  • Page 1 29” (72 : 29F08...
  • Page 4 ELENBERG Elenberg. Elenberg ..................5 ..................5 .............5 ................6 .............6 .........6 ...........7 ........8 .................9 .........9 ..............9 ..............10 ..........11 ..................12 ............12 ..............13 ..................14 ...................14 ..............16 ............18 .............19 ..........20...
  • Page 5 • • • “ ” • • 2 AV • S-VIDEO • • • D/K, I, B/G SECAM D/K, B/G (AV), SECAM NTSC 3.58/ 4.43 DVD- VHF: 46.25 - 144.25 VHF: 152.25 -424.25 UHF: 432.25 - 863.25 ( × × ): ×...
  • Page 6 PROG PROG...
  • Page 7 DVD- Задняя панель телевизора Задняя панель DVD Задняя панель телевизора Задняя панель DVD...
  • Page 8 Q.VIEW Переключение каналов Таймер переключения Таймер автоматического отключения P.TIMER SWAP TIMER Режим изображения Режим звука PICTURE SOUND ТВ INFO Качество звука I/II AAA (#7, 1.5 ) • – • •...
  • Page 9 MUTE ON/OFF Q.VIEW P.TIMER SWAP TIMER PICTURE SOUND PROG ▲/▼ INFO I/II PROG ▲/▼ PROG ▲/▼ MUTE ON/OFF Q.VIEW P.TIMER SWAP TIMER (000-239) PICTURE SOUND (0-9), INFO I/II ◀/▶. MUTE. VOL ▶ VOL ▲...
  • Page 10 MUTE ON/OFF MENU ◀/▶, PROG ▼. Q.VIEW – P.TIMER SWAP TIMER PICTURE SOUND MENU, MENU INFO I/II 2. 2. PROG ▲/▼ VOL ◀/▶. PROG ▲/▼, VOL ◀/▶...
  • Page 11 (TV/AV) (TV/AV) TV/AV (TV-AV1-AV1S-DVD1-AV2-TV). (INFO) (INFO) SWAP SWAP SWAP (ZOOM) (ZOOM) (Auto/ -Normal/ -Expand/ -Compress/ -Auto/ (PICTURE) (PICTURE) PICTURE (Personal/ -Mild/ -Normal/ -Dynamic/ -Personal/ (TIMER) (TIMER) TIMER, : 5, 10, 15, 20 …, 120 (P.TIMER) (P.TIMER) P.Timer, (OFF/ , 1, 2, 3,..10 /Commercial.
  • Page 12 MENU, VOL ◀/▶ (Picture) PROG ▲/▼, (Brightness) VOL ▶ VOL ◀ ontrast, / olour, /Sharpness, olour temp. / Hue NTSC. /Colour temp /Normal – /Warm – /Cold. VOL ◀/▶ /Personal- /Mild- /Normal- /Dynamic- /Personal). /Zoom: /Zoom: Auto- /Normal- /Expand- /Compress. /Auto /Auto /Normal.
  • Page 13 MENU, VOL ◀/▶ Sound: /Volume /Volume VOL ▶. VOL◀. /Balance /Balance Sound, /Balance, ◀/▶ /Bass /Bass VOL ▶. VOL ◀. (Treble) (Treble) VOL ▶, VOL ◀. – (AVL) (AVL) VOL ◀/▶. (Sound) (Sound) VOL ◀/▶ /Personal- /News- /Mu- sic- /Theatre- /Personal).
  • Page 14 (Effect) (Effect) VOL◀/▶ “ ” Incredible Mono credible Stereo. (Equalizer) (Equalizer) VOL◀/▶ VOL ◀/▶ PROG ▲/▼ 1 100 Hz 2 300 Hz 3 1 kHz 4 3 kHz 5 8 kHz MENU VOL ◀/▶ (Sleep timer): VOL ◀/▶ ./off, 5, 10, 15, 20..., VOL ◀/▶...
  • Page 15 MENU VOL ◀/▶ (Features) (Source) (Source) VOL ◀/▶ ./On: ./Off: 2. 2. VOL ◀/▶ (Screen Saver) (Screen Saver) VOL ◀/▶ ./Off- /Blue- ./Off) (Child lock) (Child lock) VOL ◀/▶ Child lock, /New password, /Confi rm, – 0000, - 1980.
  • Page 16 MENU. VOL ◀/▶ /Installation ( (Program) (Program) VOL ◀/▶ (Colour System) (Colour System) VOL ◀/▶ (PAL-SECAM). (Sound System) (Sound System) (Sound System), VOL ◀/▶ (BG-I-DK) (Frequency) (Frequency) VOL ◀/▶, (AFC) (Auto Install) (Auto Install) PROG ▲/▼ VOL ◀/▶, MENU. (Manual Install) (Manual Install) VOL ◀/▶...
  • Page 17 (Skip) (Skip) PROG ▲/▼, VOL ◀/▶ PROG ▲/▼ VOL ◀/▶ ./On, PROG ▲/▼. PROG ▲/▼. ./Off, (Lock) (Lock) PROG ▲/▼ VOL ◀/▶ Program. PROG ▲/▼ VOL ◀/▶ PROG ▲/▼ PROG ▲/▼, Off,...
  • Page 18 NTSC SECAM SECAM NTSC NTSC 3.58 4.43 50Hz 50Hz 60Hz 60Hz 29F08 S-VIDEO NICAM Mono 29F08 29F08 AC:180-240 29F08 750X500X570...
  • Page 19 MUTE VOL.
  • Page 20 • • •...
  • Page 21 29” COLOUR TELEVISION MODEL: 29F08 USER’S MANUAL...
  • Page 22 IMPORTANT SAFETY PRECAUTIONS CAUTION Risk of electric shock, do not open. Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualifi ed service personnel. WARNING 2.
  • Page 23 IMPORTANT SAFETY PRECAUTIONS 4. Do not push objects of any 5. Do not place this apparatus kind into this apparatus through near water, for ex ample, near a cabinet slots as they could touch bathtub, washbowI, kitchen sink, current carrying parts or short- or laundry tub;...

