Teka DW8 45 S User Instructions

Hide thumbs

Advertisement

Quick Links

Download this manual
Contents
1.
Description of the controls ________________________________ 2
2.
Operating instructions ____________________________________ 9
3.
Cleaning and maintenance _______________________________ 20
4.
Troubleshooting _______________________________________ 25
Thank you for choosing one of our products.
You are advised to read this manual carefully; it contains all the
information you need use your dishwasher safely, correctly and in the
most satisfactory manner.
Following the cleaning instructions provided here will keep your
dishwasher's performance at peak levels in the long term.
USER INSTRUCTIONS: these consist of recommendations for using the
appliance, a description of its controls and of the correct cleaning and
maintenance procedures.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the DW8 45 S and is the answer not in the manual?

Questions and answers

Related Manuals for Teka DW8 45 S

Summary of Contents for Teka DW8 45 S

  • Page 1 Contents Description of the controls ________________________________ 2 Operating instructions ____________________________________ 9 Cleaning and maintenance _______________________________ 20 Troubleshooting _______________________________________ 25 Thank you for choosing one of our products. You are advised to read this manual carefully; it contains all the information you need use your dishwasher safely, correctly and in the most satisfactory manner.

  • Page 2: Description Of The Controls

    User instructions 1. Description of the controls Front panel All the dishwasher control are grouped on the front panel. Programming and option selection are only possible with the door closed. ON/OFF BUTTON SELECTION PROGRAM BUTTON PROGRAM INDICATOR LIGHTS START/PAUSE BUTTON PROGRAM STARTED/STOP INDICATOR LIGHT (*) PROGRAM DELAY BUTTON PROGRAM DELAY LIGHT...
  • Page 3 User instructions SETTING THE WASHING PROGRAM To select the most suitable program for the dishes to be washed refer to the table below, which indicates the most appropriate program according to dish type and degree of soiling. DURATION CONSUMPTION PROGRAM PROGRESS TYPE AND GRADE DIRT SELECTION...
  • Page 4 User instructions NOTES AND REFERENCES Only run the soak program with half loads. Options cannot be used with the soak program. Standard programme under EN 50242. See information sheet provided Program consumption and duration figures have been measured in accordance with the EN 50242 standard. Values may vary depending on water supply and ambient temperatures and the type and quantity of dishes loaded.
  • Page 5 User instructions Washing programs The dishwasher is equipped with a control panel and an 3-FIGURE DISPLAY (8), described in chapter “3.Description of the controls”, from which it is possible to carry out all the power switch-on, switch-off and programming operations. Before starting a washing program make sure that: •...
  • Page 6 User instructions CHANGING THE PROGRAM To modify the program keep the START/PAUSE button (4) pressed for a few seconds, until the PROGRAM STARTED indicator light (5) stops flashing, then select the new program following the instructions provided above; press the START/PAUSE button (4) again and keep it pressed for a few seconds, until the indicator light (5) starts to flash again.
  • Page 7 User instructions STARTING THE DISHWASHER After carrying out all the operations described above correctly, to start the dishwasher simply press the START/PAUSE button (4) for a few seconds until a beep sounds (the PROGRAM STARTED (5) light start to flash). The 3-FIGURE DISPLAY (8) will show the duration of the program in minutes.
  • Page 8 User instructions TO SAVE ENERGY AND PROTECT THE ENVIRONMENT • Always use the dishwasher with a full load. • Do not wash the dishes in running water. • Use the wash program that is most appropriate for each type of load.

