControls in its group, to Serial Hall Call drivers through SC-HCE- ME modules, and to SC-ION input/output expansion boards. The Serial Hall Call and input/output expansion board connections are completed at the factory before the system is shipped and need only be checked to make certain they are in place.
Page 219: Lan Hub/Switch
DC iControl Ethernet Overview LAN Hub/Switch 1. Connect the group and car controllers and the iView PC to the LAN hub/switch as shown in the illustration below and in the MCE job prints. The job prints are the con- trolling document.
Page 220: External Connections
System Options External Connections As indicated in the LAN hub/switch connection illustration, the elevator group may be con- nected to larger area networks in the building or, through T1, DSL, or dial-up modems, to remote sites via phone lines or the Internet. These kinds of connections are necessary if remote iView or iMonitor access is required.
Page 221: Tcp/Ip Reference
DC iControl Ethernet Overview TCP/IP Reference An Ethernet network is basically several computers (or smart equipment with a computer inside — like the iBox or iCue) all connected together at a single point (the hub/switch) so they can communicate with each other. In order for a message from one computer to reach the com- puter (or iCue/iBox) it wants to talk to, all the computers connected to the network have to have their own unique address.
Page 222 System Options Figure 5.10 Example of Ethernet Addresses and Connection GROUP 1 ETHERNET ADDRESS EXAMPLES CAR A CAR B CAR C CAR D CAR E 192.168.193.001 192.168.193.001 192.168.193.001 192.168.193.001 192.168.193.001 192.168.192.001 192.168.192.002 192.168.192.003 192.168.192.004 192.168.192.005 192.168.191.001 192.168.191.002 192.168.191.003 192.168.191.004 192.168.191.005 Swing Car Additional System Hub Connections for Serial Hall Call Hall Calls...
Page 223 DC iControl Ethernet Overview iView, Direct PC used for Direct Connection 192.168.193.2 255.255.255.0 Subnet Mask iCue Group Controller 0.0.0.0 ( . . . ) Gateway iCue LAN 192.168.191.201 255.255.255.0 Subnet Mask 192.168.191.254 Gateway ORANGE CABLES SYSTEM HUB iCue SYSTEM 192.168.192.201...
Page 224: Mce System Ethernet
The LAN hub/switch is provided so that you can connect a PC running iView, which will then be able to access all the iCue and iControl hardware connected to the hub/switch. The TCP/IP addresses for the LAN network (iView connection) are set at the factory. If your iView PC was provided by MCE, you can simply connect the iBoxes, the iCue, and the iView PC to the hub/switch and they are ready to communicate.
Page 225 DC iControl Ethernet Overview 6. Click Properties to open the Local Area Connection Properties dialog. 7. In the Local Area Connection Properties dialog, select Internet Protocol (TCP/IP). 8. Click Properties to open the Internet Protocol (TCP/IP) Properties dialog. 5-19...
Page 226 System Options 9. Set the IP Address to match the iCue LAN EXCEPT FOR the last set of numbers. Typi- cally, you can set your PC’s IP address to 192.168.191.101. 10. Set the Subnet Mask to 255.255.255.0. 11. Set the Default gateway to 192.168.191.254. 12.
Page 227: Setting Icue Pc Lan Ip Addresses
DC iControl Ethernet Overview Setting iCue PC LAN IP Addresses You should not need to set the iCue LAN IP address unless you are changing addresses to add the LAN hub/switch to an existing Local Area Network. When entering IP Addresses on a PC, do not enter leading zeros (i.e., .020 is entered as .20).
Page 228 System Options 6. Click Properties to open the Sys- tem Ethernet Properties dialog. 7. In the System Ethernet Proper- ties dialog, select Internet Proto- col (TCP/IP). 8. Click Properties to open the Internet Protocol (TCP/IP) Prop- erties dialog. 5-22 Manual # 42-02-7223...
Page 229 DC iControl Ethernet Overview 9. Set IP address, Subnet Mask, and Default Gateway accord as required to reside on the new LAN. The values shown below are the factory values. 10. Click OK and follow any instructions to save the changes you made.
Page 230: Pinging
System Options Pinging If you suspect that one or more of the devices is still not communicating, you can “ping” them from the iView PC. Pinging just lets you send a message manually that just asks for a reply if the other device can “hear”...
Page 231: Icue User Interface
DC iControl Ethernet Overview iCue User Interface Whenever iCue is running and the monitor is switched to the iCue PC (rather than the iView PC), the iCue GUI is visible on the screen. The iCue GUI provides an overview of group opera- tion and status.
Page 232: Write Permission
• IP Address: The TCP/IP address of the group on this network • Subnet Mask: The subnet mask limits the number of valid addresses in the group. For iControl, this should always be 255.255.255.0 • Gateway LAN: 192.168.191.254 • Gateway System: 000.000.000.000 (o.o.o.o) •...
Page 233: Icue Watchdog
DC iControl Ethernet Overview iCue Watchdog When iCue is running, there is a utility called iCue Watchdog running in the background. The watchdog monitors iCue and makes certain that it continues to run as it should. The watchdog is a Windows Service, which means that it will not show up on the task bar or icon tray.
Page 234: Comm-Connect Cabinet - Local/Dispatcher
System Options Comm-connect Cabinet - Local/Dispatcher The Comm-connect cabinet is used to house the system communication components when the Local/Dispatcher option is used. This cabinet houses the Serial Hall Call Driver(s), Ethernet Switches, SC-ION Serial Control I/O Node board and AC power connections. Figure 5.11 Typical Comm-connect Cabinet SC-HCE-ME Serial to Ethernet Adapter...
Page 235 DC Comm-connect Cabinet - Local/Dispatcher Figure 5.12 Comm-Connect Interconnection iMonitor or iReport iView Comm-connect Cabinet To Cars LAN: iView, iMonitor, iReport (4 connections per car max.). General Field Inputs to Dispatcher SYSTEM Hall Calls To Cars SYSTEM: Hall calls, Parking,...
Page 236: Serial Hall Call
System Options Serial Hall Call Direct serial I/O allows hall call buttons/indicators, to be connected to iControl using a simple, 2-wire bus for both communication and power. This serial bus reduces the amount of wiring required per riser and makes the wiring job much easier and less expensive.
Page 237 DC Serial Hall Call Figure 5.14 Typical iCentral Serial Hall Call Connections Figure 5.15 Typical Serial Hall Call Connections for a Simplex or Swing Car iController Open power box 5-31...
Page 238: Hall Call Installation
System Options Hall Call Installation Installing a serial hall call system includes: • Pulling the serial bus wiring • Setting the node board addresses • Installing the hall call enclosures (refer to the job prints) Pulling Serial Bus Wiring The serial bus is the physical, twisted pair of 14 AWG or 16AWG wires along which all the hall calls are connected.
Page 239: Setting Node Board Addresses
DC Serial Hall Call Setting Node Board Addresses Each hall call enclosure contains a “node” board. The node board provides two outputs to power hall call lamps or LEDs, two inputs for the hall call buttons, and jumpers to set floor ID and hall call “type.”...
Page 240 System Options • Call Type Jumper Jumper JP1 sets the call type for the two switch/lamp combinations serviced by the node board (or the individual jumpers can be thought of as setting the last digits of the boards two unique serial addresses).
Page 241: Checking Serial To Ip Connections
DC Serial Hall Call Checking Serial to IP Connections Each Serial Hall Call bus originates from a Serial Hall Call Driver in the iCue cabinet. Each Serial Hall Call Driver in turn communicates with iCue through the System Ethernet switch.
Page 242: Troubleshooting
The serial I/O protocol used for MCE serial hall call and serial I/O board connections is trans- lated to and from Ethernet bus protocol for system level communication over the iControl Sys- tem network by the SC-HCE board. (System hub/switch in iCentral dispatcher. Orange TCP/IP cables.)
Page 243 DC Serial Hall Call Mechanical Configuration • Ethernet Port: Standard Ethernet port. Used to connect this assembly to the System Ethernet hub/switch using an orange Ethernet cable. Figure 5.19 Ethernet Ports Link status Network activity Table 5.3 Ethernet Port LEDs...
Page 244 System Options Table 5.6 SC-HCE-2 DIP Switch SW1 Switch Run State Function Not used. When ON, enables in-circuit programming through serial port. When ON, enables in-circuit programming through serial port. When ON, runs the ethernet bootloader instead of main application (on board startup). Sets high bit of board ID.
Page 245: Trouble Indications
DC Serial Hall Call Trouble Indications • Hall Call buttons do not work • Building Hall Call buttons do not light when pressed • Building Hall Call buttons do not stay on until elevator arrives • Elevator reports “Wild Operation” (stopping at every floor) •...
Page 246 System Options General Check 1. Check all power and data cable connections. • Port status LED on System hub/switch should light when the Ethernet cable is plugged in between the hub/switch and the serial/Ethernet board. • Ribbon cable (if used) seated properly on the hall call driver and the serial/Ethernet board.
Page 247 DC Serial Hall Call Serial Connection Check, -2 Board The Hyperterminal utility may be used to check or default internal settings on SC-HCE boards. Contact MCE for information. 5-41...
Page 248 System Options TCP Address Check, -ME Board The Digi Device Discovery utility may be used to check and/or reset the TCP/IP address of the serial/Ethernet assembly (SC-HCE-ME). This utility is available from MCE. 1. Start the Digi Device Discovery utility. The utility will launch, and check the System net- work for any connected SC-HCE-ME.
Page 249 DC Serial Hall Call 3. In the Configure Network Settings dialog that appears, select Manually configure net- work settings. 4. Check the drawing package for the dispatcher or the Ethernet Address examples draw- ing in the manual. Please refer to “Ethernet Addresses” on page 5-14.
Page 250: Hall Call Driver
System Options Hall Call Driver Serial cable to serial/ ethernet translator board Serial Bus connection AC power Quick Test You can do a basic functionality test on the hall call driver. With power applied: 1. Verify 120VAC power to the driver. 2.
Page 251 DC Serial Hall Call Driver Voltages Test The hall call driver can be more thoroughly tested if necessary. The test is relatively simple on iCentral units shipped after July, 2005 because a female, “test” connector has been installed in the middle of the ribbon cable connecting the driver to the SC- HCE (Digi board) assembly.
Page 252: Flexible I/O
System Options • Node Response test 1. Insert a probe wire into pin 20, connect the positive voltmeter lead. 2. You should see 5-volts, +/- 10%. Leave the probe wire in place. 3. Bend the wire/jumper and short pin 20 to pin 17. 4.
Page 253: Sc-Ion Boards
DC Flexible I/O SC-ION Boards The number of SC-ION boards in an iCue system will vary depending upon system configura- tion and the number of additional inputs and outputs required for the job. A typical job might have one SC-ION board, providing 16 additional inputs and 16 additional outputs.
Page 254: I/O Connections
System Options I/O Connections Connect inputs and outputs as shown in your job prints. SC-ION board inputs are 115Vac +/- 15%. Outputs may be configured (in specific groups) to provide either a path to ground or cur- rent to drive indicator lamps/LEDs. Output State Selection The outputs are divided into three groups.
Page 255: Serial Cop
DC Serial COP Serial COP With the Serial Car Operating Panel system, car call buttons connect directly to a serializing board located in the car station enclosure. Multiple Serial COP boards daisy-chain together to accommodate high-rise installations with a lot of call buttons.
Page 256 System Options Wiring from the Serial COP board(s) to the iLink cartop box is a short length of shielded cable with a telephone-style RJ-11 connector at each end. The iLink cartop box supports up to four serial control panel connections. Communication between iLink and the controller is also serial, thereby reducing the traveler and hoistway cabling.
Page 257: Serial Cop Board Specifications
DC Serial COP Serial COP Board Specifications Each Serial COP board handles up to 24 call buttons or switches. If more inputs are required, Serial COP boards are daisy-chained together. • Each of the Serial COP board’s 24 I/O connections can be used as an input, an output or a combined call input and output.
Page 258: Emco Load Weigher
• Control Unit description of operation (see page 5-55) • Load Weigher calibration procedure (page 5-56) • Final calibration with iControl (see page 5-58) • Installation with 2 to 1 roping (see page 5-59) • Verifying the zero calibration (empty car weight) (see...
Page 259: Installing The Sensors
DC EMCO Load Weigher Installing the Sensors The model SWK sensors are installed using the tool supplied. In some instances it may be nec- essary to extend the length of the handle to gain more leverage. 1. Typically the sensors are mounted on the wire ropes directly above the cartop hitch.
Page 260: Installing The Control Unit And Connecting The Wires
The control unit may be mounted using the DIN mounting bracket supplied or using the holes in the sensor itself. Choose a convenient location on the cartop. (For iControl, if there is space, the control unit could be mounted inside the iLink enclosure.) Three sets of wires must be connected to the EMCO VK-3v control unit: 1.
Page 261: Programming The Emco Vk-3V Control Unit
DC EMCO Load Weigher PROGRAMMING the EMCO VK-3v Control Unit Description of Operation The purpose of the EMCO Load Weigher system is to measure the load in the elevator and pro- vide usable information about the load to the elevator controller. This information is used for pre-torquing and for dispatching decisions, e.g.
Page 262: Calibration
System Options Calibration Manual Calibration with Weights The Calibration with Weights procedure is the most accurate and recommended method of cal- ibrating the EMCO Load Weigher. This procedure allows the EMCO control unit to do the fol- lowing: • Learn the empty weight of the car and set this weight as the zero reference (the analog voltage output from the control unit will be about zero volts at this weight).
Page 263: Auto-Zero Calibration
7. With the full load of weights in the car, using a digital multimeter, measure the voltage at terminals 0-10v and Com on the control unit. It should be approximately 8 volts. Note the exact value. 8. Proceed to Final Calibration with iControl on page 5-58.
