Summary of Contents for Lami Corporation Lotus-14LK-H
-
Page 2: Table Of Contents
Preface Thank you very much for purchasing our 【 】. This Instruction Manual (booklet) includes details for safe use of this product. Please read this booklet thoroughly and correctly use the machine. Also, store this booklet properly for immediate use when necessary while using the product. Table of contents ■... -
Page 3: Precautions Before Use P
Precautions before Use Meaning of symbols This document classified and explains hazards and damages created when the displayed symbols are neglected and the product is used improperly, to prevent danger on customers or others and property damage in advance. When this sign is neglected and the product is handled improperly, there is a Warning concern for serious accident on human beings. -
Page 4: Places Appropriate For Installation
Places appropriate for installation Install this product in the following places. Horizontal and stable places Slanted or unstable use can have bad impact such as supply of paper. Also, there is a concern for an unexpected accident. Places where exclusive power outlet can be secured Do not use this product with power sources other than power with rated voltage regulated in this Manual. -
Page 5: Precautions For Handling
Precautions for handling Warning Do not use in abnormal state such as smoke or strange odor and sound. They are causes of electric shock and fire. Immediately turn the power switch off and remove power plug from the outlet before contacting the seller or our company. Do not repair the product on your own as it is dangerous. -
Page 6: Precautions About Power
Precautions about power Warning Power plug must be removed from the outlet when the product is not used for long time. Regularly remove power plug from the outlet to clean the root and gap of electrode. If power plug is left as inserted in the outlet for long time, dusts can adhere to electrode of power plug, which can cause short circuit and fire. -
Page 7: Characteristics Of Product And Confirmation Of Parts P
Characteristics of Product Lotus-14LK-H is a pack-type laminator that supports up to A3 size. It can be used for wide range of uses from black-and-white photocopy to menu. Also, stable outcomes and high quality laminate processing can be secured during continuous use for long time. -
Page 8: Name Of Each Part
Name of Each Part Front side of main body Vent hole This is a vent hole of the fan used to cool the body Top cover Be careful while processing as the cover gets hot. Body cover Insertion Insert paper covered by laminate film. Operation panel Set temperature and speed. -
Page 9: Control Panel
Operation Panel The panel includes various setting buttons and LCD. LCD Part Displays laminate speed Processing speed is displayed using a number between 1~6. The higher the number, the faster the roller rotates Displays temperature setting Temperature set to 170℃~190℃ is displayed. Waiting lamp Once surface temperature of the roller is close to the setting temperature displayed on LCD, 【READY】... - Page 10 Speed setting, stop, and reverse buttons Set the speed of laminate process. Flickers Speed can be set in 6 steps using 【1】~【6】 buttons. Press 【Stop】 button to stop rotation of the roller. If 【Reverse】 button is pressed during rotation of the roller, the roller rotates in reverse direction while the button is being pressed.
- Page 11 『CURRENT TEMPERATURE』 button When 【CURRENT TEMPERATURE】 button is pressed, current surface temperature of the roller is displayed. 【MEASURE】 is displayed while the button is being pressed. 【Current Temperature】 button is pressed in HOT setting Temperature display switch button Whenever 【℃/℉】 button is pushed, it is switched between Celsius display (℃) and Fahrenheit display (℉).
-
Page 12: Before Processing Laminate P
Before Laminate Processing Composition and thickness of laminate film There are two types of laminate film, 「roll type」 and 「pack type」. This product uses 「pack type」 laminate film. ※ 「Roll type」 laminate film cannot be used. Composition of film Pack type laminate film is a set of two sheets that have a contacting side. Glue is applied on the inside. Glue is melted using heat when passing through the laminate for adhesion. -
Page 13: Size And Type Of Laminate Film
Size and type of laminate film Size of laminate film includes standard sizes and special order sizes cut into different sizes. Standard sizes Size of laminate film (affiliated standard products) Card size (55mm X 85mm ~ 100mm X 146mm) ~ A3 size (303mm X 426mm) There are two types of 「AB board」... -
Page 14: Materials That Can Be Laminated
Materials that can be laminated Different laminators have different materials (papers) that can be laminated. This product can also laminate 「photographs」 and 「colored printouts」 with the help of heating structure in the internal rollers, but there are materials (inappropriate) for laminate. Things written using crayons (there are crayons that are liquefied when heated) Thermal papers (since papers pass between heated rollers, papers are discolored) Pressure sensitive papers (since papers pass between pressurized rollers, papers are... -
Page 15: Correct Method Of Use
Correct Method of Use Use appropriate laminate film This product can use laminate films with size of card ※ ~ A3. (Refer to P13) If an inappropriate film is used, laminate may not be clearly done or the laminator can be broken. Refer to details below when using this product to use appropriate laminate film. -
Page 16: Correctly Insert Laminate Film
Correctly insert laminate film When inserting laminate film with paper into the laminator, incorrect handling can cause poor laminate or failure of the laminator. Refer to details below for correct insertion. Direction of film insertion When inserting laminate film into the laminator, The contact side of the film must be inserted first. - Page 17 Note During laminate process, correct temperature and speed setting can improve the degree of completion for the processed material. Internal structure of this product Heat roller Pull roller Paper (film) Cooling plate Paper insertion Cooling fan hole Flow of laminate film ①...
-
Page 18: Laminate Processing
Laminate Processing Laminate processing sequence Refer to the following sequence during laminate processing. Preparation of laminator Preparation of materials (paper and film) Turn power on the rear side on and pull Check the size of paper. the lever down. Set temperature according to paper. Prepare for laminate film appropriate for the paper size. -
Page 19: When Completing Laminate Process
When completing laminate processing When completing laminate processing, the laminate roller can be broken or damaged by turning power off immediately. Use 【COLD】 function to decrease temperature of the laminate roller and finish the work before turning power off. COLD function When 【COLD】... -
Page 20: Repair And Inspection
Cleaning work can be effective when performed at every 100~200 laminate works. Prepare a thick paper such a drawing paper. (There is a pack type laminate film product of Lami Corporation Inc that includes exclusive cleaning paper.) Appropriate size is about 30cm X 30cm ~ 50cm. -
Page 21: Movement And Storage Of Laminator
Movement and storage of laminator Be careful about the following matters when transporting or storing this product. Precautions for movement ① Confirm that roller temperature is low and power is turned off. ② Lift the lever and turn the power OFF. ③... -
Page 22: Troubleshooting For Failures
Troubleshooting for Failures The following must be kept in mind while using this product. Power does not turn on or machine does not function Insert outlet plug and check power switch This product is used with AC 230V Makes sure that the outlet plug is correctly connected. Check whether power switch on the rear side is turned on. -
Page 23: Processing Is Not Cleanly Done
Processing is not cleanly done Check temperature and speed setting Refer to P15 of this document to check correct setting of laminate temperature and speed. If temperature and speed are inappropriate, processing may not be done cleanly as shown below. Bubbles formed between film and paper. -
Page 24: Others P
Others Product Specification Max. laminating width 350 mm Max. substrate thickness 1.5 mm Laminating speed 3430 m/min (fixed) Processing temperature 170℃ ~ 190 ℃ Heating method External heating method Power requirements AC 230V 50/60 Hz Max. power consumption 1800 W Size (W×D×H) 645 ×...
