Camera & Software Installation
1.
Install the imaging software on the computer:
• To install the KODAK Dental Imaging Software,
• U .S. users see Kodak Digital Imaging System
Installation Guide (CS3000).
• U sers outside of U.S. see the KODAK Dental
Imaging Software Installation Guide (9H2290).
• T o install imaging software using TWAIN interface,
see your imaging software user guide.
2. I nsert the Intraoral Camera Installation Wizard DVD
and follow the on-screen instruction.
When you are prompted with following pop-up, click
Continue Anyway.
General Tips
• R eview the User Guide for more detailed information on
the camera and software features and functions.
• I nstall the camera holder (instructions in the User
Guide).
Refer to the User Guide on the DVD for more detailed information on camera and software functions and features
• S leep mode: camera automatically goes into sleep mode
when inserted into the camera holder or left idle for 1.5
minutes. To use it again, pick it up or press the Capture
button.
• A utomatic power down: Camera automatically powers
off when idle for an hour.
•
Preference button: Accesses the preferences
dialog box.
Camera Overview
6
7
1
2
3
4
5
1.
Capture button
2. Review button (backward)
3. Review button (forward)
4. Power button (LED indicator)
5.
Cable connection
6.
Camera Lens
7.
Push-pull connector
8. USB connector
9.
Camera holder
Preference Settings
On the Acquisition interface, click
and software options.
8
9
to set the camera
Use
General
Preference tool to:
• E nable/Disable audio
notifications
• A djust brightness and
contrast settings.
• C reate a log file for
faster service response