Page 264: Final Calibration With Icontrol
System Options Final Calibration with iControl 1. Connect the multimeter to test points TP_LW and GND on the ICE-CTP board inside the cartop Box. Adjust trimpot LW ADJ until the multimeter reads the same as the value noted in step 8.
Page 265: Installation With 2 To 1 Roping
(see Load Weigher Adjustment for Dispatching in Section 4. 6. iControl needs to learn the empty and full load weights at every landing available to this car. This is a semi-automated process (see Learning Load Values in Section 4.
Page 266: Verifying The Zero Calibration (Empty Car Weight)
System Options Verifying the zero calibration (empty car weight) It is recommended to verify the zero calibration if: 1. When working with new ropes, the calibration may change slightly as the ropes settle. After the first 30 days of operation it is recommended to check the empty car weight, with the car in the middle of the hoistway, using the display on the EMCO Load Weigher.
Page 267: Mce Load Weigher
DC MCE Load Weigher MCE Load Weigher The MCE Load Weigher is designed for use with isolated platform elevator cars. The accuracy of the load weigher depends on the condition of the rubber isolation pads. If they are old, cracked or hard, the performance of the load weigher will suffer.
Page 268: Installation Method #1 — Preferred
System Options Installation Method #1 — Preferred When installing, remember that the car is supported near the center of gravity. The center of gravity may be offset towards the front of the car to compensate for door operator weight unless the car has both front and rear doors.
Page 269 DC MCE Load Weigher Figure 5.4 Target Bracket and Sensor mounted on Support Assembly and Car frame These screws hold the 2 small angles to the bottom of the floor - minimum 2 screws per angle. Center of Floor...
Page 270 System Options If the distance between where the target bracket attaches to the floor and the center of the floor is greater than 20% of distance “A” (see Figure 8.2), an alternate mounting method may pro- duce better results. • Example: If distance “A” is 10' Then 20% of 10' is 2' Therefore, if the target bracket attaches to floor more than 2' from the center of the channel, an alter- nate method of mounting is suggested (see Figure 8.5).
Page 271: Method #1 Installation Instructions
• Connecting the wiring • Adjusting the amplifier (iLink car top box) • Verifying performance • Adjusting iControl parameters • Maintenance recommendations The Support Assembly 1. Cut a piece of 1 ¼" x 1 ¼" or 1 ½" x 1 ½" steel angle to span the width of the floor as shown in Figures 8.3 and 8.6.
Page 272 • Condition of rubber pads • Voltage variance when weight is in center of car vs. on edge of car (sagging problem) Adjust iControl Parameters The load weigher is now installed and properly adjusted. However, the parameter adjustments for the load weigher must be completed.
Page 273: Installation Method # 2
DC MCE Load Weigher Installation Method # 2 1. Re-use pre-existing holes or brackets to mount sensor and target. 2. When using supports created for other load weighers, be sure to arrange sensor and tar- get so that increasing the weight in the car increases the clearance between the proxim- ity sensor and the target.
Page 274 System Options 5-68 Manual # 42-02-7223...
Page 275: About Troubleshooting
Safety String Bypass Jumper Temporarily bypasses an open safety string. page 6-3 Fault and status messages table - includes a description, car iControl Messages page 6-13 reaction and troubleshooting tips for each message. A description of the iBox boot process, procedure for...
Page 276: Troubleshooting Tools
Enter. Scroll down to see all of the data, including the event name. A description and troubleshooting suggestions for each event can be found in iView online Help (Help > iView Help > Messages Reference) and in the iControl Messages table in this user guide.
Page 277: Safety String Bypass Jumper
DC Safety String Bypass Jumper Safety String Bypass Jumper If any switch or relay in the safety string opens, the car immediately loses power and stops. In some situations, you may need to temporarily bypass an open safety string to move the car so that the safety string can once again be “made up.”...
Page 278: Icontrol Messages List - Numerical
(iBox maintains an Event Log as well.) This section contains two tables. Table 7.2 provides a cross-reference from iBox ID numbers to the associated iControl message name. Table 7.3 lists system messages in alphabetical order and describes the cause and recom- mended troubleshooting procedures if appropriate.
Page 279 DC Safety String Bypass Jumper iControl Message (iBox Event Log and iView Controller Event Log) ID # Front Safe Edge Failure Rear Photo Eye Failure Rear Safe Edge Failure Cartop Inspection Operation Hoistway Access Operation Machine Room Inspection Operation...
Page 280 Troubleshooting iControl Message (iBox Event Log and iView Controller Event Log) ID # Rear Safe Edge Bypassed Inspection Overspeed Fault Tach Error Fault Drive Enable Feedback Fault Safety A Inspection Overspeed Fault IO Map Compare Fault IO Map Toggle Compare Fault...
Page 281 DC Safety String Bypass Jumper iControl Message (iBox Event Log and iView Controller Event Log) ID # Safety A UETS Level 2 Speed Fault Excessive Faults Shutdown Safety A Unintended Motion Fault Ascending Car Overspeed Fault Position Synchronization Required at Terminal...
Page 282 Troubleshooting iControl Message (iBox Event Log and iView Controller Event Log) ID # SCR AC Phase Fault SCR Contactor Fuse Fault SCR Phase Lock Loop Fault SCR Phase Lock Loop Warning SCR Dynamic Brake Fault SCR Instantaneous Over Current SCR Armature Voltage On...
Page 283 DC Safety String Bypass Jumper iControl Message (iBox Event Log and iView Controller Event Log) ID # Controller Main Computer Startup Floor Synchronization Fault Terminal Synchronization Fault Position Synchronization Fault Up Emergency Terminal Switch Shutdown Down Emergency Terminal Switch Shutdown...
Page 284 Troubleshooting iControl Message (iBox Event Log and iView Controller Event Log) ID # Serial COP Bus 2 Inventory Fault Serial COP Bus 3 Inventory Fault Serial COP Bus 4 Inventory Fault User Defined Event 1 On User Defined Event 1 Off...
Page 285 DC Safety String Bypass Jumper iControl Message (iBox Event Log and iView Controller Event Log) ID # SPA Spare Event 4 SPA Spare Event 5 SPA Spare Event 6 SPA Spare Event 7 SPA Spare Event 8 LCD Fault...
Page 286 Troubleshooting iControl Message (iBox Event Log and iView Controller Event Log) ID # Hall Call Bypass Input ON Hall Call Bypass Input OFF Capture Input ON Capture Input OFF Brake Voltage Not Off Fault Emergency Power Recall (In Service) Emergency Stop Input Activated...
Page 287: Icontrol Messages
DC iControl Messages iControl Messages Table 6.3 iControl Messages iControl Messages Alternate Floor Smoke Sensor Recall, ALTERNATE FLOOR SMOKE Description: Recall to main fire floor due to active or latched smoke detector input(s) from floors other than the main recall floor.
Page 288 Troubleshooting Table 6.3 iControl Messages iControl Messages Backup Power Recall OFF Description: The Backup power recall input has been deactivated. Backup Power Recall ON, BACKUP POWER RECALL Description: The Backup power recall input has been activated (signal from the TAPS Traction Auxiliary Power Supply).
Page 289 DC iControl Messages Table 6.3 iControl Messages iControl Messages Brake Drop Fault, BRAKE DROP FAULT Description: Indicates brake contact input (SP2D or Brake Switch) was not in the state required by the “Brake is picked when SP2D or Brake Switch terminal is high (low)” parameter, indicating brake was not fully dropped for more than one second after the car had stopped.
Page 290 Troubleshooting Table 6.3 iControl Messages iControl Messages Brake Pick Fault, BRAKE PICK FAULT Description: Indicates brake contact input (SP2D or Brake Switch) not in the state required by the “Brake is picked when SP2D or Brake Switch terminal is high (low)” parameter, indicating brake was not fully picked during one entire run or was late going low (or high) indicating a slow picking brake during three consecutive runs.
Page 291 DC iControl Messages Table 6.3 iControl Messages iControl Messages Bus 3 Fuse Open, BUS 3 FUSE OPEN Description: The bus 3 fuse is open. Car Reaction: Emergency stop. Cancel demand and open doors. No further movement is allowed. Troubleshooting: Check bus 3 fuse located at bottom of iBox.
Page 292 Troubleshooting Table 6.3 iControl Messages iControl Messages Car delayed with doors stalled, CAR DEL DOORS STALLED Description: Indicates that a car, with doors stalled, has been delayed in reaching an assigned destination. Car Reaction: Assigned hall calls will be reassigned to other available cars.
Page 293 DC iControl Messages Table 6.3 iControl Messages iControl Messages Car out of service with unknown door position, CAR OS DOORS UNKNOWN Description: A delayed car with invalid doors has remained so for an excessive period of time (as determined by a user-programmed timer parameter, Car Operation Screen/Passenger tab.
Page 294 2. The Car Panel Inspection input is Normally High. Car shut down due to emergency power operation with no supervisor (Activated) Description: iControl has detected that an emergency power condition exists and it has not established com- munication with the emergency power supervisor (typically a group controller).
Page 295 2. If the connections are clean and tight, use an oscilloscope to check the TX and RX signals themselves. Or, if practical, connect the iBox end of the connection to another iControl in the machine room and see if that controller can communicate with the iLink box.
Page 296 Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped. Troubleshooting: 1. Check 1, 2, and 3 bus terminal voltages from iControl, through traveler, to car terminal strip. 2. Refer to job print drawing CT, check strip to iLink connections.
Page 297 DC iControl Messages Table 6.3 iControl Messages iControl Messages Construction Cartop Inspection Operation, Cnstr Cartop Insp, Cnstr CT Insp Description: Car is on Construction mode and Cartop Inspection. When in construction mode, the iBox is always “on inspection” operating only in Cartop or Machine Room inspection. Car top has precedence over Machine Room, just as in Passenger operation.
Page 298 Troubleshooting Table 6.3 iControl Messages iControl Messages Door Lock Clipped Greater than 200fpm, DOOR LK CLIPPED G200 Description: The door lock signal (DLAT, DLMS, DLAB, or GS) went low for over 300mS while the car was moving at over 200 fpm.
Page 299 DC iControl Messages Table 6.3 iControl Messages iControl Messages Down Emergency Terminal Switch Shutdown, DOWN ETS SHUTDOWN Description: The Down Emergency Terminal switch opened at a speed or position exceeding its specified threshold. The fault stays latched and the Fault Reset button must be pushed to clear it. If generated when the car is stopped, the fault will self clear when the condition no longer exists.
Page 300 Description: Not currently used. Drive Enable Feedback Fault, DRIVE ENABLE FDBK FLT Description: iControl failed to send the Drive Enable signal to the drive or the drive failed to respond to the Drive Enable signal. (applies to both AC and DC drives).
Page 301 DC iControl Messages Table 6.3 iControl Messages iControl Messages Drive Fault, DRIVE FAULT Description: Detected by the drive, this fault indicates that the motor speed is outside threshold limits defined by the drive parameter. (TORQMAX drive only.) Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped.
Page 302 Troubleshooting Table 6.3 iControl Messages iControl Messages Dual Channel QUAD Fault, DUAL CHANNEL QUAD FLT Description: The Safety system did not detect movement of the car even though the iBox processor reported car movement, or the Safety system reported car movement while the processor did not.
Page 303 DC iControl Messages Table 6.3 iControl Messages iControl Messages Earthquake Operation (Seismic Switch) Description: The Seismic Switch has been activated (input has gone low), indicating an earthquake condi- tion. Car Reaction: The car will react as determined by user configuration. (iView/Car Operation/Earthquake) The car will either make an emergency stop and then move slowly to the next available floor or it will stop nor- mally at the next available floor in the direction of travel.
Page 304 Troubleshooting Table 6.3 iControl Messages iControl Messages Emergency Alarm Activated (Alarm button), Emergency Alarm Activated, EMERG ALARM ACTI- VATED Description: Emergency Alarm input activated. Typically used to sound an alarm and/or illuminate an indica- tor light to alert security personnel.
Page 305 DC iControl Messages Table 6.3 iControl Messages iControl Messages Emergency Brake Leg 2 Short Fault, EMERG BRK LEG 2 SHORT. See Emergency Brake Leg 1 Short Fault. Emergency Brake OK open, EMERG BRAKE OK OPEN Description: The Emergency Brake OK input has dropped (off) when the configuration states that the brake is installed and therefore the input should be picked (on).
Page 306 1. Related inputs: EPI: Active level field adjustable. Emergency Power and no communication with group, EMERG PWR NO COMM Description: iControl has detected that an emergency power condition exists and it has not established com- munication with the emergency power supervisor (typically a group controller).
Page 307 DC iControl Messages Table 6.3 iControl Messages iControl Messages Emergency Power Recall, EMERG POWER RECALL. See Emergency Power Activated. Description: This event is logged when the elevator has been commanded to lower to the emergency power recall floor. Car Reaction: The elevator proceeds to the user-defined emergency power recall floor. Door operation at the recall floor is in accordance with the user defined door operation under emergency power recall conditions.
Page 308 Troubleshooting Table 6.3 iControl Messages iControl Messages Excessive Brake Feedback Fault, EXCESS BRAKE FDBK FLT Description: After each brake activity, the controller checks to see that brake current is bleeding off properly. (After 1 second, brake voltage should be at or below 85% of the voltage applied by the last command.) This fault is issued if brake voltage remains too high when checked by the controller.
Page 309 DC iControl Messages Table 6.3 iControl Messages iControl Messages Excessive Relevels Fault, EXCESS RELEVELS FAULT Description: The car has failed to relevel after ten attempts. Car Reaction: Cancel all calls and shutdown. The doors are cycled and the car remains shutdown until the fault is reset by pressing the iBox Fault Reset button, toggling Inspection or cycling power to the controller.