  • Page 24: Table Of Contents

    YOU ARE WELCOME TO USE ELENBERG COLOUR TV Thank you for purchasing an Elenberg colour TV. We hope this Elen- berg TV brings you pleasure in your audio and visual entertainment. To enjoy the various functions offered by the unit, please read this manual thoroughly before using the unit.

  • Page 25: Introduction

    INTRODUCTION Features: • 240 programs memory • Auto search • Child lock function • 1 component input • 2 AV inputs (Rear) • 1 S-VIDEO input • AV output (Rear) • C control system technology • Sleep timer Specifi cations Receiving System of TV Receiver SYSTEM FUNCTION...

  • Page 26: General Description General Description

    GENERAL DESCRIPTION Overview of the function keys Overview of the function keys Dear customer, please observe the function keys on the TV and refer to the following diagram to learn every function key. PROG PROG Overview of the side AV jacks Overview of the side AV jacks Please refer to the following diagram to learn the function of every side jack.

  • Page 27: Overview Of The Back Av Jacks

    Overview of the back AV jacks Overview of the back AV jacks By connecting a VCR (or other VIDEO equipment)to this unit,you can receive broadcasting programs or show VIDEO playback. Back of DVD Back of DVD...

  • Page 28: Overview Of The Remote Control

    OVERVIEW OF THE REMOTE CONTROL Quick view TV/AV Q.VIEW Swap Program switching timer P.TIMER SWAP TIMER Sleep Timer Picture mode Sound mode PICTURE SOUND Menu button TV Mode Status information INFO Stereo/MONO/NICAM I/II Batteries loading: Open the battery compartment cover, then insert 2 AAA (#7, 1.5V) batteries with the polarities (+ and -) as indicated in the battery compartment.

