Elenberg CTV-1515 Service Manual

Hide thumbs Also See for CTV-1515:

Advertisement

Quick Links

Download this manual
CTV-1515 SERVICE MANUAL
CONTENT
PART 1：
Brief Introduction Of The CTV-1515
◆
◆
Exploded View
PART 2:
Key Ics And Assemblies
PART 3：
Detailed Circuit
PART 4:
◆
◆
Parts List
PART 5:
Debug Procedure
PART6:
Schematic Diagram
Printed Circuit
Main Board
HI-voltage Board

Advertisement

loading
Need help?

Need help?

Do you have a question about the CTV-1515 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Elenberg CTV-1515

Summary of Contents for Elenberg CTV-1515

  • Page 1 CTV-1515 SERVICE MANUAL CONTENT PART 1： Brief Introduction Of The CTV-1515 ◆ Schematic Diagram ◆ Printed Circuit Exploded View PART 2: Key Ics And Assemblies PART 3： Detailed Circuit PART 4: ◆ Main Board ◆ HI-voltage Board Parts List PART 5:...

  • Page 2: Schematic Diagram

    Part 1 Brief Introduction Of The CTV-1515 Schematic Diagram 电源 接口 视频 DC-DC IC Vcc5 TUNER,DDC, TUNER TV—CVBS 电源板 AP1513 AUDIO-PROCESS AV—CVBS STBY 5V Svideo—Y HZ5B1 FOR IR S-VIDEO FLASH Svideo—C 3.3V VGA-R DC-DC IC Vcc3.3 1.8V FLI8125 AP1513 VGA-G 屏...

  • Page 3: Printed Circuit

    Printed Circuit 1. Main board A: TOP LAYER B: BOTTOM LAYER...

  • Page 4: Power Board

    2. Power board A: TOP LAYER B: BOTTOM LAYER 3. Inverter board A: TOP LAYER...
  • Page 5 B: BOTTOM LAYER 4. Remote Control Board A: TOP LAYER B: BOTTOM LAYER 5. Key board A: TOP LAYER B: BOTTOM LAYER...

  • Page 6: Part 2 Exploded View

    Part 2 Exploded view...