Page 310 Troubleshooting Table 6.3 iControl Messages iControl Messages Field Module Over Temperature Fault, FIELD MODULE OVR TEMP Description: Motor Field module heat sink temperature is excessive (DC only). Car Reaction: Stop at next floor. Restart not permitted. Troubleshooting: 1. Check machine room temperature (should not exceed 104 degrees F or 40 degrees C).
Page 311 DC iControl Messages Table 6.3 iControl Messages iControl Messages Fire Service Recall Deactivated Description: Fire service recall operation has been deactivated. Car Reaction: Car returns to its prevailing mode of operation. Troubleshooting: NA Flood Operation Activated, FLOOD OPERATION Description: Flood operation has been activated via system command or hardware switch.
Page 312 Troubleshooting Table 6.3 iControl Messages iControl Messages Floor Synchronization Fault Description: While performing floor synchronization, the system either did not receive edge position data from the cartop or did not detect a floor position magnet where expected. Car Reaction: The car will stop and initiate terminal synchronization.
Page 313 DC iControl Messages Table 6.3 iControl Messages iControl Messages Front Door Close Time-out Description: Front door failure to close detected. Controller will attempt to close doors for a period of time defined by Closing protection timer parameter (Door Motor Protection Timers). If timer elapses prior to doors closing fully, this event is generated.
Page 314 Troubleshooting Table 6.3 iControl Messages iControl Messages Front Doors Stopped, FRONT DOORS STOPPED Description: The Door Stop button or Emergency Stop switch was activated causing the doors to be pre- vented from moving. Car Reaction: The car is not allowed to move unless the doors are fully closed.
Page 315 DC iControl Messages Table 6.3 iControl Messages iControl Messages Global Parameter Update, Reset Controller, PARAM CHNG-RESET CAR Description: Indicates controller parameters updated, controller reset required (iBox COMPUTER RESET). Car Reaction: Car is not allowed to run until parameter update completed and computer reset.
Page 316 Troubleshooting Table 6.3 iControl Messages iControl Messages Hall Call Service Enabled Description: Car is accepting hall calls (iBox IN GROUP indicator is On). See also, Hall Call Service Disabled. Heat Detectors Recall Activated, HEAT DETECTORS RECALL Description: A heat detector input has been activated.
Page 317 DC iControl Messages Table 6.3 iControl Messages iControl Messages Hoistway Heat Detectors Activated, HOIST HEAT DETECTORS Description: The hoistway heat detector input is activated. The fire warning light will flash until all heat detectors have been reset. The fire-warning buzzer will sound until the car is shutdown at a floor.
Page 318 Troubleshooting Table 6.3 iControl Messages iControl Messages IMP Switch Fault - Inspection, IMP SW FAULT: INSP Description: There is a problem with the iBox INSPECTION switch. Both poles must activate. Car Reaction: If stopped, the car is immediately shut down and taken out of service for all types of demands, including fire and medical emergencies.
Page 319 DC iControl Messages Table 6.3 iControl Messages iControl Messages Inspection Operation, Inspection Description: The car is operating in Inspection mode. Car Reaction: One of the inspection modes (in-car, machine room, or cartop) is active. The car will operate using the Inspection performance pattern.
Page 320 Troubleshooting Table 6.3 iControl Messages iControl Messages Invalid Configuration Input, INVALID CNFG INPUT Description: An invalid input was discovered when cross checking safety inputs against safety configuration. Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped. Troubleshooting: 1. Check car setup/wiring against Safety Screen configuration.
Page 321 DC iControl Messages Table 6.3 iControl Messages iControl Messages Invalid Configuration Input DLAB, INVLD CNFG INPUT DLAB Description: Door Lock Access Bottom. The safety system detected an input/safety setting difference when cross checking inputs against configuration. Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped.
Page 322 Troubleshooting Table 6.3 iControl Messages iControl Messages Invalid Configuration TALRQ, INVALID CNFG TALRQ Description: Top Access Landing Rear Qualifier. The safety system detected an input/safety setting differ- ence when cross checking inputs against configuration. Car Reaction: Safety OK remains off.
Page 323 DC iControl Messages Table 6.3 iControl Messages iControl Messages Invalid Configuration Inventory Cross Check RD Board, INV INVTRY XCHK RD BD Description: Rear Door board. Safety system detected a configuration/inventory (board complement) differ- ence when cross checking board complement against system configuration.
Page 324 Troubleshooting Table 6.3 iControl Messages iControl Messages Invalid Configuration Inventory Cross Check TALRQ, INV INVTRY XCHK TALRQ Description: Top Access Landing Rear Qualifier. The safety system detected a configuration/inventory (board complement) difference when cross checking board complement against system configuration.
Page 325 DC iControl Messages Table 6.3 iControl Messages iControl Messages IO Map Compare Fault Off (See: IO Map Compare Fault) IO Map Compare Long Term Fault, IO MAP COMPARE LT FLT Description: Safety A long term products did not match Safety B long term products for 1.2 seconds.
Page 326 Troubleshooting Table 6.3 iControl Messages iControl Messages LCD Fault Description: Generated if controller gets a “not ready” state from LCD. This can happen if iBox LCD is not connected properly or, with some LCD models, if contrast is set to far to an extreme.
Page 327 Car Reaction: Emergency Stop. Latched fault. Troubleshooting: 1. If this is an iControl with DC Drive using an encoder for speed feedback, this fault could indicate a mal- functioning encoder. 2. On the iView oscilloscope (or a DVM connected between STP1 and STP2), compare Pattern Command and Speed Feedback readouts.
Page 328 Troubleshooting Table 6.3 iControl Messages iControl Messages Machine Room Heat Detectors Activated, MR HEAT DETECTORS Description: The machine room heat detector input is activated. The fire warning light will flash until all heat detectors have been reset. The fire-warning buzzer will sound until the car is shutdown at a floor.
Page 329 DC iControl Messages Table 6.3 iControl Messages iControl Messages Motion Start Fault, MOTION START FAULT Description: Car initiated movement but was unable to start for more than ten seconds. Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped.
Page 330 Troubleshooting Table 6.3 iControl Messages iControl Messages Other Cars Alternate Fire Sensor Recall, OTHER CARS ALT FIRE Description: Alternate fire recall due to active or latched smoke detector input(s) from the hoistway or machine room of other cars in the system.
Page 331 DC iControl Messages Table 6.3 iControl Messages iControl Messages Position Quadrature Reversed Fault, POSITN QUAD RVRSD FLT Description: The arrival sequence of the quadrature pulse streams indicates travel in the opposite direction of that requested by the system. Car Reaction: None.
Page 332 Troubleshooting Table 6.3 iControl Messages iControl Messages Position Synchronization Required at Floor, POSITION SYNC-FLOOR Description: The elevator needs to verify position by crossing a door zone sensor. Car Reaction: Cancel all existing calls, synchronize to floor. Position Synchronization Required at Terminal, POSITION SYNC-TERMINAL Description: Elevator is lost and needs to locate a terminal door zone sensor to establish position.
Page 333 DC iControl Messages Table 6.3 iControl Messages iControl Messages Primary Fire Switch On, PRI FIRE SWITCH ON Description: The primary fire switch is in the On position. Car Reaction: Car will recall to Main fire recall floor, position its doors as directed on Car Operation/Fire/Mod- ify/Fire Recall screen, and wait for activation of the in-car firefighter switch.
Page 334 Troubleshooting Table 6.3 iControl Messages iControl Messages Rear Door Contact Fault, REAR DOOR CONTCT FLT Description: A faulty rear door contact (gate switch, door lock) has been detected. This is detected when the doors are in their fully open position and either the gate switch contact is closed or the doors appear to be locked.
Page 335 DC iControl Messages Table 6.3 iControl Messages iControl Messages Rear DPM Open-GS Closed, R DPM OPEN-GS CLOSED Description: The rear door position monitoring contact is open while the gate switch is closed. Car Reaction: None. Troubleshooting: Check the rear door position monitoring contact, gate switch and all related circuitry.
Page 336 Restricted Mode Key as described in document 42-IS-0144, Restricted Mode Instruction for iControl Users. Obtain the Restricted Mode Key by calling MCE’s Credit Department at (916) 463-9582. When calling, please provide the controller’s job number and car identifier.
Page 337 Description: Safety processor A has detected that both hoistway doors and car gate doors were open as the car moved away from the floor without a command from the iControl main processor (IMP board) to move. Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped. If applicable, the rope brake drops.
Page 338 Troubleshooting Table 6.3 iControl Messages iControl Messages Safety B Contract Overspeed Fault, SPB COS FAULT Description: The car has exceeded the Contract Overspeed setting. This fault may be bypassed on the Diag- nostics > Fault Bypass tab. Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped.
Page 339 Description: Safety processor B has detected that both hoistway doors and car gate doors were open as the car moved away from the floor without a command from the iControl main processor (IMP board) to move. Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped. If applicable, the rope brake drops.
Page 340 Troubleshooting Table 6.3 iControl Messages iControl Messages Safety Configuration Learn Fault, SFTY CONFIG LEARN FLT Description: Safety Processor A had a failure when storing configuration values to nonvolatile memory. Car Reaction: Car will not run until fault is cleared. Troubleshooting: 1.
Page 341 DC iControl Messages Table 6.3 iControl Messages iControl Messages Safety Inventory Creation Fault, SFTY INVTRY CREATION FLT Description: During a relearn of the Safety board inventory, the safety system had a problem creating a list of boards in non-volatile storage.
Page 342 Troubleshooting Table 6.3 iControl Messages iControl Messages SCR Contactor Fuse Fault, SCR CNTACTR FUSE FLT Description: Indicates that either the semiconductor fuse has blown or one or more of the 6 contacts within the two contactors has failed. DC controls only.
Page 343 Description: This fault indicates that either the ambient temperature inside the System 12 drive has exceeded 170 degrees F or there is a bad or failing SCR. iControl will attempt to bring the car to the nearest floor before shutting down. The fault clears when the temperature drops below tripping threshold. DC con- trols only.
Page 344 Troubleshooting Table 6.3 iControl Messages iControl Messages SCR Loop Over Current, SCR LOOP OVER CURRENT Description: DC loop current has grossly exceeded the reference value. DC controls only. Car Reaction: Emergency Stop. Troubleshooting: 1. Verify that the brake is completely lifting.
Page 345 DC iControl Messages Table 6.3 iControl Messages iControl Messages SCR Phase Lock Loop Warning Description: Phase lock loop circuit PLL LED is ON in SCR-LGA and that System 12 SCR Drive was unable to lock onto incoming line frequency. PLL LED is normally on for a few seconds during power up. Detected while the car is not moving.
Page 346 Troubleshooting Table 6.3 iControl Messages iControl Messages Sheave Brake Drop Fault, SHEAVE BRAKE DROP FLT Description: The sheave brake was disabled via Sheave Brake Enable output, but the Sheave Brake Monitor input was high. There is a five second delay before fault is generated.
Page 347 DC iControl Messages Table 6.3 iControl Messages iControl Messages Speed Limit, MF Forcing, SPD LMT MF FORCING Description: The system detected armature current without the armature current command. (The motor field is forced to help dynamic braking slow the car.) DC controls only.
Page 348 Troubleshooting Table 6.3 iControl Messages iControl Messages Tach Failure, TACH FAILURE Description: Difference between synthetic tach signal and external speed feedback signal exceeds tolerance. Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped. Cancel all calls. Troubleshooting: 1. Check velocity encoder and recalibrate tach failure and synthetic speed.
Page 349 DC iControl Messages Table 6.3 iControl Messages iControl Messages Up Direction Limit Open, UP DIR LIMIT OPEN Description: The up normal terminal direction switch is open Car Reaction: Immediate stop if moving. Further up direction movement is prevented. Troubleshooting: 1.
Page 350 Troubleshooting Table 6.3 iControl Messages iControl Messages Up Normal Terminal Switch ’n’ Level 2 Speed Fault, UP NTS’n’ L2 SPEED FLT (n = 1 to 5) Description: A Level 2 Overspeed fault has been detected at Up Normal Terminal switch 'n' (1 to 5). The car was traveling faster than defined by Level 2 overspeed settings (105% of sum of learned speed plus Over- speed 1 Margin percentage setting on Configuration >...
Page 351: Ibox Troubleshooting
• iBox removal and replacement iBox boot-up sequence Beginning with the April 09 release of iControl (IMP Boot ROM version 4.0.0) the iBox firm- ware includes visual feedback as the boot-up process progresses. The time at the beginning of each step is the approximate number of seconds from the beginning. The sequence is as follows: 1.
Page 352: Updating Ibox Firmware
Removal 1. Shut off power at the main disconnect. 2. Open the iControl cabinet. 3. Loosen the iBox cover retaining screws and remove the cover. 4. Unplug all connections to the body of the iBox. You can leave the connections to the rail- mounted circuit boards above and below the iBox connected.
Page 353: Ibox Installation
Troubleshooting iBox Installation 1. Verify that power is off at the main disconnect. 2. Open the iControl cabinet. 3. Remove the cover (bezel) from the new iBox. 4. Secure the new iBox in position between the rail-mounted circuit boards.
Page 354: Replacing Circuit Boards
Circuit Board Removal and Replacement Peripheral circuit boards in iControl and in the iLink cartop box are connected along a central, pluggable bus. The boards are mounted on slide-tracks so that, if you need to replace a board you can loosen the mounting bolts of the boards above or below it, slide them away, then loosen, slide, and remove the board you need to replace.