  • Page 9: Operating Instructions

    User instructions 2. Operating instructions Once the dishwasher has been correctly installed, prepare it for use as follows: • Adjust the water softening system • Add salt • Add rinse aid and detergent Using the water softening system The dishwasher is equipped with an automatic softening system which uses a special regenerating salt to reduce the SALT...
  • Page 10 User instructions • Do not use table salt, as it contains insoluble substances which, over time, may damage the water softening system. • The salt container should be refilled before starting the wash program. This way, the excess saline solution will be immediately removed by the water;...
  • Page 11 User instructions WATER HARDNESS TABLE WATER HARDNESS SETTING German Degrees (° dH) French Degrees (° dF) 0 - 6 0 - 11 h.-1 NO SALT 7 - 10 12 - 18 h.-1 h.-2 11 - 15 19 - 27 h.-3 16 - 21 28 - 37 22 - 28...
  • Page 12 User instructions ADDING RINSE AID Rinse aid helps the dishes dry faster and prevents the formation of scale deposits and staining; it is automatically added to the water during the final rinse cycle. To add rinse aid: • Open the door. •...
  • Page 13 User instructions ADDING DETERGENT To open the detergent dispenser cap, lightly press the button P. Add the detergent and close the cap carefully. During the wash cycle, the dispenser will open automatically. • When a program with hot prewash is selected (see program table), extra detergent must be placed in the cavity G/H (depending on model).
  • Page 14 User instructions The introduction of detergent into the rinse aid dispenser, even in liquid form, will damage the dishwasher. General warnings and recommendations Before using the dishwasher for the first time, it is advisable to read the following recommendations concerning dish types and loading. There are generally no constraints on washing of domestic dishes, but in certain cases it is necessary to take their characteristics into account.
  • Page 15 User instructions WARNING! • Make sure that the dishes are securely in place so that they cannot tip over or obstruct the rotation of the spray arms during the wash cycle. • Do not place very small objects in the baskets as these could fall and obstruct the spray arms or the pump.
  • Page 16 User instructions Using the baskets The dishwasher has a capacity of 10 place-settings, including serving dishes. LOWER BASKET Used for items with a heavier degree of soiling. All types and combinations of loads are permitted, provided that the dishes, pots and pans are arranged with all the soiled surfaces exposed to the water jets coming from the bottom.
  • Page 17 User instructions BOTTOM BASKET INSERTS Some models are equipped with bottom basket inserts which improve the drying of dishes. The inserts are supplied in the accessories bag; to use them, simply fit them into place as shown. CUTLERY BASKET The cutlery should be arranged in an orderly manner inside the basket, with the handles pointing downwards.
  • Page 18 User instructions UPPER BASKET It is recommended to load the upper basket with small or medium-sized items such as glasses, small plates and saucers, tea or coffee cups, shallow bowls and light objects made from heat resistant plastic. If the upper basket is used in the lowermost position, it can also be loaded with serving dishes, provided they are only lightly soiled.
  • Page 19 User instructions ADJUSTING THE UPPER BASKET The height of the upper basket can be according to requirements and the size of the dishes in the lower basket. Pull-out adjustment system: • Turn the retainer E on both runners, right and left, through 90° •...

  • Page 20: Cleaning And Maintenance

    User instructions 3. Cleaning and maintenance Before carrying out any work, always unplug the appliance from the electrical supply or turn off the dual-pole dedicated switch. General warnings and recommendations Avoid the use of acidic or abrasive detergents. Clean the outer surfaces and door-lining of the dishwasher regularly using a soft, damp cloth or with a normal detergent suitable for painted surfaces.
  • Page 21 User instructions CLEANING THE OSCILLATING BOTTOM SPRAY ARM ● Take hold of the bottom spray arm unit and pull it upward to release. ● Separate the oscillating arm A from the spray arm B. ● Turn the oscillating arm A upside down to release the toothed wheel C by pressing the teeth D and turning them anticlockwise.
  • Page 22 User instructions CLEANING THE FILTER UNIT • The central filter should be cleaned regularly. To remove it, pull the spray arm assembly upwards. • Turn the microfilter M anticlockwise to release and extract it, then lift the stainless steel filter F. •...
  • Page 23 User instructions PROLONGED DISUSE: • Run the soak program twice in succession. • Unplug the power cord from the socket. • Leave the door slightly open in order to prevent the formation of unpleasant odours inside the wash tank. • Fill the rinse aid dispenser.
  • Page 24 User instructions If the dishes fail to dry or remain dull, check that: • The rinse aid container is not empty • The rinse aid dispenser setting is correct • The detergent used is of good quality and has not lost its effectiveness (for example, through incorrect storage, with the box left open) If the dishes show signs of streaking, staining etc., check that:...

  • Page 25: Troubleshooting

    User instructions 4. Troubleshooting The dishwasher is equipped with a self-diagnostics system that is capable of detecting and signalling a number of possible faults. TABLE OF FAULTS DETECTED BY THE SELF-DIAGNOSTICS SYSTEM FAULT DESCRIPTION The anti-flooding system (where present) has been tripped. The water level limitation system has tripped.
  • Page 26 User instructions TECHNICAL DATA 447 ÷ 449 mm Width Depth measured flush with the Free standing: 600 mm outer edge of the control panel Semi-integrated: 570 mm Height Free standing: from 850 mm to 870 mm Semi-integrated: from 820 mm to 870 mm Capacity 10 Standard place settings Water supply pressure...
  • Page 27 Misurare l’altezza del pannello comandi; fare coincidere l’indice relativo a tale valore con il profilo superiore della porta in legno; tracciare il posizionamento degli agganci porta. Measure the height of the control panel; bring the mark relating to this value into line with the top edge of the wooden door; mark the positions of the door connections. Measurer la hauteur du panneau de commandes;...