  • Page 7: Part 3 Key Ics And Assemblies

    Part 3 Key ICs And Assemblies On Main Board On remote control board Serial Serial Position Type Position Type W39L040AP70Z HL38B17 AT24C32AN On power board FLI8125-LF FSCM0765RGWDTU 24C02 PC817 MSP3415G KA431AZ CD4052 U7 U9 AP1513S On HI-voltage Board L7808C-V Bit3193 AZ1117H-1.8 FDS9435 Q2,Q6...
  • Page 8 ICS ON MAIN BOARD 1. AP1513 · Block Diagram...
  • Page 9 2. FDS9435A Single P-Channel Enhancement Mode Field Effect Transistor SO-8 P-Channel enhancement mode power field effect transistors are produced using Fairchild's proprietary, high cell density, DMOS technology. This very high density process is especially tailored to minimize on-state resistance and provide superior switching performance.
  • Page 10 3. FLI8125 The FLI8125 is a cost-effective, highly-integrated, mixed signal solution for TV and Digital Video applications. It incorporates a multi-standard video decoder, high-speed triple 8-bit Analog-to-Digital Converter(ADC),and front end switching. An integrated VBI Slicer adds Closed Captioning(CC) and Teletext service support, and the built-in microprocessor enables full system control without external devices.
  • Page 11 ·PInput ·Pin List I/O Legend: A = Analog, I = Input, O = Output, P = Power, G= Ground Table 1: Analog Input Port Pin Name Description VDD18_A Analog Power (1.8V) for A & B Channels. Must be bypassed with 0.1uF capacitor to the analog system ground plane.
  • Page 12 Positive analog input ‘A’ for channel 1. The input has to be AC coupled using a series 20 Ohm resistor and 0.1uF Capacitor network. GNDS Analog Ground. Must be directly connected to the analog system ground plane on board. Positive analog input ‘B’ for channel 1. The input has to be AC coupled using a series 20 Ohm resistor and 0.1uF Capacitor network.
  • Page 13 Negative analog sync input for channels 1 through 4. This acts as the return Path for the Sources connected to SV Channel Inputs. This has to be AC coupled using a series 20 Ohm resistor and 0.1uF Capacitor network to Analog Ground Plane on board. VO_GND Analog Ground.
  • Page 14 VID_DATA_IN_8 Input Pr / Pb Data in case of 16 Bit Video Input (CCIR601) of Video Input – 1 VID_DATA_IN_9 OR Input Green Data in case of 24 Bit Video Input VID_DATA_IN_10 VID_DATA_IN_11 VID_DATA_IN_12 VID_DATA_IN_13 VID_DATA_IN_14 VID_DATA_IN_15 VID_DATA_IN_16 Input Blue Data in case of 24 Bit Video Input VID_DATA_IN_17 OR Video Input –...
  • Page 15 GPIO14/PWM3/ This Pin can be programmed to give out Pulse Width Modulated Output Pulses for external use. SCART16 Or it can be programmed to sense the Fast Blank Input signal from a SCART I/P source. When not used, this pin is available as General Purpose Input/output Port. This Pin provides the Output Data in case of Boundary Scan Mode.
  • Page 16 Table 7: TTL Display Interface Pin Name Description For 8-bit panels For 6-bit panels PBIAS Panel Bias Control (backlight enable) [Tri-state output, 5V- tolerant] PPWR Panel Power Control [Tri-state output, 5V- tolerant] Digital Power for TTL Block. Connect to digital 3.3V supply. AVDD_LV_33 VCO_LV Reserved.
  • Page 17 PD46 Blue channel bit 6 (Odd) Blue channel bit 4 (Odd) PD47 Blue channel bit 7 (Odd) Blue channel bit 5 (Odd) Note: In case of 24 Bit TTL Panels the RGB Odd Channel Outputs will not be used. In that case they can be made available for other purposes as Address &...
  • Page 18 4. TDA1517P 2 x 6 W stereo power amplifier The TDA1517 is an integrated class-B dual output amplifier in a plastic single in-line medium power package with fin (SIL9MPF), a plastic rectangular-bent single in-line medium power package with fin (RBS9MPF) or a plastic heat-dissipating dual in-line package (HDIP18).
  • Page 19 5. AT24C32AN 2-Wire Serial EEPROM 32K (4096 x 8)
  • Page 21 6. CD4052B The CD4052B is a differential 4-Channel multiplexer having two binary control inputs, A and B, and an inhibit input. The two binary signals select 1 of 4 pairs of channels to be turned on and connect the analog inputs to the outputs. ·PInputs...
  • Page 22 ICS ON HI-VOLTAGE BOARD 1. BIT3193 High Performance PWM Controller BIT3193 integrated circuit provides the essential features for general purpose PWM controller in a small low cost 16-pin package. BIT3193 has built-in a low frequency PWM generator for any specified application. BIT3193 includes latched off protection feature may make the system more reliable while compare to other similar products.
  • Page 23 ·Pin Description Symbol Descriptions The inverting input of the error amplifier. Output of the error amplifier. LOAD A switch that connected to the high frequency triangle wave generator. This switch is open while ISEN pin <1.3V. An external resistor connected here may change the operation frequency of CTOSC in open load situation.
  • Page 24 2. AP4511M N AND P-CHANNEL ENHANCEMENT MODE POWER MOSFET...

