OPERATING
INSTRUCTIONS
EN
IO-WMS-0477
(01.2018/1)
AWDT814S
ONLY USE THE APPLIANCE WHEN YOU
HAVE READ AND UNDERSTAND THE
WASHER-DRYER
OPERATING
INSTRUCTIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the AWDT814S and is the answer not in the manual?

Questions and answers

Related Manuals for Amica AWDT814S

Summary of Contents for Amica AWDT814S

  • Page 1 OPERATING INSTRUCTIONS IO-WMS-0477 (01.2018/1) AWDT814S ONLY USE THE APPLIANCE WHEN YOU HAVE READ AND UNDERSTAND THE WASHER-DRYER OPERATING INSTRUCTIONS...
  • Page 2 CONTENTS CONTENTS ECOLOGY IN PRACTICE BASIC INFORMATION SAFETY AND GERMENT CARE LABELS INSTALL THE APPLIANCE PRODUCT DESCRIPTION TROUBLESHOOTING PRACTICAL TIPS ON WASHING BUILT-IN INSTALLATION SPECIFICATIONS PRODUCT FICHE In accordance with European Directive 2012/19/EU and Polish legislation regarding used electrical and electronic goods, this appliance is marked with the symbol of the crossed-out waste container.

  • Page 3: Ecology In Practice

    ECOLOGY IN PRACTICE CONTENTS For many years, Amica has consistently pursued pro-ecological policy. Concern for the environment is as important for us as the use of modern technology. That's why we focus on energy-efficient appliances of the highest energy efficiency class — A+, A++ and A+++.
  • Page 4 Dear customer! Thank you for choosing an Amica product. For years we have de- livered high-quality appliances, so that household chores become a real pleasure. Before being packaged and leaving the manufac- turer, the appliance was thoroughly checked with regard to safety and functionality.

  • Page 5: Basic Information

    BASIC INFORMATION CONTENTS This appliance is intended for domestic use only to wash/dry textiles and clothes designed to be machine washed in a detergent bath. Before plugging the appliance into the mains, remove the safety packaging and ensure the machine is level. The manufacturer reserves the right to introduce changes, which do not affect operation of the appliance.

  • Page 6: Safety And Germent Care Labels

    SAFETY AND GERMENT CARE LABELS The risk of death! This appliance should not be used by children under 8 years of age, persons with reduced physical or mental capabilities, and persons who do not have sufficient skills to use this type of appliance. Such persons should be offered proper supervision or instructions on safe handling of appliance and related...
  • Page 7 SAFETY AND GERMENT CARE LABELS Risk of burns! If laundry is washed at high tem- perature, door glass becomes hot. Prevent children from touching the hot door. Eye/skin irritation! Contact with detergents and softeners may cause eye or skin irritation. In case of eye/skin contact, thoroughly rinse eyes/ skin to remove fabric detergent/ softener.
  • Page 8 SAFETY AND GERMENT CARE LABELS Risk of electric shock. The power cord and the ground- Risk of fire/damage to ed wall socket fit together and property/appliance! the grounding system has been properly installed. Power cord cross section is suf- ficient. Power plug is always accessi- ble.
  • Page 9 SAFETY AND GERMENT CARE LABELS Risk of fire/damage to The use of extension cords or property/appliance! splitters may result in fire due to overheating or short circuit. Connect the appliance directly to a properly grounded wall socket. Do not use extension cords, splitters or power strips.
  • Page 10 SAFETY AND GERMENT CARE LABELS Risk of injury! This appliance has sharp edges that can cause a hand injury. Do not hold the appliance by sharp edges. Only lift the appliance after you put on the gloves. If the hoses or electrical cables are not routed properly, you can trip and sustain an injury.
  • Page 11 SAFETY AND GERMENT CARE LABELS Important! Use only hoses supplied with Damage to property/ the appliance, or the original appliance hoses up designed for the appli- ance. The appliance is secured for transport with transit bolts. If you don’t remove transit bolts before using the appliance, the appliance may be damaged.
  • Page 12 SAFETY AND GERMENT CARE LABELS Risk of poisoning! Cleaning agents containing solvents may give off poisonous vapours. Do not use cleaning agents con- taining solvents. Risk of injury! Do not lean against/sit on open appliance door as this can lead to the appliance tipping over.
  • Page 13 SAFETY AND GERMENT CARE LABELS Eye/skin irritation! Fabric detergents and soften- ers may splash, if the detergent drawer remains open during operation. In case of eye/skin contact, thoroughly rinse eyes/skin to re- move fabric detergent/softener. In the event of accidental in- gestion, consult your doctor.
  • Page 14 SAFETY AND GERMENT CARE LABELS SAFETY AND GERMENT CARE LABELS The risk of death!! The appliance is powered by electricity. Touching live ele- ments poses a risk of electric shock. Therefore, remember: Turn off the appliance: Unplug the appliance from the wall outlet.
  • Page 15 SAFETY AND GERMENT CARE LABELS SAFETY AND GERMENT CARE LABELS Risk of poisoning! Cleaning agents containing solvents may give off poisonous vapours. Do not use cleaning agents con- taining solvents. Risk of electric shock / If water penetrates into the ap- damage to property / pliance, it may cause a short appliance!
  • Page 16 SAFETY AND GERMENT CARE LABELS Important! Make sure there is no contact with the appliance Damage to surface. property/ appliance Clean the appliance with a damp cloth only. Do not dry clothes that have not been washed. Do not dry chemically washed garments or cloth- ing, where stains were removed by chemicals.
  • Page 17 UNDERSTANDING THE SYMBOLS ON CLOTHES LABELS Washing boil at 90°C normal wash at 60°C normal wash at 40°C Do NOT wash! delicate handwash Chemical cleaning all solvents all except TRI petrol only Dry clean! Tumble dryer normal high Do NOT dry! Ironing 110°C 150°C...