Page 355: Icontrol Circuit Board Quick References
DC iControl Circuit Board Quick References iControl Circuit Board Quick References This section contains information about iControl circuit boards and assemblies, including pho- tographs with informational call outs, input/outputs, indicators, jumpers, test points and other information pertinent to troubleshooting.
Page 356: Ice-Cop-2 Serial Car Operating Panel Board
Troubleshooting ICE-COP-2 Serial Car Operating Panel Board The ICE-COP-2 board interfaces between analog devices in the elevator car and serial devices in the elevator controller. Multiple ICE-COP-2 boards may be “daisy-chained” together to accom- modate high-rise installations. Board connection is described in detail on the prints for the specific job. Normal Operation During normal operation, I/O LEDs will be lighted when the associated I/O is active (dimmer when the output is active;...
Page 357 DC iControl Circuit Board Quick References Figure 6.2 ICE-COP-2 Serial Car Operating Panel Board 4-pin “universal” inputs may be used instead of screw terminals if desired. Test points,+5v OUT to additional ICE-COP boards (RJ45) Reset button 8-position DIP switch package...
Page 358: Ice-Ctp Cartop Processor
TP_LW test point CTS Cartop Safety Relay, part of the safety string +2.5V test point Load Weigher adjust, LW- test point Refer to iControl User Manual, Section 5 for adjustment instructions Fuse F1, 1A, 125VAC, MDQ Front door level sensor...
Page 359 DC iControl Circuit Board Quick References Table 6.6 ICE-CTP Board Connections Terminal Description Common DLSP Door Logic Supply (See job prints for source level) 120VAC Door Open Function output (active level =DLSP) Door Boost Function output (active level =DLSP)
Page 360 Troubleshooting Table 6.7 ICE-CTP Board Connections Terminal Description SHLD Shield: Common 26V output to load weigher Input from Load Weigher (analog voltage) Input from Load Weigher (analog voltage) DP2- Position input from iLand (balanced pair with DP2+) DP2+ Position input from iLand (balanced pair with DP2-) SHLD Shield: Common DP1-...
Page 361: Ice-Ctp Cartop Diagnostics
DC iControl Circuit Board Quick References ICE-CTP Cartop Diagnostics There are eight diagnostic LEDs on the CTP board inside the iLink enclosure. On power up or reset, these LEDs will light sequentially, first in one direction, then the other, after which they will briefly clear.
Page 362 Troubleshooting Normal Operation The normal operating condition is with all DIP switches OFF. This gives the normal operation display as follows: Table 6.9 Diagnostic Indicators (Normal Operation - All DIP Switches OFF) Description Represents message input from iBox to iLink. With proper communication, toggles approx- imately every 80mS.
Page 363 DC iControl Circuit Board Quick References Receive Serial Data There are five serial connections on the cartop - one to the iBox and up to four to Serial COP boards. Each connection can be monitored by setting the S1 DIP switches as described below: •...
Page 364: Ice-Eb Emergency Brake Board
Troubleshooting ICE-EB Emergency Brake Board The Emergency Brake board is used in iControl AC and DC elevator controllers to control a hoist motor-mounted emergency brake. The emergency brake is typically a separate friction brake mounted on an extended or secondary sheave.
Page 365: Ice-Fml Field Module Logic Board
ICE-FML Field Module Logic Board iField Modules are used to supply power to the brake on iControl AC and DC systems and to the motor field on iControl with DC drive. The iField Modules used for both purposes are the same, with the exception of the wiring to terminal J7 on the ICE-FMP, Field Module Power Board.
Page 366 Troubleshooting Table 6.11 IFIELD-MODULE Indicators on the ICE-FML Board Indicators Description +15 ISO OK LED indicator for isolated +15V power supply, measured with respect to isolated Ground, GND-ISO. Normally ON. Turns OFF when module loses +15 ISO voltage. F. BAD LED indicator for AC input on FMX1 and FMX2 terminals (on FMP board).
Page 367 DC iControl Circuit Board Quick References Table 6.13 IFIELD-MODULE Terminals on the ICE-FMP Board (Brake Module) Terminal Description FMO+ Field Module Output, positive, to brake coil. FMO- Field Module Output, negative, to brake coil. FMSI Field Module Safety Input: Jumpered to FMSO. FMSI and FMSO are always jump- ered together unless there is a requirement for a mechanical safety contact to break between the load and the field module.
Page 368: Ice-Ieq Earthquake Board
Troubleshooting ICE-IEQ Earthquake Board The Earthquake board provides an interface between motion sensing devices and the iControl elevator controller. Figure 6.7 ICE-IEQ Earthquake Board Testpoints On = EQ sensor tripped GND, +5V, Board Query LED +3.3V EQ Board Reset Fuse FCW...
Page 369 DC iControl Circuit Board Quick References Figure 6.8 Earthquake Board, Supporting Information 6-95...
Page 370: Ice-Imp Main Processor Board
Troubleshooting ICE-IMP Main Processor Board JP8, JP16 Test Points: TorqMax +1.5V Interface +2.5V +3.3 B DGND RS 232 PC Ethernet 3 = PC Programming port, factory use only Ethernet 2 = SYSTEM Ethernet 1 = LAN Internal CAN +5V to power supply shunt IMP Flash Internal CAN...
Page 371 JP11 CAN2 Termination JP12 IMP (iControl Main Processor): ON = enables iBox COMPUTER RESET button to reset this processor. *iBox Rev. 7 thru 10 have a wire from this jumper to the ICE-SAF board which allows resetting if any power supply voltages are out of tolerance.
Page 372: Ice-Irb-2 Relay Board
Troubleshooting ICE-IRB-2 Relay Board The Relay Board is an integral part of the iBox. Three system relays are mounted on the board. The SAFT relay is socketed (replaceable). There are also six fuses protecting the 110VDC and 120VAC iBox output buses that may be replaced. Electrically, the Relay Board is between the iBox processor and the motor and brake field modules inside the iPower Box.
Page 373 DC iControl Circuit Board Quick References Table 6.17 ICE-IRB Relay Board Signal (Left Edge) Signal (Right Edge) BD: Brake Driver relay indicator. When the BD relay on M1: Drive contactor coil connection. the Relay board is closed to pick the brake, this LED will light.
Page 374: Checking Tm Triac On Ice-Irb Board
Note These faults do not necessarily mean that the problem is with the TM Triac. It is recommended to first consult the iControl Messages table in the Troubleshooting section and follow the trou- bleshooting tips for the message(s) displayed. To check the TM triac: 1.
Page 375: Ice-Ird Rear Door Board
DC iControl Circuit Board Quick References ICE-IRD Rear Door Board The Rear Door board provides additional door zone inputs. Figure 6.10 ICE-IRD Rear Door Board Testpoints L to R: Safety Processor +5V, GND, +3.3V Query LEDs. Safety Processors A, and B Table 6.18 Rear Door Board Connections...
Page 376: Ice-Lcb Low Current Brake Board
Low Current Brake board connections clearly if it is used. Table 6.19 Low Current Brake Board Signals Signal B2 -, B1+ Brake voltage feedback signals to iControl Safety Board. BKX1, BKX2 110VAC (typical) inputs to Low Current Brake Board rectifier. BKD1...
Page 377: Ice-Miac (-24V) Multiple Input Board
DC iControl Circuit Board Quick References ICE-MIAC (-24V) Multiple Input Board The ICE-MIAC board is used in AC and DC iControls and in the iLink cartop interconnect as a general purpose input board suitable for industry-common 120VAC input signal levels. The ICE-MIAC-24V board can be used for 24V AC or DC inputs.
Page 378 Troubleshooting Table 6.20 ICE-MIAC Board Connections Connector Signal Connector Signal Orange Terminals 1: Common Inputs 1 - 32 Orange 120VAC = input active Orange Typical Input Circuit LST 670 LST 670 Table 6.21 ICE-MIAC-24V Board Connections Connector Signal Connector Signal Blue Terminals 1: Common Inputs 1 - 32...
Page 379: Ice-Mor Multiple Output Relay Board
ICE-MOR Multiple Output Relay Board The ICE-MOR board is a multi-purpose, relay-closure output board. ICE-MOR boards are used in iControl elevator controllers and in iLink cartop enclosures. Output Connections Connect outputs as shown in your job prints. Outputs may be configured (in specific groups) to provide either a path to ground or current to drive indicator lamps/LEDs.
Page 380 Troubleshooting Figure 6.13 ICE-MOR Board FMOR Fuse 6/10A, 250V, MDQ +5V Test point +24V Test point 18VAC Board Query LED 24V OK LED 1 bus On when iBox queries board LED lights when corresponding output relay is active. Active = Open Active = Closed Determined by iView settings according to user requirements.
Page 381: Ice-Rg Rope Gripper Board
DC iControl Circuit Board Quick References ICE-RG Rope Gripper Board The Rope Gripper board monitors and resets a rope gripper (emergency brake). The board is used in both AC and DC iControls. Figure 6.14 ICE-RG Rope Gripper Board Reset button...
Page 382: Ice-Saf Safety Board
Troubleshooting ICE-SAF Safety Board To I/O Boards Status LEDs JP5, JP6 Encoder/Tach Switch TACH ADJ. trimpot Power Input -15VDC +15VDC +5VDC Motor Field connections RS485 Fault LED Brake connections AC/DC Drive connections DCC Filter J3 AC Drive Encoder Output Drive Serial Port Test Points STP1 STP2...
Page 383 DC iControl Circuit Board Quick References Table 6.24 ICE-SAF Board Jumper Table Jumper Setting Description Encoder Voltage. A = +5V, B = +15V Pre-Torque Filter (AC / DC): AC setting is hard wired, adds filtering to the pre- torque output.
Page 384 Troubleshooting Table 6.26 iBox Field Connections on ICE-SAF Board Source Connection Signal Description iBox transmit, positive going serial communication stream from iBox to iLink. Connects to iLink ICE-CTP Board terminal RX+. TX+ and TX- comprise a differential communications pair. Please refer to “Installing iLink” on page 3-13.
Page 385 DC iControl Circuit Board Quick References Table 6.26 iBox Field Connections on ICE-SAF Board Source Connection Signal Description UNTD Up Normal Limit Direction switch input. 110 VDC = input on/switch closed. 0 VDC = input off/switch open. UNT5 Up Slowdown Limit switch #5 input. (see UNTD) UNT4 Up Slowdown Limit switch #4 input.
Page 386 Troubleshooting Table 6.26 iBox Field Connections on ICE-SAF Board Source Connection Signal Description Gate Switch input. The gate switch makes up when the elevator doors close. When the switch is made, there will be 110 VDC on this input. When the switch is open, there will be 0 VDC on this input.
Page 387: Ice-Sf-X Serial Fixtures Board
Circuit Board Quick References ICE-SF-x Serial Fixtures Board The Serial Fixtures board is used in iControl elevator controllers to communicate with serial- control audible and visual indicators, e.g., voice annunciators or character displays. The board provides two identical outputs — one for hall displays and one for car displays. The “x” in the part number refers to the fixture type: •...
Page 388: Sc-Hcda-Iso Serial Hall Call Driver Isolation Board
Troubleshooting SC-HCDA-ISO Serial Hall Call Driver Isolation Board The SC-HCDA-ISO Serial Hall Call Driver Isolation Board is used on iControl AC and DC Sim- plex and Swing car controllers. The isolation board is placed between the SC-HCDA Serial Hall Call Driver (usually mounted inside the iPower Box) and the Serial Hall Call Input on the right side of the iBox.
Page 389: Sc-Hcnt Serial Hall Call Node Board
DC iControl Circuit Board Quick References SC-HCNT Serial Hall Call Node Board In a typical installation, an SC-HCNT Serial Hall Call Node board is mounted in each hall call fixture enclosure. Please refer to “Hall Call Installation” on page 5-32.
Page 390: Sc-Ion: Serial Control I/O Board
Troubleshooting SC-ION: Serial Control I/O Board One or more SC-ION boards may be used in an iCentral group. The SC-ION board provides a communications interface between discrete signal or relay-oriented field equipment and the serial communications bus used for serial hall call and other serial messaging. Inputs and out- puts on the SC-ION board are assigned unique serial addresses at the factory according to cus- tomer requirements.
Page 391 DC iControl Circuit Board Quick References Figure 6.19 SC-ION Serial Control I/O Board COMP ON: On = Computer on Off = Computer resetting RST_OUT: Low when computer is in reset mode Inputs Board programming port: Outputs Factory use only.
Page 392: System 12 Scr Drive
Troubleshooting System 12 SCR Drive This section provides a quick reference to the indicators, test points and jumper settings found on the SCR-LGA Drive Logic board and explains how to replace various components in the Sys- tem 12 SCR Drive, including: •...
Page 393 A = iControl setting. JP17 A = iControl setting. Loss of power at the Emergency Power Input causes a signal to be sent to the drive which causes the drive to modify the PLL feedback gain so that the PLL circuit can tolerate frequency shift for faster response.
Page 394 Troubleshooting Figure 6.20 SCR-LGA Board Layout 6-120 Manual # 42-02-7223...
Page 395: Replacing Fuses
DC System 12 SCR Drive Replacing Fuses The 12-pulse drive has a total of 9 fuses. Of the 9, 6 are semiconductor fuses (FL1 - FL6, one on each input line terminal for a 6 phase transformer). These semiconductor fuses are located above the contactors, under the drive cover.
Page 396 Troubleshooting Semiconductor Fuses Replace semiconductor fuses as described here. Figure 6.21 Replacing the Semiconductor Fuses The semiconductor fuses (FL1 - FL6) are rated at 200 Amps, 500 Volts. Before removing or replacing a fuse, ensure that all power is OFF. The cover of the 12–Pulse SCR Drive must be removed to access the semiconductor fuses.
