Page 1: Power Supply
NSTRUCTION MANUAL VARIABLE FREQUENCY VIBRATORS POWER SUPPLY AFV2000 : AP02020G ORDERING CODE filename: AP02020G_eng update: 09/11/2012... -
Page 2: Table Of Contents
INDEX INTRODUCTION ............................2 DEVICE DESCRIPTION ..........................3 TECHNICAL SPECIFICATIONS ........................4 WIRING TABLE ............................5 STARTUP ...............................6 PROBLEMS SOLUTION ..........................7 OPENING INSTRUCTIONS.........................7 PARTS IDENTIFICATION...........................8 OPTION'S WIRING TABLE.........................9 INTRODUCTION The vibrators power supply has been designed to keep in vibration the feeded system giving it the necessary energy exactly when required. -
Page 3: Device Description
DEVICE DESCRIPTION The vibrators power supply is very compact and easy to install. With reference to the drawing at the bottom of this manual, it will be very simple to identify the most important components. Two holes (diam. 6 mm) will allow to fix the box to the structure which will support the device. Electrical connections are made with a 6 and with a 9 poles terminal box (see wiring options table at page 9). -
Page 4: Technical Specifications
TECHNICAL SPECIFICATIONS Power supply: 230Vac ± 15%, frequency 50 or 60 Hz Output voltage: from 50 to 220Vca (with power supply 230Vca) Output compensation: compensation of power supply variations Output frequency: from 3,0 to 199,9 Hz in step of 0,1 Hz Current: maximum current 5 Amperes peak (about 2,5 Arms) limited from a circuit with autoreset... -
Page 5: Wiring Table
WIRING TABLE PIN REF. SIGNAL DESCRIPTION WIRE SECTION CONNECT TO: M3-6 GROUND CONNECTION EARTH M3-5 MAINS INPUT (NEUTRAL) 230 Vac M3-4 MAINS INPUT (PHASE) 230 Vac GROUND and SHIELD CONNECTION VIBRATOR (if provided) M3-3 shielded OUTPU SUPPLY FOR VIBRATOR VIBRATOR COIL M3-2 shielded M3-1... -
Page 6: Startup
STARTUP • Verify that mains breaker is in OFF position • Put the voltage reference at about 20% • Verify switch SW2 (red) lever status (if is up the power supply will start as soon as supplied, if is down the external start command is required) •... -
Page 7: Problems Solution
If actions remarked on the table doesn't resolve the problem you may contact factory digisystem srl (e-mail ) we will help you. info@digisystemsrl.it OPENING INSTRUCTIONS... -
Page 8: Parts Identification
PARTS IDENTIFICATION: PART REF. FUNCTION Connector Mains input 230Vac and Load output, Connector Start-stop command and Remote potentiometer Fuses Mains fuses Trimmer Sets minimum reference voltage from potentiometer Trimmer Sets maximum reference voltage from potentiometer Rotary switches Selects output frequency Switch Sets start command (autostart or external start command) Jumper... -
Page 9: Option's Wiring Table
OPTIONS WIRING TABLE (M2) REFERENCE PIN NUMBER WIRE SIGNAL DESCRIPTION SECTION REF. VOLT. 0,35 Voltage reference (0-5V) 0,35 Potentiometer sliding contact (10K) 0,35 Potentiometer counterclockwise side (0V insulated) 0,35 Potentiometer clockwise side (+5V insulated) 0,35 0V insulated for external sensor feeding 0,35 Run command from PNP or NPN sensor INV.
