AWDI712S

OPERATING INSTRUCTIONS

WASHER DRYER
Please carefully read these Operating Instructions before using the appliance!
IO-WMS-0224
(05.2016)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AWDI712S and is the answer not in the manual?

Questions and answers

Summary of Contents for Amica AWDI712S

  • Page 1: Operating Instructions

    AWDI712S OPERATING INSTRUCTIONS WASHER DRYER Please carefully read these Operating Instructions before using the appliance! IO-WMS-0224 (05.2016)
  • Page 2: Table Of Contents

    CONTENTS Basic Information........................3 Safety instructions.......................4 Install the appliance......................8 Understanding the symbols on clothes labels..............10 Display and control panel..................11 Special programmes....................14 Using the appliance....................15 Table of programmes..................16 Troubleshooting....................17 Maintenance and Cleaning..................19 Practical tips on washing..................20 Specification......................23 Service....................23 Product fiche......................24 In accordance with European Directive 2012/19/UE and Polish legislation regarding used electrical and electronic goods, this appliance is marked with the symbol of the crossed-out waste container.
  • Page 3: Basic Information

    BASIC INFORMATION Dear customer, From today, washing will be easier than ever before. Your Amica washer-dryer is exception- ally easy to use and extremely efficient. After reading these Operating Instructions, operating the appliance will be easy. Before being packaged and leaving the manufacturer, the appliance was thoroughly checked with regard to safety and functionality.
  • Page 4: Safety Instructions

    NOTES ON SAFETY Use only those detergents and additives which l Detergents are designed for automatic washing machines, especially when using the COTTON 90°C programme. Do not use any agents containing solvents, as these may damage certain parts of the appli- ance, or cause them to emit poisonous gases.
  • Page 5 NOTES ON SAFETY Unplug the appliance before preparing it for l Transport transport. Do not transport the washer-dryer if drum locking bolts are not in place. See the chapter INSTALL THE APPLIANCE (page 8). Keep the appliance in upright position when transported.
  • Page 6 NOTES ON SAFETY Do not dry clothes that have not been l Dry washed. l Do not dry chemically washed garments or clothing, where stains were removed by chemicals. l Do not dry clothes soiled with substances such as cooking oil, crude oil, acetone, alco- hol, petrol, kerosene, stain removers, turpen- tine, wax.
  • Page 7 NOTES ON SAFETY Checking stability Once the appliance is in position and levelled, it must be checked to ensure it rests firmly on all four legs. In order to check this, press down each corner of the appli- ance in turn to see if it moves. Safe, long-term and reliable operation of the appliance depends on it being correctly positioned and level.
  • Page 8: Install The Appliance

    INSTALL THE APPLIANCE I. Remove the transport protection (keep the locking bolts for future use, e.g. when moving house). Unscrew the 4 locking bolts Stop up the holes with the stoppers with a spanner. enclosed in the accessories bag. Remove the rubber and plastic transport brackets from the sockets along with the washers and bolts.
  • Page 9 INSTALL THE APPLIANCE III. Connecting the water supply Use the new hoses sup- plied with the machine. Do not re-use hoses. A supply hose with seals is inside the drum of the dryer-washer. Water pressure min 0.1 MPa (1 bar), max 1 MPa (10 bar). Supply the machine with cold water after connecting, make sure the hose is not twisted after connecting the hose and the valve, check they are sealed tight...
  • Page 10: Understanding The Symbols On Clothes Labels

    UNDERSTANDING THE SYMBOLS ON CLOTHES LABELS I. Washing normal wash normal wash DO NOT boil at 90°C at 60°C at 40°C wash! delicate handwash II. Chemical cleaning all solvents all except TRI petrol only DO NOT dry clean! III. Tumble Dryer DO NOT dry! normal high...
  • Page 11: Display And Control Panel