Page 397 DC System 12 SCR Drive 120VAC Fuses (FD1, FD2) Replace AC line fuses as described here. Figure 6.22 120VAC Fuses (FD1, FD2) FD1 protects the power supply and the trigger transformer. FD2 protects the two fans. Both fuses are 1 Amp, 250VAC Slow Blow. Do not use a fuse with a different rating. The fuses are located on the left side of the drive enclosure.
Page 398 Troubleshooting Commutation Fuse (FD3) Commutation fuse replacement is described here. Figure 6.23 Commutation Fuse (FD3) Fuse (FD3) protects the commutation circuit. The cover of the drive must be removed. FD3 is located on the top of the drive above the swing tray. The fuse is a KLKD type rated at 30 Amps DC at 600VAC.
Page 399: Replacing Contactors
DC System 12 SCR Drive Replacing Contactors The 12-Pulse Drive has two main contactors located at the bottom of the enclosure. The left con- tactor is used to terminate Delta phases (X1, X2, X3) from the 6 phase transformer. The right contactor is used to terminate Wye phases (Y1, Y2, Y3).
Page 400 Troubleshooting 2. Loosen the two screws on the right and left side of the auxiliary contactor and remove it by pulling out and away from the main contactor. 3. Install the new auxiliary contactor. Make sure that the auxiliary contactor pin is inserted into the body of the main contactor.
Page 401 DC System 12 SCR Drive Replacing the Contactors Refer to the following illustration. 1. Remove all semiconductor fuses attached to the contactor being replaced. 2. Mark and disconnect all necessary wires. 3. Loosen the four contactor mounting bolts. Remove the contactor.
Page 402: Replacing Scrs And Diodes
Troubleshooting Replacing SCRs and Diodes SCR devices are located on and near the drive heatsinks. There are 6 SCR devices (12 Pulse Bridge) on the heatsink located in the middle of the drive. Three SCR devices (Direction Bridge and Dynamic Braking) are on the top-most heatsink in the drive. Just below the top-most heat- sink is a combination SCR/Diode device and a dual Diode device.
Page 403 DC System 12 SCR Drive 1. Remove the semiconductor fuse attached to the SCR device being replaced. 2. Remove bus bars G and H. 3. Loosen and remove the screws in terminals 2 and 3 on SCR1 - SCR6. (The terminal number is on top near the left side of the SCR pack.)
Page 404 Troubleshooting Replacing Direction Bridge (SCR7, SCR8) and Dynamic Braking (SCR9) Ensure that all power is OFF at the main disconnect. Figure 6.27 SCR7, SCR8, SCR9 1. Remove the bolts on terminals 1, 2, and 3 of the SCR being replaced. Place the bus bars that connect to the SCR so that they will not obstruct removal and replacement.
Page 405 DC System 12 SCR Drive Commutation SCR/Diode and Dual Diode Device To gain access to the Com- mutation SCR/Diode and Dual Diode Device, the SCR–DS board must be partially removed. We suggest you leave the connections on the bottom of the board connected and remove only the mounting screws.
Page 406: Replacing Pc Boards
Troubleshooting Table 6.38 Replacement Parts for Commutation SCR/Diode and Dual Diode Device ITEM (DESCRIPTION) MCE PART # UNIT Thyristor Diode (95 Amp 1400V) 33-03-0018 Each Thermstrate 41-06-0030 Each SCR Mounting Plate 40-02-0084 Each Dual Diode Pack (105 Amp 1500V Diode/Diode) 33-03-0014 Each Mach.
Page 407 DC System 12 SCR Drive 1. Remove the two mounting screws from the SCR-LGD board. 2. Disconnect the ribbon cable from J10 on the SCR-LGA board and remove the SCR-LGD board. 3. Install the new SCR-LGD board and torque the mounting screws to 15-20 inch pounds.
Page 408 3. Install the new board and torque the mounting screws to 15-20 inch pounds. Please refer to “SCR-LGA Board Jumper Settings for use with iControl” on page 6-119 “SCR-LGA Board Layout” on page 120.. 4. Reinstall the board connectors (J1-J10 and the ground wire). Ensure that the bottom right corner mounting screw is torqued to 15-20 inch pounds.
Page 409 DC System 12 SCR Drive Replacing the SCR-SN Board Removing the SCR-SN board requires that a few wires be disconnected. Label the wires to ensure they can be reconnected correctly. The right angle copper brackets and the insulator on the SCR-SN board must be transferred to the new board.
Page 410 Troubleshooting emove the semiconductor fuses and the ribbon cable from J2 on the SCR-LGA board. 2. Disconnect the wires attached to terminals 2 and 3 on SCR1 through 6 in the drive. 3. Remove the three mounting screws on top of the SCR-SN board and remove the board. Transfer the angle brackets (35-30-0009) to the new board.
Page 411 DC System 12 SCR Drive Replacing the SCR-DS Board The SCR-DS board contains the SCR firing leads that attach to the SCR devices. Handle these wires with care. In some cases, the SCR-DS board does not require complete removal. Partial removal consists of removing all of the items stated below except the cathode and gate connectors on the bottom of the SCR-DS board, the 6 phase wires, and the A2 wire.
Page 412 Troubleshooting Replacing the SCR-CC H/L Board To gain access to the SCR-CC-H/L board, the SCR-DS board must be removed. Label the wires you disconnect so they can be reconnected correctly. The three studs (X1, A, AX) on the board should be torqued with care. Figure 6.33 Replacing the SCR-CC H/L Board 6-138 Manual # 42-02-7223...
Page 413 DC System 12 SCR Drive 1. Label and disconnect the wires on the studs (X1, A, AK) and J1 of the SCR-CC-H/L board. 2. Remove the mounting screws and the board. 3. Install the new SCR-CC board and torque the mounting screws to 15-20 inch pounds.
Page 414 Troubleshooting 6-140 Manual # 42-02-7223...
Page 415: About The Ibox Front Panel
iBox Front Panel Controls About the iBox Front Panel System status indicator LEDs and function control switches are on the iBox front panel. The front panel also provides: • LCD display and entry keypad (see page 7-3). • Access to iBox Ethernet Port addresses (see page 7-9).
Page 416 iBox Front Panel Controls The following illustration shows iBox front panel controls. Figure 7.1 iBox LCD Display and Keypad ENTER System Status Display COMPUTER SAFETY OK SAFETY A DRIVE ON DOORS LOCKED SAFETY B DOWN INSPECTION CARTOP IN GROUP FAULT RELEVEL SYS COMM System Control Switches...
Page 417: Lcd Display And Keypad
• View error messages and the system event log Typically, when you need to view or change parameters in an iControl, you connect to the iBox through the PC or LAN ethernet port and use the iView graphical user interface running on a Windows OS PC to easily access, view, or edit any desired parameter.
Page 418: Keypad Controls
iBox Front Panel Controls Keypad Controls Keypad controls include: • Display Contrast — adjusts the LCD display • Computer Reset — resets the iBox computers • Fault Reset — initializes the fault list • Softkeys — selects the associated topic across the bottom of the LCD display •...
Page 419: Parameter Entry
DC LCD Display and Keypad Parameter Entry To edit or view a parameter, you select a broad topic by pressing the Enter soft key, then select and view or edit a parameter. For example, to change or edit a Car-associated parameter.
Page 420: Editing A Controller Parameter
iBox Front Panel Controls Editing a Controller Parameter To edit a parameter: 1. Navigate to the desired screen. 2. Edit the parameter. 3. Save the edited parameter. The following illustration shows which parameter groups are accessible on the Car and Mgmt menu LCD screens.
Page 421 DC LCD Display and Keypad Table 7.1 Car Menu Parameters Car Menu Parameters Network Setup There are three Ethernet ports on the iBox. #1 is the Local Area Network connection used to connect Group and Elevator controllers to your Local Area Network.
Page 422 ID Number, ordered by time-of-occurrence. Additional data is also stored, e.g. Type, Date, Time, Acknowl- edgement Status, and Event (name) for each event. A listing of iBox Event Log ID Numbers and a cross-ref- erence to iControl Messages and descriptions can be found in Section 6 of this User Guide. Please refer to “Cross Reference: iBox Event Log ID Numbers to iControl Messages”...
Page 423: Setting Ibox Ethernet Port Addresses
DC Setting iBox Ethernet Port Addresses Setting iBox Ethernet Port Addresses The table below lists the factory default addresses TCP/IP addresses. The iBox 3 = PC port (PC direct) is set to 192.168.193.001 and should not be changed. Table 7.3 System, LAN, & 3=PC TCP/IP Addresses...
Page 424: Ip Address Verification/Setting
iBox Front Panel Controls IP Address Verification/Setting You should not need to change the factory-set IP information. If you are having problems con- necting to an iBox Ethernet port, verify that IP information is correct as described here. If you find an incorrectly set port, these instructions will help you correct it.
Page 425: System Status Display
DC System Status Display System Status Display iBox front panel LEDs and the LCD display both provide status information. LED Status Display The LEDs of the front panel display provide immediate controller status information: • Computer: Lights green when the controller microprocessor is running properly.
Page 426: Lcd Status Display
The second line of the display shows the mode Passenger of operation (Passenger in the example) displayed in rotation with any active status messages. Please refer to Ofpm “iControl Messages” on page 6-13 for description. 2:26:22AM 11/30/2003 Mgmt System Control Switches The front panel system control switches allow you direct access to system functions including: •...
Page 427: Safety Bypass Jumper And Fuses
DC Safety Bypass Jumper and Fuses • Hoistway Door Bypass: Switch used to bypass the hoistway door electric contacts (Bypass position). When set to Bypass, the car will run only on Inspection mode. The ability to set this bypass must be enabled at the factory and is only available if allowed by safety regula- tions in your area.
Page 428 iBox Front Panel Controls 7-14 Manual # 42-02-7223...
Page 429: About Iview
Using iView About iView iView is a graphical user interface running on a Windows computer. The computer may be con- nected directly to the iBox PC Ethernet port or, through a Local Area Network, to the iBox LAN ethernet port. Using iView, you can quickly and easily: •...
Page 430: How Iview Works
Using iView How iView Works iView software runs on any PC using the Windows 2000 or later operating system. iView com- municates with a controller through an Ethernet connection and loads operating parameters stored on the controller into iView screens. The iView user can view virtually any controller parameter and can edit/adjust any user-configurable parameter, then send changed parameters to the controller.
Page 431: Setting Up An Iview Pc
DC Setting Up an iView PC Setting Up an iView PC Important If you purchased your iView PC from MCE, iView was installed at the factory. In addition, all of the network assignments (connections) for your job have been created and stored on the iView PC.
Page 432: Setting The Iview Pc's Ip Address
LAN must have their own unique address. The address is called a TCP/IP number. The table below lists iControl default IP addresses. Your job prints provide specific instructions as to how all of your IP addresses are set.
Page 433 DC Setting Up an iView PC Table 8.1 System, LAN, & 3=PC TCP/IP Addresses Group IP, Primary System/Serial Group Car ID Car IP iView PC & Backup Hall Call Bus 1 - 4 System 192.168.192.201-202 1-20 192.168.192.001-020 192.168.192.211-214 192.168.191.201-202 1-20 192.168.191.001-020...
Page 434 Using iView 5. Click Properties to open the Local Area Connection Properties dialog. Sample screens are Windows XP operating system. 6. In the Local Area Connection Properties dialog, select Internet Protocol (TCP/IP). 7. Click Properties to open the Internet Protocol (TCP/IP) Properties dialog 8-6 Manual # 42-02-7223...
Page 435 DC Setting Up an iView PC 8. For a direct connection, set the IP Address to match the iBox EXCEPT FOR the last set of numbers. The #3 iBox port is defaulted to 192.168.193.1. Typically, you can set your PC’s IP address to 192.168.193.2...
Page 436: Creating A Direct Connection In Iview
Using iView Creating a Direct Connection in iView Once you have set your computer TCP/IP as described previously, you need to create a connec- tion in iView. 1. Double-click on the iView icon on your computer screen to launch iView. 2.
Page 437 DC Setting Up an iView PC 8. Enter a File name for this connection in the Save As dialog. When creating direct con- nections, it is a good practice to name them clearly so they are easy to distinguish (i.e., “CarA Direct”).
Page 438 Using iView Connecting to the iBox Once the connection is created and saved, you are ready to connect. 1. Click the Open Connection button 2. or click File on the menu bar, select Connection and click Open. The Open dialog appears. 3.
Page 439 DC Setting Up an iView PC 5. When iView is communicating with a controller, this symbol is displayed in the bottom left corner of the iView screen. 6. When iView is not communicating with a controller, this symbol is displayed in the bottom left corner of the iView screen.
Page 440: Lan Connections
Using iView LAN Connections In most installations, there will be at least one iView PC continuously connected to the Local Area Network on which the iBox controllers reside. LAN TCP/IP addresses and associated set- tings for any hubs, routers, or other equipment involved are resolved when network equipment is installed.
Page 441 DC Setting Up an iView PC 8. Enter a File name for this connection in the Save As dialog (the Connection automati- cally suggested). 9. The suggested (default) location for connections is the Connections folder (My Docu- ments > Motion Control Engineering > iView > Connections). You may choose another location using standard windows methods.
Page 442: Connecting To The Ibox
Using iView Connecting to the iBox Once the connection is created and saved, you are ready to connect. 1. Click the Open Connection button 2. or click File on the menu bar, select Connection and click Open. The Open dialog appears. 3.
Page 443: Editing An Existing Lan Connection
3. Click OK. Deleting an Existing LAN Connection You can delete an existing connection from the iControl Connections folder: 1. Select Edit on the File > Connection menu. 2. The Open dialog is displayed. Right-click on the connection you wish to delete.