  • Page 29: Basic Operation Basic Operation

    BASIC OPERATION How to Turn Power On/Off How to Turn Power On/Off 1. Press down the main power switch to turn on the TV set. MUTE ON/OFF 2. If you need to turn off TV temporarily, press button on the remote control, and TV will be Q.VIEW on standby status while the power indicator will P.TIMER...

  • Page 30: Using The Menu

    BASIC OPERATION Using the Menu Using the Menu 1. How to operate the main menu 1. How to operate the main menu Press the MENU button on the remote control MUTE ON/OFF to enter the main menu, you can select the item with VOL ◀/▶...

  • Page 31: Special Function Adjustment Special Function Adjustment

    SPECIAL FUNCTION ADJUSTMENT 1. TV/AV switch 1. TV/AV switch Press TV/AV button repeatedly to change TV mode or AV mode into (TV-AV1-AV1S-DVD1-AV2-TV). 2. TV 2. TV Press TV button to go to TV mode immediately. 3. INFO 3. INFO Display current channel, volume and multi-sound information. 4.

  • Page 32: Adjustment Adjustment

    PICTURE ADJUSTMENT Picture adjustment Picture adjustment Press the MENU button to enter the main menu, then use the VOL ◀/▶ button to select the Picture item: 1. Press the PROG ▲/▼ button to select Brightness, press the VOL ▶ button to increase the brightness value and the VOL ◀ button to de- crease it.

  • Page 33: Sound Adjustment

    ADJUSTMENT Sound adjustment Sound adjustment Press MENU button to enter the main menu, then use VOL ◀/▶ button to select Sound item: 1. Volume 1. Volume Press the VOL ▶ button to increase Volume. Press the VOL ◀ button to decrease Volume. 2.

  • Page 34: Timer

    ADJUSTMENT 8. Effect 8. Effect Press VOL ◀/▶ button to decrease/increase the intensity of the sur- round effect for the Listening modes Incredible Mono and Incredible Stereo, the Listening mode determines which one is presented to the user. 9. Equalizer 9.

  • Page 35: Features

    ADJUSTMENT Features Features Press the MENU button to enter the main menu, then use the VOL ◀/▶ buttons to select the Features item, or press the white button: 1. Source 1. Source Press the VOL ◀/▶ button to Toggle Source OSD On or Off On: after the program is changed, the program number will be dis- played permanently.

  • Page 36: Installation

    ADJUSTMENT Installation Installation Press the MENU button to enter the main menu. Then use the VOL ◀/▶ buttons to select the Installation item, (lf child lock is set to ON, it is necessary to input the password to enter this menu) 1.
  • Page 37 ADJUSTMENT 7. AFC 7. AFC Select AFC item, press VOL ◀/▶ button to select On or Off. 8. Skip 8. Skip Press the PROG ▲/▼ button to select the Program item, then press the VOL ◀/▶ buttons to select the program you want to skip, and press the PROG ▲/▼...

  • Page 38: Special Function Tables Special Function Tables

    Colour TV receiving systems table SYSTEM NTSC SECAM SECAM NTSC NTSC 3.58 4.43 MODEL 50Hz 50Hz 60Hz 60Hz 29F08 Colour TV Functions table Function S-VIDEO Component Headphone NICAM Teletext Child Mono lock MODEL 29F08 Colour TV Specifi cations table Model...

  • Page 39: Troubleshooting Troubleshooting

    TROUBLESHOOTING If you have any problem, check the countermeasures for each symp- tom listed below. The following symptoms may have been caused by inappropriate adjustments rather than actual malfunction of the unit. If the trouble persists, contact the service centre. SYMPTOMS SYMPTOMS POSSIBLE SOLUTIONS...

  • Page 40: Picture Defects And The Reasons Picture Defects And The Reasons

    PICTURE DEFECTS AND THE REASONS SNOWY PICTURE SNOWY PICTURE Snowy picture is usually due to weak signal. Ad- just antenna or install an antenna amplifi er. DOUBLE IMAGE OR GHOSTS DOUBLE IMAGE OR GHOSTS Double images are usually caused by refl ections from tall buildings.