  • Page 25: Part 4 Detailed Circuit

    Part 4 Detailed Circuit MAIN BOARD 1. Interface VCC16 R127 200R +5V STBY L1206 EC46 C122 CON3 VCC16 R128 200R 100uF/16V 100nF HZ5B1 OUT_L TDA1517P 2EC1 AUDIO-L CON4 IN1- +5V STBY OUT_R 100u 470n SGND SVRR OUT_L 2EC2 OUT1 470u PGND 8125IR VCC16...
  • Page 26 2. Hundson ROM_OEN VCC3.3 ROM_OEN ROM_CSN 2.7k 2.7k VCC3.3 100n VCC3.3 ROM_WEN 4.7k 100n AT49BV040B 24LC32SN H_SY NC1 VCC3.3 V_SY NC1 VSY NC1 XOSD_FLD/A11/PD35/ROM512K VDD18_AB XOSD_VS/A12/PD36/JT_BSCAN XOSD_HS/A13/PD37/OP_MD0 GND18_C XOSD_CLK/A14/PD38/OP_MD1 VDD18_C EXT_ADC_CLMP/A15/SPI_EN ADC_TEST RVSS AVDD_ADC RVDD_33 ROM_WEN 100n 100n AGND ROM_SDI/ROM_WEN AGND ROM_SDO/A16/OCM_ROM VCC3.3_PANEL...
  • Page 27 3. Audio 2.7K SCART-AL EC31 10uF 2.7K SCART-AR EC32 10uF EC33 10uF 4052-L EC34 10uF 4052-R VCC5_TUNER TV_MONO 0805 L1206 EC35 C100 C101 C102 100uF/16V 1.5nF 470pF 220pF VCC8 100NF EC36 C103 C104 100uF/16V 1.5nF 470pF EC38 C105 EC39 C106 10uF 0805 EC37...
  • Page 28 4. Power LH0608-33UH DC12V-IN VCC5_TUNER VCC16 R142 R143 VCC5 VCC16 100k 33uH/2A VCC5 OUT1 CON8 OCSET OUT2 EC49 0805-50R VSS1 100u SS23 VSS2 C134 TFL1 R141 AP1513 3.3k TRANSFORMER C132 R144 EC50 C133 100n 220u 100n C135 R145 HIGH LEVEL 100n 1.2k POWER_ON...
  • Page 29 5.CVBS&VGA CON/RCA3 2.7k RIN1 EC20 2.2uF/16V RIN1 AV_R1 AV_R 100n GIN1 GIN1 100n EC21 2.2uF/16V 2.7k AV_L1 AV_L BIN1 BIN1 100n H_SY NC1 H_SY NC1 100p 100p V_SY NC1 V_SY NC1 100n CVBS CVBS1 D-SUB15 FEMALE 2.2k 2.2k D1 1N4148 2.7k SVIDIO VCC5...
  • Page 30 6. SCART & TUNER 2.7uH SCART-R1 SCART-R L0603 0.1uF 20R/1% 75R/1% 330pF 330pF SCART-SW DESCRIPTION LEV EL 2.7uH SCART-G1 SCART-G SCART-ROUT L0603 0.1uF 0V - 2.0V SCART ABSENT SCART-AR 20R/1% SCART-LOUT 330pF 330pF 75R/1% 4.5V - 7.0V SCART PRESENT 16:9 INPUT SCART-AL SCART-B1 2.7uH...
  • Page 31 7. Y/PB/PR FOR RUSSIA C145 100nF R154 RIN2 C146 100nF BIN2 R155 C147 100nF R156 GIN2 C148 C149 C150 R157 R158 R159 75R/1% 75R/1% 75R/1% 22pF/NC 22pF/NC 22pF/NC Y PbPr_R1 EC58 2.2UF/16V R160 2.7k Y PbPr_R Y PbPr_L Y PbPr_L1 R161 2.7k EC59 2.2UF/16V...
  • Page 32 HI-VOLTAGE BOAD NIA19LES018 1206-102 220uF/25V 2N3904 PH05-2A 10pF/3KV 8.0-2A IC_VCC 2N3904 2N3906 7.5B BAV99 2N7002 BAV99 AP4511 BIT3193 10pF/3KV 8.0-2A IC_VCC AP4511 BAV99 BAV99 1SS355 1SS355 1SS355...
  • Page 33 Part5 Part list of CTV-1515 Bom No Part No Part No LTD06P-2956C01 02.19.LTD06P2956C01 Power board Part No Name Specification LOCA NO 01.57.R.3.E681J SMD resistor 0805-680Ω±5% 01.57.R.3.E472J SMD resistor 0805-4.7KΩ±5% 01.57.R.3.E222J SMD resistor 0805-2.2KΩ±5% 01.57.R.3.E123J SMD resistor 0805-12KΩ±5% R3 R11 01.57.R.4.E4R7J SMD resistor 1206-4.7Ω±5%...
  • Page 34 01.41.D.PD.EFR104 Diode FR104 DIP 01.41.D.PD.ESF20NC15 Diode SF20NC15M D3 D4 01.41.D.PD.E2015CT Diode MBRF20150CT DIP D3 D4 01.41.D.WD.E10V DIP zener diode 01.41.D.WD.E20V DIP zener diode FSCM0765RGWDTU 01.44.IC.D.EM0765 01.44.IC.D.EPC817 PC817 DIP 01.44.IC.D.EKA431A KA431AZ DIP 01.41.D.PD.EUS4K80 Diode US4K 80R DIP 01.41.D.PD.EGBU406 Diode GBU406 DIP 01.41.D.PD.EGBU408 Diode GBU408 DIP...
