Mannesmann 01730 Instruction Manual

Electric Air-pump
Item-no. 01730
I N S T R U C T I O N - M A N U A L
Before using electric power-tools, please read and
understand this manual and the attached safety-
instructions.
Intended use
With this air-pump you may inflate or deflate air-
mattresses, inflatable dhingis or swimming pools and
other big-volumed inflatable items.
The air-pump can be used in connection of the
attached 230V-AC adaptor or by connecting to the
cigarettelighter plug of your vehicle.
Important safety-notes
Always store the air-pump at a dry and safe
-
place.
Keep out of the reach of children.
-
Do not run the air-pump without inspection and
-
pay attention to the filling-hints of the product to
be inflated.
Check the air-pump carefully before use and do
-
not operate in case of any demages.
All repairs have to be undertaken by qualified
-
technicians.
Do not use the air-pump for other uses, than
-
intended.
Do not point the air-outlet to your own body or to
-
other people.
Only use the attached accessories or parts,
-
which are recommended by the dealer.
Do not try to repair the plug or power-cord of the
-
AC-adaptor by yourself.
Do not expose the air-pump to rain or humidity.
-
Protect the air-pump against direct sunlight.
-
Keep free all ventilation-openings during use and
-
do not cover the air-pump by any object. (risk of
overheating)
Discription
1. Housing
2. Main-switch
3. Inflating-nozzle
4. Deflating-nozzle
5. 12V-socket
6. 230V-AC – adaptor
7. 12V-DC connecting-cable
8. Valve adaptors
Technical specifications
Voltage:
air capacity:
operating time:
Sound pressure level (LPA)
230V AC adaptor:
input:
output: 12V / 1,6 A / 19,2 VA
Make sure, that the main-switch (2) is in position "O" ,
before connecting the air-pump to the power-supply.
Operation by AC-adaptor
•
Put the AC-adaptor (6) into the 230V-outlet.
•
Connect the cable of the adaptor to the 12V-
socket (5) on the air-pump.
Operation by car-battery 12V:
•
Place the plug of the 12V-DC cable (7) into the
socket for the cigarette-lighter of your vehicle.
•
Connect the other plug of the 12V-DC cable with
the 12V-socket (5) of the air-pump. (For the use
of the cigarette-lighter see manual of your
vehicle)
Inflating
•
Select the adequate valve-
adaptor (8), fasten on the
Inflating-nozzle (3) of the
air-pump and stick into the
valve of your inflatable item.
•
Switch the air-pump "ON"
by setting the main-switch
(2).
•
Switch "OFF" the air-pump,
after the inflatable item has
reached its required volume
and disconnect the valve-
adaptor. Place valve caps
onto the inlet-valves of the inflatable item.
7
12 V =
240 l/min
max. 20 minutes
78dB(A)
230V~/50 Hz