  • Page 18: Install The Appliance

    INSTALL THE APPLIANCE Remove the transit bolts (keep the bolts for future use, e.g. when moving house). stop up the holes with the stoppers enclosed unscrew the 4 transit bolts with in the accessories bag. a spanner, remove the rubber and plastic transport brackets from the sockets along with the washers and bolts.
  • Page 19 Connect the water supply Use only the new hoses supplied with the machine. Do not re-use hoses. A supply hose with seals is inside the drum of the machine. Water pressure min 0.05 MPa (0.5 bar), max 1 MPa (10 bar).
  • Page 20 Connect to power supply Electrical wall outlet where the appliance is connects must be in a visible and accessible place, Only plug the appliance into a properly installed socket with an earthing pin, Do not use an extension cord to connect the appliance, in the event of the power cord being damaged, it must be replaced by an authorised service technician, the electrical system to which the appliance is to be connected...
  • Page 21 FEATURES AND COMPONENTS CONTENTS DESCRIPTION OF THE APPLIANCE 1. Detergent drawer 2. Drum 3. Control Panel 4. Door handle 5. Pump filter cover Accessories: Transport Supply hose Supply hose Drain hose Owner’s hole plug cold water hot water support manual (optional) (optional)
  • Page 22 DISPLAY AND CONTROL PANEL ■ ■ ■ ■ ■ ■ ■ ■ ■ 1. Programme button 2. Display 3. On/Off button 4. START/PAUSE 5. Button for the additional function Start delay 6. Button for the selection of the Temperature 7. Button for the selection of the Spin speed 8.
  • Page 23 Programme selector dial Choose the appropriate wash, dry or combined wash-dry programme as required, depending on the soil level, and type and amount of laundry loaded, which ensures better results and more effective washing. Once the drying programme is started, turning the programme selector knob to another position is possible, however it does not change the previously selected programme.
  • Page 24 Start delay button This function delays programme start by 0 to 24 hours Set the Delay Start function: 1. Select a programme; 2. Press the Delay start button and select time: 3. Press Start/Pauses to activate the Delay Start function. Cancel the Delayed Start Press the Delay Start button repeatedly until 0h is dis- played.
  • Page 25 6+7 Child lock The child lock blocks the function buttons, so that children cannot inadvertently change the settings. In order to activate the child lock during the washing, push the buttons (Temperature selection) and (Spin speed) simultaneously and hold them for about 3 seconds. In order to deactivate this function during the wash cycle, again push the same buttons and hold them for about 3 seconds.
  • Page 26 DESCRIPTION OF THE APPLIANCE SPECIAL PROGRAMMES Wash programme Anti-Allergy: This wash programme is intended for children and persons with sensitive skin. The main wash is always at 60°C (possible temperatur settings are 90/60/40/30/20—“cold”). Wash programme Mixed: Standard wash programme at a standard temperature of 40°C with a standard spin speed of 1000 rotations/minute.
  • Page 27 USING THE APPLIANCE Select Programme Set the programme selector turning it left or right. Customize the programme to your needs – you can change the temperature, spin speed, or enable additional features. Press the Start/ Pause button. Time Remaining To set the Time Remaining: Close the appliance door.

