IMPORTANT: Read the instructions and watch the video for further details
RTR ASSEMBLY
Note: For more detailed instructions, refer to page 4 of
the assembly and operation manual.
2.
Install (8) "AA" batteries into
the transmitter. Check to make
sure the red power light glows
when the transmitter is on.
4.
Install (4) "AA" batteries into the
receiver battery holder.
6.
Decal the body as desired and install on the chassis.
Install the wing wire into the holes in the rear shock tower.
Note: If the wing fits loosely, bend the end of the wires a bit.
®
on running and maintaining your new DuraTrax
1.
Install the transmitter
antenna into the transmitter.
3.
Install the receiver
antenna tube. Secure the
excess wire to the tube
using tape. DO NOT CUT
THE ANTENNA WIRE.
5.
Use a tie strap to secure
the batteries in the holder.
®
RUNNING THE NITRO EVADER
1.
Install the included "C"
size battery into the included
glow starter.
2.
Add fuel to the fuel tank using the included fuel bottle.
3.
Turn the transmitter "on" and check that the battery
indicator light is on. If the battery indicator light is not "on"
or is blinking, you need to change your transmitter
batteries before running your Nitro Evader.
4.
Turn on the Nitro Evader.
Squeeze for
forward
5.
Make sure the throttle opens all the way when the
throttle is applied on the transmitter. Make sure the brakes
work adequately when the trigger is pushed forward.
ADJUSTABLE
STEERING
RATE
6.
Make sure the front wheels of the Nitro Evader move left
and right correctly when the transmitter wheel is turned.
™
vehicle.
Push for
brake
THROTTLE
STEERING
TRIM
TRIM
™