Page 444: Working Online
Using iView Working Online Working Online means that you are connected to an iController and are viewing or adjusting its parameters. To work online, select Open from File > Connection menu and double click the desired connection in the Open dialog. When the connection is established, the Operational Status tab and Hoistway window are dis- played with the Controller’s connection name on the top left side of the title bar.
Page 445: Iview Menu Bar
DC Working Online iView Menu Bar Table 8.2 lists the description and location where the menu bar options are explained. Table 8.2 iView Menu Bar Options Menu Option Description File Connection Create a new direct connection (page 8-8) or LAN connection (page 8-12).
Page 446: Iview Button Bar
Using iView iView Button Bar Table 9.2 lists the locations where the functions of the buttons are explained. Open Connection System view Open Configuration File Controller view Refresh Save Configuration File Call Registration Table 8.3 Buttons and Dialogs Buttons / Dialogs Description Open Connection Displays the Open dialog...
Page 447: Viewing And Adjusting Settings
DC Working Online Viewing and Adjusting Settings To view and/or adjust settings, you first select the Configuration tab associated with those set- tings. There are two ways to select Configuration tabs: 1. Click the desired tab on the View > Configuration menu.
Page 448: Sending Adjustments To The Controller
Using iView Sending Adjustments to the Controller After making adjustments you will want to send the new parameter values to the controller. To send the new values: 1. Select Acquire from the Write privilege menu. 2. Press the “Yes” softkey on the iBox to grant the privilege request.
Page 449: Saving Current Parameters To A Configuration File
DC Working Online Saving Current Parameters to a Configuration File All of the iView settings associated with a controller can be saved in a configuration (.cfg) file. The .cfg extension identifies a file used to store information in a predetermined, fixed structure (XML).
Page 450: Loading Parameters From A Configuration File
Using iView Loading Parameters from a Configuration File When working online (connected to a controller), you may load (send) selected data from a pre- viously saved configuration (.cfg) file to the controller (after ensuring that it is safe to do so and setting the iBox Controller Stop switch appropriately).
Page 451: Working Offline
DC Working Offline Working Offline Working offline means that you are not connected to a controller but are working with a config- uration (.cfg) file. You must have previously created the configuration file by saving it while working on line with a controller.
Page 452: Accessing Online Help
• iView Windows and Tabs - Lists all of the iView windows and tabs and provides links to descriptions of the parameters on each tab. • Message Reference - An alphabetical listing of iControl status and error messages. Each listing includes a description, an indication of what action is taken, and troubleshooting tips.
Page 453: Iview Windows And Tabs
Then click the desired diagnostics tab. Controller - Setup Tabs The Controller - Setup tabs are used to perform the iControl automatic and semi-automatic setup procedures. The Setup tabs can be accessed by selecting Setup from the View menu. Then click the desired calibration tab.
Page 454 Using iView Specific contents will vary depending on the hardware installed at your site and on the revision level of your iView and iBox software. Always refer first to the online help available within iView. Online help contains the most detailed and current information about your iView soft- ware.
Page 455 DC iView Windows and Tabs Table 8.5 Controller - Configuration Tabs Sub-Tab Content Car Operation Elevator Recall Recall floor, call disposition, door operation, and override settings for car (continued) on recall operation (see page 9-65). Earthquake Counterweight displacement sensor enable/disable, and earthquake code...
Page 456 9-122). Configurable Determines during which modes of operation the Door Enable Output, outputs Automatic Closing Output and/or Hall Door Button Output are disabled. IBox IP information for iControl (see page 9-148). Configuration Load Weigher Load Weigher configuration and threshold settings (see page 9-149).
Page 457 Registration Registration button on the button bar (see page 9-182). Firmware Update Guides you through the process of updating iControl firmware. This control is accessed by selecting Firmware Update from the File menu (see page 8-25). Refresh Updates the information displayed on iView windows and tabs. This control is accessed by clicking the Refresh button on the button bar.
Page 458: Controller - Layouts
Using iView Controller - Layouts With iView, you can move and size tabs to suit the task to be performed. When you find a partic- ular arrangement to be useful, you can save it as a custom layout (View > Layouts > Save as). You can then display that layout at any time by selecting your custom lay0ut from the View >...
Page 459: System View Windows And Tabs
DC iView Windows and Tabs System View Windows and Tabs System - Configuration Tabs System parameter settings are displayed and may be changed on the System - Configuration tabs. The Configuration tabs may be accessed in one of two ways.
Page 460 Using iView Table 8.10 System - Configuration Tabs Sub-Tab Content Emergency Use to indicate cars connected to each generator and define how switch- Power ing to and from emergency power is handled (see page 10-39). System Building Floor definition and labeling. Car definition and labeling (see page 10-7).
Page 461: Pinning And Unpinning Windows
DC iView Windows and Tabs Table 8.12 System - Miscellaneous Dialogs/Controls Content Call Allows you to register car and hall calls. This control is accessed by clicking the Call Registration Registration button on the button bar (see page 10-85).
Page 462: Resizing Windows
Using iView • To temporarily bring the window into view again, place the mouse cursor over the button. The window slides into view and will remain in view if you click the window title bar or as long as the cursor remains on the button or window.
Page 463: Docking And Undocking Windows
DC iView Windows and Tabs Docking and Undocking Windows iView windows can be undocked from their assigned position and moved to another position on the screen. To undock and move a window: 1. Notice that the Diagnostics window is positioned at the bottom of the screen (connec- tion arrows at bottom left corner).
Page 464 Using iView To dock a window in a new location: 1. Notice that while moving an undocked window, docking controls appear near the center and at the top, bottom and sides of the screen. As you slide the cursor over the controls, a light blue highlight indicates the position to which the window will be moved.
Page 465 DC iView Windows and Tabs 2. An alternate method of moving a window is to right click the title bar of the window. In the drop down list that appears, select Dock to and click the desired location. In the example below, the Diagnostics window has been moved to the top of the screen.
Page 466: Printing Screens
6. Save the file if you want to keep a record of the screen on the PC hard drive. Setting System Date and Time The iControl system’s time and date can be set using the iView application connected to the Central Dispatcher (iCue PC), Local/Dispatcher or Simplex car controller. The dispatcher’s time and date are transferred to all local cars that are running (communicating) and all other cars as they power up.
Page 467: Editing Dynamic Displays
DC iView Windows and Tabs Editing Dynamic Displays The virtual oscilloscope display is editable. You may easily modify labels, displays, animation, and more to suit your immediate display needs. When a display is closed, then re-opened, it reverts to its default values.
Page 468 Using iView 2. Experiment with modifying the display to find the combinations that suit the signal types you are currently examining. The Edit menu is extensive: 3. Several different editors are available depending on where you click in the graphic dis- play.
Page 469: Updating Controller Firmware
MCE Technical Support. Failure to do so can result in cata- strophic failure of the iBox. Firmware Update allows you to install updated iControl operating software. It is likely that two firmware program files will be updated. They are: • Bootrom.mce, the iControl boot-up program.
Page 470 Using iView 6. Follow instructions 1 through 4 in the Firmware Update dialog and then click Continue. The Firmware Update dialog will change to: 7. Update the Bootrom first. Double click the (…) in the Bootrom row. 8. Use the Open dialog to navigate to the computer’s Desktop and double click the Bootrom.mce file.
Page 471: Upgrade Options
DC Updating Controller Firmware 14. Use the Open dialog to navigate to the computer’s Desktop and double click the vxworks.mce file. The IMP application file will load and the version will be indicated in the Upgrade version column. 15. Click Start upgrade. The upgrade progress will be indicated in the text window. When the upgrade is completed you will be instructed to close iView and press the iBox Com- puter Reset button.
Page 472: Ftp File Viewer
Using iView FTP File Viewer The FTP File Viewer is a very useful troubleshooting tool. It can be used to copy firmware files from an iBox to a PC, delete iBox firmware files or copy firmware files from a PC to an iBox. For example, the Controller’s Event Log file could be copied from the iBox to the iView PC and then sent via e-mail to MCE for evaluation.
Page 473 DC Updating Controller Firmware 3. Connect the FTP File Viewer utility to a controller: Select Connect from the File menu and click Open 4. or click Connect next to STEP 1: 5. The Open dialog appears. Click the desired connection.
Page 474 Using iView 8. Set the iBox INSPECTION, CONTROLLER STOP and WRITE ENABLE switches as shown. 9. The FTP Viewer window changes to: 8-46 Manual # 42-02-7223...
Page 475 DC Updating Controller Firmware 10. To copy a file from an iBox to a PC, select a file in the Controller FLASH or BBRAM list and then click Copy to PC. The default folder to which the files are copied is Documents and Settings\User’s name\My Documents\Motion Control Engineer-...
Page 476 Using iView To copy a file from a PC to an iBox, select the file in the Computer list box and then click Copy to iBox. Note If you attempt to copy the VXWORKS file to the iBox, the following Warning message appears: 8-48 Manual # 42-02-7223...
Page 477: Boot Parameter Recovery
DC Updating Controller Firmware Boot parameter recovery In very rare instances the iBox may refuse to bootup. This utility may be able to allow the iBox to recover from this state. Note: To use this tool, the iBox must have Boot Loader version 4.0 or greater.
Page 478: Bootrom Recovery Via Obd
Instructions for using the FTP File Viewer are in the April 2010 Release or later iControl User Guide. Boot - This option causes the boot process to continue. Press soft switch #4. 8-50 Manual # 42-02-7223...
Page 479: About This Section
iView - Controller View About this Section This section contains detailed information about: • Selecting Controller view: • Controller View Windows and tabs: A complete list of iView windows and tabs, and infor- mation about the parameters on each. Selecting Controller View iView is used to view and adjust the Controller and System parameters.
Page 480: Controller View Windows And Tabs
iView - Controller View Controller View Windows and Tabs The parameters displayed in the Controller view are related to the operation and control of the connected car. Table 9.1 lists the locations where the parameters and settings are explained. If you are viewing this as a .pdf file, click the page number link to jump to the description of the parameters on that tab.
Page 481: Hoistway Window
DC Controller View Windows and Tabs Hoistway window Mode of Operation Direction Current Car Position Destination floor Car Speed Load in Car Manual / automatic scrolling Down Rear Main Hall Call Floor Label Up Front Main Hall Call Floor Height...
Page 482: Mode Of Operation
iView - Controller View Mode of Operation The top line of the Hoistway pane shows the current car operation mode: • Attendant Service: Usually initiated by a key-operated switch inside the car to allow opera- tion by an in-car Attendant. On Attendant service, hall and car call buttons remain active. The elevator will respond to car calls as specified by the car call eligibility and card reader options.
Page 483 DC Controller View Windows and Tabs • Construction Inspection: Construction mode enabled (Configuration > Safety tab), allow- ing the car to be run on Inspection with a bare minimum of field wiring installed, and the car is operating on Inspection. The car can be moved using either cartop or machine room inspection switches.
Page 484 iView - Controller View • Passenger: The car is operating in normal passenger mode, responding to dispatching and parking instructions and to hall and car call demands. Car and door operation are deter- mined by settings on the Configuration > Car Operation > Passenger tab. Please refer to “Car Operation - Passenger Tab”...
Page 485: Operational Status Tab
DC Operational Status tab Operational Status tab The Operational Status tab is displayed, along with the Hoistway pane, when iView first con- nects to an iController. Speed • Commanded: Speed commanded by the control system • Actual: Actual car speed reported by the landing system encoder.
Page 486: Motion
iView - Controller View Motion • Cmd direction (Commanded direction): Indicates commanded direction of travel. • Actual direction: Indicates actual direction of travel. • Category: (Note: Insp = Inspection mode, all others = Automatic (Passenger) mode.) • AutoHalt: An emergency stop has been initiated. •...
Page 487: Door Lock
• All active fault messages are displayed in the Faults list box. A complete listing of fault messages is provided in Section 6. Please refer to “iControl Messages” on page 6-13. Car status • All active car status messages are displayed in the Car status list box. A complete listing of status messages is provided in Section 6.
Page 488: Diagnostics Tabs
iView - Controller View Diagnostics Tabs The following four Diagnostics tabs can be displayed one at a time by selecting each one from the Controller > Diagnostics menu or opened as a group by selecting Diagnostics from the Con- troller > Layouts menu. Four other diagnostic screens, Call Generator, Data Trap, Diagnostic Outputs and Virtual Oscil- loscope are displayed each in their own window.
Page 489: Diagnostics - Call Generator
DC Diagnostics Tabs Diagnostics - Call Generator The Call Generator can be used to diagnose problems or test the elevator. In addition, the Auto button generates a script that includes all possible source to destination car calls so that the pre- dictive gongs feature can learn the transit times.
Page 490: Diagnostics - Data Trap
iView - Controller View Diagnostics - Data Trap The data trap diagnostic tool allows you to record and analyze controller data including input and output states, internal flags and parameter values. When the trap is ON (Running), the con- troller samples data at specified intervals (Data sample time). The most recent 500 samples are retained in a buffer.
Page 491: Diagnostics - Diagnostic Flags
DC Diagnostics Tabs Diagnostics - Diagnostic Flags During an elevator run, a number of “events” occur in a particular sequence. Examining this sequence is useful in determining the status of the elevator. The Diagnostics flags provide a near real-time, graphical display of system diagnostic flags. LEDs indicating currently active flags are lighted.
Page 492: Diagnostics - Diagnostic Outputs
iView - Controller View Diagnostics - Diagnostic Outputs The Diagnostic Outputs window allows you to select from hundreds of system outputs and dis- play those outputs (up to sixteen at a time) on the screen for easy monitoring. To select outputs to monitor: •...
