Technical Manual
JBL CONTROL 25T/WH
SPECIFICATIONS
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance:
• Power Capacity:
• Frequency Range:
• Crossover Frequency:
SYSTEM COMPONENTS:
• Cabinet:
• Grille:
• Low Frequency
Transducer:
• DC Resistance:
• Tap Settings:
100V Line: Tap 1 = 7.5W, Tap 2 = 15W
70V Line: Tap 1 = 3.7W, Tap 2 = 7.5W
PACKAGE
RED
INPUT
BLK
JBL Incorporated, 8500 Balboa Boulevard, P.O. Box 2200, Northridge, California 91329 U.S.A.
8 ohm
150W Continuous Program
80 Hz to 15 kHz (–10 dB)
3 kHz
Not For Sale
128-00163-60
135mm (5.25 in.) Cone
Transducer (124-10000-00)
5.6 ohm ±5% Copper Wire
Tap 3 = 30W, Tap 4 is not used
Tap 3 = 15W, Tap 4 = 30W
Warranty 59660
Owners Manual 980-00024-00
Foam Pad (2)
991-00053-00
Packaging
Carton
990-00038-00
WHITE
3
BLUE
4
VIOLET
5
ORANGE
6
Switch
546-00003-00
Not
Used
SYSTEM COMPONENTS:
• High Frequency
Transducer:
• DC Resistance:
• Crossover Network:
AURAL SWEEP TEST SPECIFICATIONS:
A. System Aural Sweep Test:
B. L.F. Aural Sweep Test:
C. H.F. Aural Sweep Test:
PHYSICAL SPECIFICATIONS:
• Enclosure Dimensions:
• Shipping Weight:
WARRANTY INFORMATION:
• Refer to Warranty Statement packed with each product.
WIRING DIAGRAM
Speaker,
High Freq
123-00001-00
Speaker,
Low Freq
124-10000-00
BLK
SCHEMATIC CONTROL 25 (338142-001)
R1
R2
6
6
SK3
SK3
2 YEL
Transformer
1 GRN
NOTE: INDIVIDUAL PARTS FOR THE ABOVE CROSSOVER ARE NOT AVAILABLE.
A COMPLETE REPLACEMENT ASSEMBLY SHOULD BE ORDERED.
SK3 LAMP IS AVAILABLE SEPARATELY.
(cont'd)
19mm (0.75 in.) Polycarbonate
Dome Tweeter (123-00001-00)
6.7 ohm ±5% Copper Wire
338142-001
7.0V Input, 20 Hz to 20 kHz
7.0V Input, 20 Hz to 1.2 kHz
2.83V Input, 2 kHz to 20 kHz
231mm x 183mm x 140mm D
(9.5 x 7.3 x 5.6 in. D)
11 lbs. (5 kg.) (in Pairs)
(Net Weight 5lbs. Each)
BLUE
BLK
Network
338142-001
RED
BLUE
R3
C1
5
1µ5
H.F.
123-00001-00
BLK
RED
L2
1mH
L.F.
124-10000-00
C2
12µF
BLK
–
–
09-06
