TV/VCR Features
Using the TV/VCR Features

Sleep Timer

Wake-Up Timer

The timer turns the TV/VCR on at a desired time. You can set it to
wake you up in the morning or remind you that a favorite program
is about to start.
Note: When the wake-up timer turns on the TV/VCR, the volume
level does not change from when the TV/VCR was last turned off.

Front Panel Block

10
The sleep timer automatically turns the TV/VCR off after 30, 60, 90,
or 120 minutes.
1. Press SLEEP on the remote to select 30, 60, 90 or 120 minutes.
2. To cancel the sleep timer, press SLEEP until the timer
disappears.
You can also access the sleep timer through the menu system.
1. Press MENU on the remote to display the TV/VCR MAIN MENU.
2. Press 2 to display the TIME menu.
3. Press 2 to display the SLEEP TIMER screen.
4. Press CHAN up or down to select 30, 60, 90, or 120 minutes.
5. Press MENU three times to exit.
While watching a program, press DISPLAY to check the amount
of time remaining before the TV turns off.
6. To cancel the sleep timer, first display the SLEEP TIMER menu
by repeating steps 1-4 above. Then, repeatedly press CHAN up
or down until 0:00 is displayed on the screen.
1. Press MENU on the remote to display the TV/VCR MAIN MENU.
2. Press 2 to display the TIME menu.
3. Press 3 to display the WAKE-UP TIMER menu.
4. Use the number buttons to enter the channel number and time.
• After you enter the time, press 1 for AM or 2 for PM. Example:
For a time of 5:07PM, press 5, then 0, then 7, then 2.
• Press CLEAR to correct an entry or RESET to clear the timer.
5. Press MENU to set the timer.
• The wake-up timer will turn on the TV/VCR every day. The
WAKE-UP indicator light on the front panel is illuminated
when the wake-up timer is set.
• Once the TV/VCR is turned on by the wake-up timer, the
unit automatically turns off after 60 minutes if no buttons
are pressed.
6. To cancel the wake-up timer, first display the WAKE-UP TIMER
menu by repeating steps 1-3 above. Then, press RESET to cancel
the timer, and press MENU to exit. The timer is also canceled if
MENU is pressed before step 4 is completed.
Selecting this option lets you block (disable) or unblock (enable) the
TV's front panel buttons. Any timer recordings will still record
(provided there is a tape in the VCR). Front Panel Block can keep
children from watching TV or playing with the TV buttons when a
parent is not present.
1. With the TV/VCR on, press and hold the POWER button on the
remote for approximately 6 seconds. The indicator in the Power
button flashes.
The indicator in the Power button flashes if the STOP/EJECT or
POWER buttons on the front panel are pushed but nothing will
happen.
To turn off the Front Panel Block, press and hold the POWER
button for 6 seconds.
CH 08
Sleep Timer
0:30
10/31/98 Sat 0:800 AM SLP
TV/VCR MAIN MENU
1 Screen
2 Time
TIME
1 Set Time and Date
2 Sleep Timer
SLEEP TIMER
Turn off TV in 0:00
Press Channel up or
down to adjust timer.
Press MENU to exit
TV/VCR MAIN MENU
1 Screen
2 Time
TIME
1 Set Time and Date
2 Sleep Timer
3 Wake-up Timer
WAKE-UP TIMER
Channel --
Time
--:--
WAKE-UP TIMER
Channel 12
Time
05:07 AM
Press CLEAR to correct
Press RESET for --:--
Press MENU to exit