  • Page 35 Bom No Part No Part No LTV06K-3670C01 02.15.LTD06K3670C01 Key board Part No Name Specification LOCA NO 01.57.R.2.E102J SMD resistor 0603-1KΩ±5% R1 R2 R3 01.57.R.2.E202J SMD resistor 0603-2KΩ±5% R4 R5 01.57.R.2.E472J SMD resistor 0603-4.7KΩ±5% R6 R7 0603-104 01.54.CS.2.E104Y SMD capacitor C1 C2 C3 Y5V-20+80%/50V 01.54.CS.B.E150 Press agile resistor...
  • Page 36 R160 R161 01.57.R.2.E302J SMD resistor 0603-3KΩ±5% R144 01.57.R.2.E332J SMD resistor 0603-3.3KΩ±5% R141 R5 2R9 R138 01.57.R.2.E472J SMD resistor 0603-4.7KΩ±5% R139 R140 R3 R4 R6 R7 R9 R10 R11 R12 R13 R14 2R4 2R7 R34 R110 R112 R113 01.57.R.2.E103J SMD resistor 0603-10KΩ±5% R114 R118 R119 R123 R124 R131...
  • Page 37 0603-102 X7R± 01.54.CS.2.E102X SMD capacitor (C117) (C118) 10%/50V 0603-103 01.54.CS.2.E103Y SMD capacitor C134 C141 Y5V-20+80%/50V C1 C2 C3 C4 C5 C6 C7 C8 C9 C10 C11 C12 C13 C14 C15 C16 C17 C18 C19 C20 C21 C22 C23 2C3 C24 C25 C26 C27 C28 C29 C30 C31 C35 C37 C38 C39 C40...
  • Page 38 CD110-470UF/25V 01.34.CL.D.E470U25VE Electrolyse capacitor 2EC3 2EC2 8*14 CD110-1000uF/25V 01.34.CL.D.E1000U25VG1 Electrolyse capacitor 2EC4 10*20 L8 L28 L29 L30 L32 L33 L34 L16 01.13.L.Z.ESA50 SMD magnetism bead 0603-50Ω L17 L18 L19 L46 01.13.L.L.D.E150 DIP inductor LH0608-33UH L36 L38 01.13.L.L.D.E038 Color code inductor 33UH L25 L24 01.13.L.L.D.E056...
  • Page 39 01.40.CON.S13.AY.E002 SMD jack 1.25-20A CON1 01.40.CON.DPH.E020 Jack PH-4A CON2 01.40.CON.DPH.E024 Jack PH-5A CON6 01.40.CON.DTJ.E004 Jack TJC3-2A CON3 CON4 01.40.CON.DTJ.E012 Jack TJC3-6A CON8 01.40.CON.DCZ.E007 VGA jack EV-015FC/15 01.40.CON.DDZ.ES-081-9 S end seed S-081-9 CKX-3.5-02(without 01.40.CON.DCZ.E102 Perch earphone jack switch) 01.40.CON.DCZ.E164 Same core jack AV3-8.4-14G 01.40.CON.DCZ.E089 Same core jack...
  • Page 40 0603-104 X7R± 01.54.CS.2.E104X SMD Capacitor 10%/50V 0603-474 01.54.CS.2.E474Y SMD Capacitor Y5V+80-20%/50V 0603-105 01.54.CS.2.E105Y16V SMD Capacitor C6 C15 C22 C23 Y5V-20+80%/16V 0603-225 01.54.CS.2.E225Y SMD Capacitor Y5V-20+80%/10V 01.35.CC.E121010U25VX SMD ceramic Capacitor C3225X5R1E106KT C10 C3 1808-10P/3KV NPO± 01.54.CS.6.E100 SMD Capacitor C2 C9 01.34.CL.D.EKW220U25VO Electrolyse capacitor KW-220UF/25V 8*9 C1 C21...
  • Page 41 Part 6 Debugging Procedures 1. Signal process diagram...
  • Page 42 2. Debugging Strategy IR and Keys are Check communications between Check periphery circuit All Ok? IR,Key mode and FLI8125 Of IR,Keypad,drive IC Check wiring circuit of End debugging IR,Keypad...

  • Page 43: White Screen

    3. Tips Of Some Typical Troubleshooting White screen First check voltage in HI-voltage Board; otherwise check the voltage of MAIN board , if abnormal , the problem occurs in U7or U9. If the voltage is OK, check the LVDS. At last the connection between the main board and drive board may be the target for troubleshooting.
