- Page 1 Motion Control Engineering, Inc. 11380 White Rock Road Rancho Cordova, CA 95742 voice 916 463 9200 fax 916 463 9201 www.mceinc.com User Guide, Universal Serial Network Manual # 42-02-S028, Rev A1, December 2008...
-
Page 2: Limited Warranty
Limited Warranty Motion Control Engineering (manufacturer) warrants its products for a period of 15 months from the date of shipment from its factory to be free from defects in workmanship and materials. Any defect appearing more than 15 months from the date of shipment from the factory shall be deemed to be due to ordinary wear and tear. -
Page 3: End User License Agreement
End User License Agreement This End User License Agreement (“Agreement”) grants you the right to use the software con- tained in this product (the “Software”) subject to the following restrictions: You may not: (i) copy the Software, except for archive purposes consistent with your standard archive procedures; (ii) transfer the Software to a third party apart from the entire product;... -
Page 4: Important Precautions And Useful Information
Important Precautions and Useful Information This preface contains information that will help you understand and safely maintain MCE equipment. We strongly recommend you review this preface and read this manual before installing, adjusting, or maintaining Motion Control Engineering equipment. This preface dis- cusses: •... -
Page 5: Table Of Contents
Motion 3000ES Installation ........ - Page 6 Manual # 42-02-S028, 12/30/08...
-
Page 7: In This Manual
In This Manual This manual describes installing and setting up the MCE Universal Serial Network product. The USN is used to allow equipment without appropriate networking capabilities to communicate with state-of-the-art, MCE software applications including iMonitor, iReport, and BMS-Link. • Installation •... -
Page 8: Usn Installation
USN-BASE Assembly Power transformer - 6-feet power leads are provided but are not connected to the transformer. Cut leads to length required and connect to transformer per local requirements. 2 Manual # 42-02-S028 A1 CAN 2 AC1/AC2 PCA JP3 M2C Assembly... -
Page 9: Mounting The Board Assemblies
(For a duplex, mount an M2C assembly in each controller enclosure but just one USN-BASE assembly in the enclosure of your choice.) Motion 3000ES Installation For Motion 3000ES, only the USN-BASE assembly is required. Special hinged stand-offs will be provided to mount the USN-BASE (HC-MPU) board assembly. Mounting the Board Assemblies 1. -
Page 10: Configuration
5. Press N to go to save menu. Press S to save. 6. After the device type has changed, place the F7 switch down. 7. Reset the USN board by pressing the RSTA button. 8. After the device reboots, confirm new device type is selected. 4 Manual # 42-02-S028 A1... -
Page 11: Escalator Only
Escalator Only If you are not configuring an escalator, proceed to IP Setup. An escalator connection has additional parameters that need to be configured. Please note: each escalator must have its own unique lift number. 1. Place switch F7 in the up position. Using the keypad as described earlier, set and save: •... -
Page 12: Communication Connections
MCE Universal Serial Network Communication Connections Connections are described for IMC, PTC/PHC, and Motion 3000ES. 1. Connect the external Ethernet cable to Ethernet Port A on the USN-BASE assembly. 2. Connect the supplied C-RJ11/DB9M cable from a con- troller MC-RS (serial board) COM port to RS232 Port B (J7) on the USN-BASE assembly. -
Page 13: Ptc/Phc
PTC/PHC 1. Connect the external Ethernet cable to Ethernet Port A on the USN-BASE assembly. 2. The boards in the controller are connected along a ribbon cable bus. Connect the M2C assembly’s “From PCA” (JP3) to the last controller board on the bus using supplied rib- bon cable. -
Page 14: Motion 3000Es
• Connect CAN H to J12 TB. • Connect CAN L to J12 TA. • The SHLD is only connected on the HC-MPU (USN) side. 2. Press RSTA to reset the USN board so that it will read its new connections. 8 Manual # 42-02-S028 A1... -
Page 15: Mc Usn Information
MC USN Information This section describes the features of the USN device. Jumper Settings These jumper settings apply to the Rev X3-0 version of the MPU-M board. • JP1 = A (5V) • JP2 = Off • JP3 = ON •... -
Page 16: Lcd And Keypad
If the display never changes from this message, verify that the SW1 switch is in the down (ETHERNET PORT A) position. After approximately four seconds it should display: Or, WAITING FOR ESC COMMUNICATION for escalators, with a progress bar to indicate the initial data request. 10 Manual # 42-02-S028 A1... -
Page 17: Troubleshooting
Once the USN has connected to the device it will display the following message: This indicates that the USN board has successfully established connectivity with the device. If the following message is displayed: The USN board is not receiving data from the device. Troubleshooting •... -
Page 18: Configuration Menus
• Refresh Xport: This option causes the ethernet interface to refresh all saved parameters. Press the S key to activate. • TFTP Status: Press the S key to enable the embedded TFTP service. This is used to upgrade the Xport ethernet interface using the device installer software. 12 Manual # 42-02-S028 A1... -
Page 19: Security Password Default For Imc Connections
Security Password Default for IMC Connections If the USN is connected to an IMC controller with the CRT Security feature enabled, the USN will allow iMonitor software to configure security parameters. In order to configure security parameters, a user must log into the controller using a password. This password is stored on the USN board. - Page 20 MCE Universal Serial Network 14 Manual # 42-02-S028 A1...