    DISPLAY AND CONTROL PANEL ■ ■ ■ ■ ■ ■ ■ ■ 1. Programme selector knob 2. Display 3. Temperature selector button 4. Spin speed selector button 5. Drying Level selector button 6. Delay Start additional function button 7. START/PAUSE button 5+6.
  • Page 12 DISPLAY AND CONTROL PANEL 1. Programme selector knob Choose the appropriate wash, dry or combined wash-dry programme as required, de- pending on the degree of soil, and type and amount of laundry loaded, which ensures better results and more effective washing. Once the wash programme is started, turning the programme selector knob to another position (except ) does not change the previ- ously selected programme.
  • Page 13 DISPLAY AND CONTROL PANEL 5. Drying Level selector button I. Set the drying level: You can select one of the three drying levels: a) Level 1: Iron dry — recommended for the laundry to be ironed after drying. b) Level 2: Hanger dry — recommended for the laundry to be hung on a hanger after drying.
  • Page 14: Special Programmes

    SPECIAL PROGRAMMES 1. The Allergy Safe programme: This programme is designed for washing clothes of children and people with sensi- tive skin. Main wash is carried out at a temperature of 60°C (temperature setting: 60/50/40/30/-- "cold water"), followed by four rinses. Additionally, during all stages of rinsing water is heated to 30°C.
  • Page 15: Using The Appliance

    USING THE APPLIANCE I. Select Programme 1. Set the programme selector knob to the desired programme (see the table further on). 2. In order to adapt the programme to your individual needs, you can set the tempera- ture, spin speed, set the drying level, drying time or set a delayed start. 3.
  • Page 16: Table Of Programmes

    TABLE OF PROGRAMMES Washing and Drying drying Wash programmes Programmes programmes * - standard programmes for washing cotton fabrics at 60 °C. This programme is suitable for washing normally soiled cotton fabrics. This is the most effective programme for washing these type of fabrics, taking into account the total energy and water consumption.
  • Page 17: Troubleshooting

    TROUBLESHOOTING Problem Probable cause/Solution The appliance does not work - Turn the tap on - Clean the mesh filter on the supply hose - Close the door - Press the [Start/ Pause] button Water leaks Properly connect the water intake. The load in the appliance has not - Replace the load evenly in the drum, clean the pump filter.
  • Page 18 TROUBLESHOOTING The fault indicator lights The washing machine indicates error codes to help locate minor operating faults and identify their cause. The ERROR CODES help locate and determine the cause. Detected errors are indicated as shown in the following table: Display indica- Reason Solution...
  • Page 19: Maintenance And Cleaning

    MAINTENANCE AND CLEANING Never clean the product’s casing or plastic parts using solvents or strong, abrasive detergents (e.g. washing powders or creams)! Use mild liquid detergents and soft cloths only. Do not use sponges. Clean the pump filter every 20 wash- es or so.
  • Page 20: Practical Tips On Washing

    PRACTICAL TIPS ON WASHING I. Detergents and It is recommended to use a general-purpose laundry deter- laundry additives gent powder or liquid for the full range of temperatures ac- cording to the manufacturer's instructions on the detergent packaging. Detergents Pour the detergent into the drawer compartment marked Pour the pre-wash detergent into the drawer compartment marked Liquid detergents...
  • Page 21 PRACTICAL TIPS ON WASHING IV. Conservation Reducing energy and water consumption Garments which are only lightly soiled should be washed on the QUICK WASH setting. The appliance detects partial load. For partial load, when using the Cotton programme, the appliance will reduce water and energy consumption and shorten the wash cycle.
  • Page 22 PRACTICAL TIPS ON WASHING VIII. Load The electronic control panel contains a balance control system. Before spinning, this checks the distribution of clothes inside the distribution control drum. In the event that too great an imbalance is discovered, it makes several attempts to rearrange the clothes inside the appliance.
  • Page 23: Specification

    SPECIFICATION AWDI712S - Type - Rated voltage 220-240V / ~50Hz. - Rated power 2200 W - Overcurrent protection 10 A - drum capacity (washing) max 7 kg - drum capacity (drying) max 5 kg - Water pressure min 0,1 MPa (1 bar)
  • Page 24: Product Fiche

    PRODUCT SHEET The maximum load for washing (dry clothes) (kg) The maximum load for drying [kg] Spin speed [RPM] 1200 Number of programmes Operating voltage [V] 220-240V Frequency [Hz] ~50 Hz Water pressure [MPa] min 0.1 MPa (1 bar), max 1 MPa (10 bar) Dimensions (HxWxL) [mm] 845x597x582 Energy consumption (washing, spinning,...