Page 493: Diagnostics - Event Log
The Event Log (Controller > Diagnostics > Event Log) provides a way to view controller events logged by iControl. This is an invaluable troubleshooting tool. A complete listing of iControl messages, a description and trouble shooting tips can be found in Section 6 and in the iView on- line help.
Page 494 iView - Controller View Event Properties To view greater detail about an event: • Double-click the event in the Event Log. The Event Properties dialog is displayed. • Click Help in the Event Properties dialog. The Troubleshooting Tips dialog is displayed 9-16 Manual # 42-02-7223...
Page 495 DC Diagnostics Tabs Event Filter The Event Filter controls which events will be displayed in iView. • Click the button on the Event Log tab. The checked events will be displayed. • Click to remove the check mark from events that you don’t want displayed.
Page 496: Diagnostics - Fault Bypass
iView - Controller View Diagnostics - Fault Bypass The Fault Bypasses allow you to temporarily bypass the normal system reaction to certain faults. This can be helpful when diagnosing system problems or operating the elevator under abnormal conditions. Bypasses can only be activated when not on normal (passenger) opera- tion.
Page 497 DC Diagnostics Tabs System status • Inspection - lights when the iBox INSPECTION switch is in the INSP position. • Test - lights when the iBox TEST switch is ON. • Fault bypass - lights when the iBox FAULT/FUNCTION BYPASS switch is ON.
Page 498: Diagnostics - Terminal Switches Status
iView - Controller View Diagnostics - Terminal Switches Status The Terminal Switches Status shows information about the speed and position of the car when each Normal Terminal Switch (U/DNT1 - U/DNT5) and Emergency Terminal Switch (U/DETS) opened. The parameters are divided into the following groups: •...
Page 499 DC Diagnostics Tabs Switch Data • Position (ft.) • Learned: Learned position of the car when this switch opened during the Learn opera- tion. • Lower limit: Variance below the learned switch position required to generate an Up or...
Page 500: Diagnostics - Virtual Oscilloscope
iView - Controller View Diagnostics - Virtual Oscilloscope The Virtual Oscilloscope allows you to display and track two signals over time simultaneously. The selected signal values are shown on the Test point 1 and 2 displays and output on the STP 1 and STP 2 physical test points on the iBox.
Page 501: Display Editing
DC Diagnostics Tabs Display Editing The virtual oscilloscope display is editable. You may easily modify labels, displays, animation, and more to suit your immediate display needs. When a display is closed, then re-opened, it reverts to its default values.
Page 502 iView - Controller View Scale One typical modification you might want to make is to the scale of a display. For example, if you wanted to change the scale of the Test point 2 vertical display (Y axis): 1. Right-click on the Test point 2 display scale and select edit. 2.
Page 503: Configuration Tabs
DC Configuration Tabs Configuration Tabs The Controller Configuration tabs are used to view and enter (change) iController parameter values. The Configuration tabs are accessed from the Controller View menu (Controller > Con- figuration) or you can display all of the configuration tabs by selecting Configuration from the Controller >...
Page 504: Brake - Control Tab - Voltage
iView - Controller View Brake - Control Tab - Voltage The Brake Control tab allows you to set brake operating voltage outputs. Please refer to “Brake Parameter Adjustments” on page 4-25. • Pick voltage: Enter the necessary brake Pick voltage (from the job prints) for the brake used on this job.
Page 505: Brake - Control Tab - Timers
DC Configuration - Brake Tab Brake - Control Tab - Timers The Brake > Control tab - Timer section allows you to set brake operation delays. • Pick delay: Delay between drive enable and brake voltage set to Pick.
Page 506: Brake - Configuration Tab
iView - Controller View Brake - Configuration Tab Caution The parameters on this tab are set automatically during brake calibration. Do not modify these parameters unless advised to do so by an MCE representative. • Voltage: The voltage output to the brake coil at various percentages of maximum voltage, measured during calibration (see Caution above).
Page 507: Configuration - Car Call Enable
DC Configuration - Car Call Enable Configuration - Car Call Enable Car Call Enable inputs are used with card reader or key switch security devices. The inputs are programmed using the Controller > Configuration > I/O Boards tab. When Elevator Security is on, the appropriate car call enable input must be activated in order for a call to be registered to the corresponding secured floor.
Page 508: Configuration - Car Operation
iView - Controller View Configuration - Car Operation The Configuration > Car Operation tab is used to view and adjust car door and device behavior under different operating modes. If you are viewing this as a PDF file, click the page number link to jump to the description of the parameters on that tab.
Page 509: Car Operation - Doors Tab
DC Configuration - Car Operation Car Operation - Doors tab The Doors tab allows you to set bypass timers for elevator safe edge and photo eye devices, set door protection timers, enable simplex operation, latch open or close door power, and disable door contact monitoring.
Page 510 iView - Controller View • Photo Eye: Check Front and/or Rear to indicate that the doors have a photo eye. If, after a period of time, an active photo eye input should be bypassed and the doors closed, enable bypass (check Bypass after timeout) and set the timer (Device timeout) to the desired time.
Page 511 DC Configuration - Car Operation • Door Close Fault Recovery: • Fault recovery attempts: (see Fault recovery timer). • Fault recovery timer: Timer starts when a Door Close Fault is detected. When the timer expires, the Door Close Fault is cleared to allow the doors to again attempt to close. If the doors still do not successfully close, another Door Close Fault is declared and the Fault recovery timer runs again.
Page 512 iView - Controller View Doors - Front / Rear • Door Closing Delay: Determines under what conditions (No delay, Always delay, Delay only if closed with hall door close button, Sabbath delay, DBD special access delay) and how much door closing delay shall be applied. These parameters may be set independently for front and rear doors.
Page 513: Car Operation - Devices Tab
DC Configuration - Car Operation Car Operation - Devices Tab The Devices tab allows you to configure the car arrival “announcement” devices, emergency alarm monitoring and serial fixture parameters. Arrival Fixtures • Hall mounted: Enable if hall-mounted arrival notification devices are used for this car.
Page 514 iView - Controller View • Car riding: Enable if car-riding arrival notification devices are used for this car. • Deactivate car lanterns when door dwell time has elapsed: Set this option to deactivate the car lanterns/gongs as soon as the door dwell time has expired and the doors start to close.
Page 515 DC Configuration - Car Operation S-Button Mode This parameter applies to both ETA and DBD dispatching modes. It specifies voice unit floor and direction announcements as follows: • Always announce floors and directions. • Announce floors and directions when the S-Button is triggered or when a special access call is answered.
Page 516 iView - Controller View Serial Fixtures If the installation uses CE Electronics serial fixtures, configure them on this tab. Node qualifier ASCII characters Message name Message number • Start Floor Arrival Announcement: Select the time at which you want the voice arrival announcement to occur —...
Page 517 DC Configuration - Car Operation To configure a serial message description: 1. Double click a serial message description to open the message definition dialog. 2. Check the fixture manufacturers documentation to determine the message number to message correlation. Enter the number in the Number entry box.
Page 518: Discrete Pi Outputs
iView - Controller View Discrete PI Outputs Use these parameters to configure the eight digital outputs of the Position Indicators Digital Outputs I and Position Indicator Digital Outputs II (See “Output Signal Groups” on page 9- 137.). Digital PI Outputs I and II The following parameters can be used to configure the Position Indicators Digital Outputs in groups I and II.
Page 519: Car Operation - Passenger Tab
DC Configuration - Car Operation Car Operation - Passenger Tab The Passenger tab is used to configure car and door behavior on Passenger (Norm) operation. General • Lobby floor: This setting determines which floor will use the lobby dwell timer. If the car is part of a group, the group dispatcher settings for primary and alternate lobby floors super- sede this selection.
Page 520 iView - Controller View Table 9.6 Nudging Operation Table Bypass Safe Edge Nudge Buzzer Door Operation After Nudging Option Option Option Output Output Device Timeout None Remain open None Remain open None Close at normal speed Buzzer only Remain open Buzzer only Remain open Buzzer only...
Page 521 DC Configuration - Car Operation • Reject hall calls when the in-car stop switch is activated: • If checked, the car is taken out of hall call service and hall calls are re-assigned when the in-car stop switch is pulled. If no other car is available, calls remain registered but unassigned.
Page 522: Passenger - Door Operation Tab
iView - Controller View • The Swing car uses normal passenger settings pertaining to door operation, door dwell timers, etc. • The Swing car uses elevator security settings that are stored on its own iBox. The security parameters must be programmed using the Swing car’s System View > Configuration > Security tab.
Page 523 DC Configuration - Car Operation Door Dwell Timers These timers set the door dwell times. • Reopen: The amount of time that the doors are to remain open (dwell) when a door reopening device or open button has been activated.
Page 524: Passenger - Door Operation - Front / Rear Tabs
iView - Controller View Passenger - Door operation - Front / Rear tabs The Configure > Car Operation > Passenger > Door operation > Front and Rear tabs determine door behavior for front or rear doors while on Passenger (Norm) operation. General •...
Page 525 DC Configuration - Car Operation Closing When “MCE Controlled” is checked, the following parameters determine what action will cause the doors to close. Mechanism: • Automatic: With the absence of door open intent, the doors shall close automatically upon dwell time expiration.
Page 526: Car Operation - Fire Service Tab
iView - Controller View Car Operation - Fire Service Tab Settings on this tab determine car behavior during Fire Service operation. Fire Service opera- tion typically proceeds in two stages. (Some codes allow the second stage to be initiated at any time by switch actuation.) The first stage, Recall, begins when a fire alarm, smoke detector, or fire recall switch is activated.
Page 527: Fire Service - Fire Code
DC Configuration - Car Operation Fire Service - Fire Code Displays the currently selected Fire Code and allows a different Fire Code to be selected. • All parameters are in default state: Indicates that all of the fire service parameters are set as specified by the selected code.
Page 528 iView - Controller View Fire Service Override • Security does not override fire service: This is the default state. • Override fire service/heat detectors when the following security configura- tions are active: This option is intended only for an installation where security is of prime importance and where fire service/heat detectors operation would compromise that security.
Page 529: Fire Code - Recall - General Tab
DC Configuration - Car Operation Fire Code - Recall - General Tab This tab allows you to set various fire code recall parameters. • Latch primary fire recall switch: • Never: The recall condition will clear automatically when the initiating condition clears.
Page 530 iView - Controller View • Latch secondary fire recall switch: • Never: The recall condition will clear automatically when the initiating condition clears. • Fire device OFF: In order to clear the recall condition, the secondary fire recall switch must be off. •...
Page 531 DC Configuration - Car Operation • Fire bypasses independent service: • No bypass: Fire recall will not bypass Independent Service. • Bypass immediately: Fire recall will immediately bypass Independent Service. • Bypass if running or after delay: Fire recall will bypass Independent Service after the delay set here expires or immediately if the car is running.
Page 532: Fire Code - Recall - Front / Rear Door Tabs
iView - Controller View Fire Code - Recall - Front / Rear Door Tabs Determine how the doors shall open and close during Fire Recall operation. Recall Not Completed - Recall Completed Determine how the doors shall open and close before recall has been completed and after recall has been completed. The parameters and descriptions are the same for both Recall Not Completed and Recall Completed and for both Front and Rear tabs.
Page 533 DC Configuration - Car Operation Closing When “MCE Controlled” is checked, the following parameters determine what action will cause the doors to close. Mechanism: • Automatic: With the absence of door open intent, the doors shall close automatically upon fire service activation.
Page 534: Fire Code - In-Car - General Tab
iView - Controller View Fire Code - In-Car - General Tab This tab allows you to set In-Car Firefighter parameters. • Fire Phase II Recall Conditions: One of the following conditions is required to initiate Fire Phase II recall when the Fire Phase II switch is deactivated. •...
Page 535 DC Configuration - Car Operation • Fire Phase II hold conditions: One of the following conditions is required to put the car on Fire Phase II Hold when the switch is turned to the Hold position. • Never: Never put the car on Fire Phase II Hold.
Page 536 iView - Controller View • During Fire Phase II Hold: • Keep doors open and disable door close button): Hold the car doors open during Fire Phase II Hold, bypassing the Door Close Button. • Cancel car calls: During Fire Phase II Hold, cancel all car calls and prevent registration of new car calls.
Page 537: Fire Code - In-Car - Front / Rear Tabs
DC Configuration - Car Operation Fire Code - In-Car - Front / Rear Tabs Determine how the doors shall open and close during Fire Service - In-Car operation. At Recall Floor - Away from Recall Floor Determine how the doors shall open and close when the car is at the recall floor and when the car is away from the recall floor.
Page 538 iView - Controller View Closing When “MCE Controlled” is checked, the following parameters determine what action will cause the doors to close. Mechanism: • Automatic: With the absence of door open intent, the doors shall close automatically upon dwell time expiration. •...
Page 539: Fire Code - In-Car Recall - Front / Rear Tabs
DC Configuration - Car Operation Fire Code - In-Car Recall - Front / Rear Tabs Determine how the doors shall open and close during Fire Service In-Car Recall operation. The parameters and descriptions are the same for both Front and Rear tabs.
Page 540 iView - Controller View Closing When “MCE controlled” is checked, the following parameters determine what action will cause the doors to close. Mechanism: • Automatic: With the absence of door open intent, the doors shall close automatically upon dwell time expiration. •...
Page 541: Car Operation - Independent Service Tab
DC Configuration - Car Operation Car Operation - Independent Service Tab This tab sets parameters associated with Independent and Attendant Service operation. General • Open front doors: If the doors are closed when the car is placed on Independent Service, the front doors shall be opened.
Page 542 iView - Controller View Opening When “MCE controlled” is checked, the following parameters determine what action will cause the doors to open when the car arrives at a floor. Mechanism: • Automatic: With the presence of door open intent, doors shall open automatically upon arrival at the floor.