  • Page 28: Troubleshooting

    TROUBLESHOOTING CONTENTS Problem Probable cause/Solution Washer dryer cannot start up Door is not closed properly - restart after the door is closed - check if the clothes is stuck Door can’t be opened Washer’s safety protection design is working - disconnect the power, restart the product Water leakage The connection between inlet pipe or outlet hose is not tight - check and fasten water pipes...
  • Page 29 THE FAULT INDICATOR LIGHTS The washing machine has an alarm system, which helps solving minor problems connected with incor- rect operation by means of “ERROR CODES” indicated in the display. With the ERROR CODES you can locate the defect and establish the cause. If an error is found, the display shows information in accordance with the following table: Display Reason...
  • Page 30 TROUBLESHOOTING MAINTENANCE AND CLEANING Never clean the appliance body or plastic parts using solvents or harsh, abrasive deter- gents (e.g. washing powders or creams)! Use mild liquid detergents and soft cloths only. Do not use sponges. Clean the pump filter Clean the pump filter every 20 washes or so.

  • Page 31: Practical Tips On Washing

    PRACTICAL TIPS ON WASHING DETERGENTS AND LAUNDRY ADDITIVES It is recommended to use a general-purpose laundry detergent powder or liquid for the full range of temperatures according to the manufacturer's instructions on the detergent packaging. Detergents Pour the detergent into the drawer compartment marked Pour the pre-wash detergent into the drawer compart- ment marked...
  • Page 32 FIRST WASH Before washing for the first time, put the appliance through one high temperature cycle without a load, according to the following procedure: 1). connect the appliance to the power supply, 2). open the water valve, 3). set the programme selector dial to washing at high temperature, add a suitable detergent and press Start/Pause.
  • Page 33 WATER HARDNESS Hard water causes scale deposition. Information about water hardness is available from the nearest water works. We recommend that you use water softener for each washing. POWER OUTAGE (PROGRAMME MEMORY) Power outage or unplugging the appliance does not cancel the set programme. The programme is memorised and resumes when power is restored.
  • Page 34 DOOR LOCK The appliance is equipped with a lock which prevents the door from being opened during wash cycle. Once a wash cycle is complete, the door lock is automatically released. In order to open the door during the wash program, press PAUSE button and wait to unlock the door. If the temperature inside the drum is high, the door may remain blocked until the water temperature has dropped below 60°C.

  • Page 35: Built-In Installation

    LOAD DISTRIBUTION CONTROL BUILT-IN INSTALLATION Appendix Self-tapping screws Hinges Spacer (ST4*12) Self-tapping screws Counter magnet Fixed position (M5*12) paper Tool Screw driver Ruler Pencil Automatic driver Install steps...
  • Page 36 Overview The door is open from right to left The door is open from left to right Preparation and assembly of the door. Make the mark on the door.
  • Page 37 Fixed position paper on the door.
  • Page 38 Drill hole on the door.
  • Page 39 Installation the hinges and spacer. Installation the counter magnet.
  • Page 40 Installation the door. Warning! When installing the appliance into the kitchen ensure furniture, if possible, the hoses are placed in either of the two recesses on the back of the appliance. This will help to prevent the hoses from becoming kinked or trapped.

  • Page 41: Specifications

    SPECIFICATION CONTENTS Type AWDT814S (WMAG 8140B1BZD0W) Rated voltage 220-240V / ~50Hz Rated power 1900 W Overcurrent protection 10 A Drum capacity (washing) max. 8 kg Drum capacity (drying) max. 6 kg Water pressure min. 0.05 MPa (0.5 bar) max. 1 MPa (10 bar)
  • Page 42 PRODUCT SHEET CONTENTS Model (Condenser / Water cooled) AWDT814S (WMAG 8140B1BZD0W) The maximum load for washing (dry clothes) (kg) The maximum load for drying [kg] Spin speed [RPM] 1400 Number of programmes Operating voltage [V] 220-240V Frequency [Hz] ~50 Hz Water pressure [MPa] min 0.05 MPa (0,5 bar),...
  • Page 43 For the UK: please call 01949 862012 01 88 2010 01.2018./1...
