FR24 shown
MODEL NUMBERS
LENGTH (mm)
INTERIOR CU. FT. (m
)
3
PLATE CAPACITY †
GLASS CAPACITY (w/ 2 optional shelves)
WITH OPTIONAL THIRD SHELF
CONDENSING UNIT H.P.
AMPS
SHIPPING WEIGHT Lbs. (kg.)
INTERIOR
EXTERIOR
DOORS (Sliding)
ELECTRICAL
PLUMBING
INSULATION
TEMPERATURE RANGE
REFRIGERATION
VENTILATION
DEFROST SYSTEM
OPTIONAL ACCESSORIES
Capacity calculations based on use of 3" dia. glass and 9 1/2" dia. x 1/2" thick plate.
†
Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice.
Printed in USA
FR36SS shown
FR24
24" (610)
3.75 (0.10)
135 Plates
90 Glasses
N/A
1/3
5.8
190 (86)
All models have stainless steel walls and floor.
Choice of black, stainless steel and all stainless.
Black Option: Front and ends are black vinyl coated steel, back and bottom are galvanized.
Stainless Steel Option: Front and ends are stainless steel, back and bottom are galvanized.
All Stainless Option: Front, ends, back and bottom are all stainless steel.
Stainless steel top and bottom pans. Die cast handles.
115V, 60Hz, 1 Phase. Furnished with 6 foot rubber plug-in cord (115V model only). Also available in 230V, 50Hz, 1 Phase AC.
Carries
marking of conformity.
None required. Moisture drains to self-evaporating pan in machinery compartment.
2 inch foamed-in-place polyurethane insulation.
Adjustable from -10ºF to +10ºF.
R134a expansion valve system with hermetric condensing unit. Pulls out for service and cleaning.
2' model is front vented, all other models require 2" clearance from wall on either left end or back of cabinet for proper air flow.
Solid-state, push-button defrost system, manually initiated at end of each day, automatically terminates after six hours.
Evaporator automatically defrosts every 4 hours for approximately 20 minutes (time/temperature terminated).
• Additional set of nesting shelves w/brackets
• Set of 4 adjustable legs
Glass Frosters Installation & Operation Manual
JOB
AREA
ITEM NO.
MODEL NO.
FR24 SERIES
FR36 SERIES
FR48 SERIES
FR60 SERIES
FR36
FR48
36" (915)
48" (1219)
7.83 (0.22)
11.68 (0.33)
215 Plates
300 Plates
142 Glasses
214 Glasses
172 Glasses
273 Glasses
1/3
1/3
6.8
6.2
245 (111)
265 (120)
• Set of 4 casters w/ brakes
• 2' , 3' , 4' and 5' Bottle rail (field installed)
2
C
US
FR60
60" (1524)
15.53 (0.44)
400 Plates
286 Glasses
363 Glasses
1/3
7.1
300 (136)
• Interior light
• Roller basket shelving