Page 543: Car Operation - Elevator Recall Tab
DC Configuration - Car Operation Car Operation - Elevator Recall Tab Elevator Recall switch parameters determine how the car will respond during Elevator Recall operation (when the Elevator Recall Switch is activated). General • Recall floor: Specifies the floor to which the elevator is recalled.
Page 544 iView - Controller View • Car call disposition: Determines how existing car calls are handled when the Elevator Recall Switch is activated. • Service existing car calls: All previously registered car calls remain registered and the elevator is allowed to answer the car calls. •...
Page 545 DC Configuration - Car Operation Door Operation Rear Determines how the elevator rear doors shall operate once the elevator has arrived at the recall floor (after all car calls have been answered). • Keep closed: The rear doors shall remain closed.
Page 546: Car Operation - Earthquake Tab
iView - Controller View Car Operation - Earthquake Tab Allows selection of operating parameters during earthquake operation. Please refer to “Install- ing the Earthquake Sensor” on page 3-21 for additional information. Earthquake Code Select the earthquake code and version/year being used. Caution Changing earthquake parameter settings may cause you to be out of compliance with the selected code and may require a variance.
Page 547 DC Configuration - Car Operation • Earthquake run mode: Specifies when the elevator should be allowed to run while under Earthquake mode of operation. The elevator is allowed to run at a reduced speed (not to exceed 150 fpm) as long as the counterweight has not been displaced from its guide rails.
Page 548: Car Operation - Ems Tab
iView - Controller View Car Operation - EMS Tab Allows selection of operating parameters during Emergency Medical Service operation. General • Medical emergency: Check to indicate that EMS Switch 1 (or 2) is a true medical service. • Recall Floor: Determines the recall floor for EMS service. •...
Page 549 DC Configuration - Car Operation EMS Switch ‘n’ - Front / Rear Tabs The EMS - Front and Rear parameters deter- mine how the front and rear doors will operate during EMS Operation. The parameters and descriptions are the same for both Switch 1 and 2 and for both Front and Rear tabs.
Page 550 iView - Controller View In-car Opening When “MCE controlled” is checked, the following parameters deter- mine what action will cause the doors to open when the car arrives at a floor. Mechanism: • Automatic: With the presence of door open intent, doors shall open automatically upon arrival at the floor.
Page 551 DC Configuration - Car Operation In-car Closing When “MCE controlled” is checked, the following parameters determine what action will cause the doors to close. Mechanism: • Automatic: With the presence of door open intent, doors shall open automatically upon arrival at the floor.
Page 552: Car Operation - Emergency Power Tab
iView - Controller View Car Operation - Emergency Power Tab Determines the car reaction to loss of commercial power. General • Emergency power type: • Group/Simplex: Select this option for a simplex or for a car that is part of a group that controls the car during emergency power generator operation.
Page 553 DC Configuration - Car Operation • Wait for doors open to manually deselect a firefighter’s car: If checked, the controller will wait for doors to be fully open before manually deselecting a fire phase II car when the EP selection switches change.
Page 554 iView - Controller View • Front door operation after recall: After Emergency Power Recall is completed, the doors shall open as follows: • Open doors (and leave them open): Open the doors and leave them open. • Open doors for ‘xx’ sec: Open the doors for the time designated and then close them. •...
Page 555: Car Operation - Cfss Tab
DC Configuration - Car Operation Car Operation - CFSS Tab The CFSS (Commandeer For Special Service) tabs allow you to configure two “commandeer” modes. When active, these modes allow the elevator to be operated independently as configured for the commandeer mode selected.
Page 556 iView - Controller View General • Medical emergency: Check to indicate that CFSS Mode 1 (or 2) is a true medical service. Recall When a CFSS mode is activated, the affected car is recalled to the activation floor according to the behavior defined by these settings. •...
Page 557 DC Configuration - Car Operation • Bypass attendant service after “nnn” sec. Determines the delay from when a car is assigned a CFSS call to when Attendant Service is bypassed and the car begins CFSS mode. • Bypass stop switch when car on CFSS recall: Enable if activation of the in-car Stop switch should be ignored when the car is on commandeered operation.
Page 558: Car Operation - Flood Operation Tab
iView - Controller View • Cancel car calls if doors are not fully closed: If enabled, during in-car CFSS operation, if the doors are not fully closed, new car calls may not be registered and existing car calls will be canceled. •...
Page 559 DC Configuration - Car Operation Flood Operation Shall Override Depending upon code requirements, flood opera- tion interaction with other operating modes is user selectable. For the mode(s) of operation selected, where the requirements of Flood operation are not in agreement with those of the selected mode, the requirements of Flood operation will take precedence.
Page 560: Car Operation - Attendant Service Tab
iView - Controller View Car Operation - Attendant Service Tab Attendant Service allows a car to be diverted from passenger operation for use by an attendant. General These parameters specify which doors to open if both doors are closed when the car is placed on Attendant operation.
Page 561: Car Operation - Auto Stop Tab
DC Configuration - Car Operation Car Operation - Auto Stop Tab If enabled and activated, Auto Stop will cause a car to stop at a selected floor and cycle its doors for observation before continuing on to its destination. The controls become enabled when “Enable”...
Page 562 iView - Controller View • Door Dwell • Dwell time: The time, in seconds, that the door(s) will remain open before re-closing. • PHE cancels dwell timer: Allows photo eye detector activation to cancel remaining dwell time. • Car call button cancels dwell timer: Allows pressing a car call button to cancel remain- ing dwell time.
Page 563: Car Operation - Sabbath Tab
DC Configuration - Car Operation Car Operation - Sabbath Tab These parameters determine how the car performs when on Sabbath operation. Sabbath opera- tion must be Enabled via the “Enable Sabbath operation” parameter, and then Activated/Deac- tivated via a key switch-input, timer or software command from iMonitor or iView (Activate/ Deactivate button on this tab).
Page 564 iView - Controller View • Disable car call button indicators: The car call buttons will not illuminate in response to automatically generated Sabbath operation calls or call button activation. • Disable position indicators: During Sabbath operation the position and direction indica- tors shall be disabled (except for CE Electronics displays).
Page 565 DC Configuration - Car Operation Arrival lanterns During Sabbath operation the arrival lanterns shall operate as follows: • Enable: Arrival lanterns are enabled. • Disable: Arrival lanterns are disabled. • Activate both up and down: (not used). Status • Sabbath service ON: LED lights green when Sabbath operation is On.
Page 566: Car Operation - Shuttle Service
iView - Controller View Car Operation - Shuttle Service The Shuttle service option allows the car to be used to provide express service for a subset of the building’s floors. Shuttle service is available only during Passenger mode and is turned On/Off via a key-switch/input or software command (Activate/Deactivate button).
Page 567 DC Configuration - Car Operation Status • Shuttle service ON: LED is lighted when Shuttle service is On. • Activate / Deactivate button: Software command used to turn Shuttle service On or Off. Shuttle Floors and Car Call Disposition •...
Page 568: Car Operation - Heat Detectors
iView - Controller View Car Operation - Heat Detectors This screen contains parameters that determine how the car will behave when one or more of the heat detectors are activated. Heat detectors can be installed in the machine room, in the hoistway, and/or on individual floors in the building.
Page 569: Car Operation - Jail Operation
Configuration - Car Operation Car Operation - Jail Operation Jail Operation provides special supervision and control of elevator use. iControl has configura- tion parameters that allows a high degree of customization to accommodate operational differ- ences from one installation to another.
Page 570: Jail Operation - Master Mode - Front / Rear Tabs
iView - Controller View • Overrides: • Fire service overrides jail operation: If checked, Fire service will override jail opera- tion. • Independent service overrides jail operation: If checked: Independent service will override jail operation. Jail Operation - Master mode - Front / Rear tabs The Configure >...
Page 571: Jail Operation - Enable Automatic Mode
DC Configuration - Car Operation Closing When “MCE Controlled” is checked, the following parameters determine what action will cause the doors to close. Mechanism: • Automatic: With the absence of door open intent, the doors shall close automatically upon dwell time expiration.
Page 572: Jail Operation - Secure Mode
iView - Controller View Jail Operation - Secure mode The Configure > Car Operation > Jail operation > Secure tab allows configuration of the Jail operation - Secure mode parameters. The default settings for Jail - Secure mode allow calls to be registered using the main/Aux COP and hall stations.
Page 573: Configuration - Destination Based Dispatching
DC Configuration - Destination Based Dispatching Configuration - Destination Based Dispatching ETA and DBD dispatching are available. ETA (Estimated Time of Arrival) dispatching is designed to minimize average hall call waiting times. When a new hall or car call is registered, all hall calls are evaluated to determine the optimum car assignment to minimize waiting time.
Page 574 iView - Controller View General Enable destination based dispatching: Enable to activate parameters unique to destination based dispatching operation. Door Operation Door operation control during destination dispatching. • Nudge door for special access calls: When checked, the doors close at reduced speed and torque for special access passengers entering or exiting the elevator.
Page 575: Destination Based Dispatching - Fixtures
DC Configuration - Destination Based Dispatching Destination Based Dispatching - Fixtures The Controller > Configuration > Destination Based Dispatching > Fixtures tab determines how the car and hall fixtures operate during Destination Based Dispatching operation. 9-97...
Page 576 iView - Controller View General • Car assignment tone: Tone used to signal that the car is assigned a special access call. • Tone delay: Delay between car assignment and tone broadcast. • Tone repeats: Number of times the car assignment tone will repeat. •...
Page 577: Configuration - Drive
DC Configuration - Drive Configuration - Drive The Drive Configuration tab allows you to set and view user adjustable drive parameters. Tabs are selectable for parameters including: • General: Drive type, speed reference, system values, pre-start sequence (see page 9-100).
Page 578: Drive - General Tab
iView - Controller View Drive - General Tab Options General drive setup: • Drive type: Select the drive used in this controller. Note: Depending on the Drive type selected, some drive parameters will be grayed out (not available for adjustment). •...
Page 579 DC Configuration - Drive Speed Reference More detailed settings related to the speed reference mechanism. Please refer to “Calibrating Actual Car Speed (System 12 SCR Drive)” on page 2-62. • Reference type: Tachometer, Encoder, Internal or Serial. • Resolution: This parameter affects elevator speed only for an encoder configuration.
Page 580: Drive - Safety Tab
iView - Controller View Drive - Safety Tab Note: Depending on the Drive type selected on the Drive > General tab, some drive parameters will be grayed out (not available for adjustment). Speed Reference • Following error: Adjusts amount of error permitted between voltage from Tach/Encoder and pattern voltage.
Page 581 DC Configuration - Drive • Synthetic armature voltage low-pass frequency: In conjunction with Synthetic Armature Current Low-pass Frequency, creates a synthetic speed signal independent of the Tach. Increase to increase armature voltage to the synthetic speed signal. • Synthetic armature current low-pass frequency: Compensates for loop circuit loss in creat- ing the synthetic speed signal from the armature current.
Page 582: Drive - Control Tab
iView - Controller View Drive - Control Tab The Control tab allows you to set drive gain parameters (not applicable to Quattro DC Drive). PID Standard gain controls are always active. Remaining PID controls are enabled or disabled by the Options choices of the same name. Optional gains change drive gain settings during cer- tain operations (i.e., starting or releveling) and may not be needed in most applications.
Page 583 DC Configuration - Drive Armature Current Test Procedure: Among other things, the armature current test feature provides a means to troubleshoot the current command signal path and SCR drive cur- rent producing capability. During the test, up to 300% of rated current can be commanded to the drive.
Page 584 iView - Controller View PID - Start (normal) Enabled/Disabled by the Start Gain (normal) Options selection. These parameters are used to control rollback. • Proportional: If there is no rollback, set to equal Standard Proportional. If there is roll- back, set to a greater value than Standard Proportional. Start Proportional Error gradually decreases to Standard Proportional Error over the time period determined by the Transi- tion Time setting below.
Page 585 DC Configuration - Drive PID - Start (relevel) Enabled/Disabled by the Start Gain (relevel) Options selection. Used for gearless machines with problems releveling into the floor to apply higher gains during releveling. Please refer to “Motor Control Adjustments (System 12 SCR Drive)” on page 4-24.
Page 586: Drive - Filters Tab
iView - Controller View Drive - Filters Tab System filters are used to smooth oscillation or resonance in a signal. Note: Depending on the Drive type selected on the Drive > General tab, some drive parameters will be grayed out (not available for adjustment).
Page 587 DC Configuration - Drive System Speed loop filtering. • Raw pattern frequency: Applies smoothing to the raw pattern frequency. Higher settings provide better response but may result in uneven (bumpy) acceleration/deceleration. • Flare pattern frequency: Applies smoothing to the flare pattern frequency. Higher settings provide better response but may result in uneven (bumpy) acceleration/deceleration.
Page 588 iView - Controller View Notch Filter Enables the current notch filter for the System 12 SCR drive. When enabled, Process Notch Frequency, Quality, and Depth parameters are active, allowing a specific, calcu- lated frequency (range) to be blocked. It is important to be certain that the oscillation is in fact mechanically induced into the speed feedback signal and not a result of improperly adjusted system gains or dampening.
Page 589 DC Configuration - Drive Notch Settings When setting the notch filter, you can determine the “center” frequency of the oscillation using an oscilloscope. This frequency is what you enter as the Process Notch Frequency. The other two settings (Bandwidth and Depth) are more subjective and you will need to experiment to find the best setting.
Page 590: Drive - Dampening Tab
iView - Controller View Drive - Dampening Tab Dampening controls provide additional adjustment to smooth car operation by causing resis- tance to rapid change in current and/or voltage levels (not applicable to Quattro DC Drive). 9-112 Manual # 42-02-7223...
