- Page 1 NSTRUCTION MANUAL VARIABLE FREQUENCY VIBRATORS POWER SUPPLY AFV2000-2,5A : AP020206-APN20206 ORDERING CODE filename: AP020206_eng update: 09/11/2012...
-
Page 2: Table Of Contents
INDEX INTRODUCTION ............................2 DEVICE DESCRIPTION ..........................3 TECHNICAL SPECIFICATIONS ........................4 WIRING TABLE ............................5 STARTUP ...............................6 PROBLEMS SOLUTION ..........................7 OPENING INSTRUCTIONS.........................7 PARTS IDENTIFICATION...........................8 OPTION'S WIRING TABLE.........................9 INTRODUCTION The vibrators power supply has been designed to keep in vibration the feeded system giving it the necessary energy exactly when required. -
Page 3: Device Description
DEVICE DESCRIPTION The vibrators power supply is very compact and easy to install. With reference to the drawing at the bottom of this manual, it will be very simple to identify the most important components. Two holes (diam. 6 mm) will allow to fix the box to the structure which will support the device. Electrical connections are made with a 6 and with a 9 poles terminal box (see wiring options table at page 9). -
Page 4: Technical Specifications
TECHNICAL SPECIFICATIONS Power supply: 230Vac ± 15%, frequency 50 or 60 Hz Output voltage: from 50 to 220Vca (with power supply 230Vca) Output compensation: compensation of power supply variations Output frequency: from 3,0 to 199,9 Hz in step of 0,1 Hz Current: maximum current 5 Amperes peak (about 2,5 Arms) limited from a circuit with autoreset... -
Page 5: Wiring Table
WIRING TABLE PIN REF. SIGNAL DESCRIPTION WIRE WIRE CONNECT TO: SECTION COLOR MAINS INPUT (NEUTRAL) BLUE 230 Vac M3-6 GROUND CONNECTION YELLOW- EARTH GREEN M3-5 MAINS INPUT (PHASE) BROWN 230 Vac M3-4 0V INSULATED 3x0, 5 M2-4 shielded START COMMAND INPUT 3x0, 5 M2-3 (required current 10 mA) -
Page 6: Startup
STARTUP • Verify that mains breaker I1 is in OFF position • Put the potentiometer P3 at about 20% • Verify switch SW2 (red) lever status (if is up the power supply will start as soon as supplied, if is down the external start command is required) •... -
Page 7: Problems Solution
If actions remarked on the table doesn't resolve the problem you may contact factory digisystem srl (e-mail ) we will help you. info@digisystemsrl.it OPENING INSTRUCTIONS As on the electronic card there are some capacitors with high voltage applied (presence of residuary energy, danger of strike) you must wait at least 4 - 5 minutes after the device is disconnected from the power supply, before opening the box. -
Page 8: Parts Identification
PARTS IDENTIFICATION: PART REF. FUNCTION Fairlead Mains input 230Vac access to M3 Connector Load output Fairlead Start-stop command access to M2 Mains switch Breaker Lamp Mains lamp Fuses Mains fuses Trimmer Sets minimum reference voltage from potentiometer Trimmer Sets maximum reference voltage from potentiometer Potentiometer 10K Regolates output voltage Rotary switches... -
Page 9: Option's Wiring Table
OPTIONS WIRING TABLE (M2) REFERENCE PIN NUMBER WIRE SIGNAL DESCRIPTION SECTION REF. CURR. 0,35 Current reference (0-20mA) 0,35 Voltage reference (0-5V) REF. VOLT. 0,35 Potentiometer sliding contact 0,35 Potentiometer counterclockwise side 0,35 Potentiometer clockwise side (+5V insulated) 0,35 0V insulated for external sensor feeding 0,35 Run command from PNP or NPN sensor INV.
