- Page 1 Wireless Calling Receiver User Manual (ZJ-48) Wireless calling system...
- Page 2 48-channel Wireless Calling Receiver ZJ-48 User Manual Summary Thanks for choosing the wireless calling system. The receiver host adopts RF wireless and learning code technology. It can easily pair up to 48 channels of wireless calling buttons. The receiver host uses advanced micro processor and high-sensitivity superheterodyne receiving technology which make the products very stable.
- Page 3 Diagram Display area Antenna Pair/Set Down Volume DC9~12V Power indicator LED indicator Cancel/delete button Button Function STUDY First press to enter working mode settings; Second press to enter pairing settings; Third press to quit settings; Hold for 10s to delete all the paired call buttons Page up the channel DOWN Page down the channel...
- Page 4 Operation Instruction 1. Self test when power on When the receiver host is power on, it starts initialization program. The 48 LED indicators flicker along with 3 sounds doorbell, and then the power LED on. 2. Function settings At first use, please do the settings like below. First press【STUDY/SET】button to enter “working mode settings”, second press the button to enter “pairing settings”, third press the button to quit settings.
- Page 5 (2) Pair call button Press【STUDY】button twice then the first channel LED will be ON that means the receiver enters pairing settings. Then press the call button, the LED will flicker twice which means the pairing successfully, and the LED indicator jumps to the second channel, then press another call button to pair the second one...
-
Page 6: Packing List
Packing List Quantity Name 1 pc Receiver host Power adaptor 1 pc 1 pc User manul Warranty card 1 pc Notice While it is working, please pull the antenna out for the best receiving effect.
