Generac Power Systems 6500EXL Owner's Manual page 17

PARTS LIST – MAIN UNIT
Item Part # Qty Description
1 A92432 1
2 A92531 1
3 A92731 1
4 92247 1
5 92679G 1
6 94981G 1
7 65791 1
8 67451 1
9 22129 2
10 86307 4
11 25254 1
12 92609 2
13 82857 4
14 92532 1
15 90239 1
16 66476 2
17 A7433 1
18 40976 2
19 83083 1
20 81917 1
24 B4986 1
25 66825C 1
26 74908 4
27 86308B 4
28 65795 2
29 66849C 1
30 67022 1
31 84132 1
32 66386 1
33 66849 2
34 B4871 1
35 22769 1
36 86494 1
37 86292 9
38 77395 4
39 83465 4
40 78831B 4
41 80270 1
42 78299 1
43 B4363 1
44 B1998 1
45 B92039 1
Generac Portable Products 6500EXL Extended Life Generator
CRADLE
SUPPORT, Engine
SUPPORT, Engine & Muffler
HOUSING, Engine Adapter
ASSEMBLY, Rotor (Incls Item 7)
ASSEMBLY, Stator
BEARING
WASHER, M8 Flat
WASHER, M8 Lock
SCREW, 5/16-24 x 3/4 SEMS
SCREW, 5/16-24 x 9-7/8"
MOUNT,Vibration
MOUNT,Vibration
BRACKET, Muffler
GASKET, Exhaust
SCREW, M6-1 x 12 with Lock
Washer
MUFFLER
SCREW, M8 - 1.25 x 20
SCREEN, Spark Arrest
PIN, 4mm x 10 Roll
DECAL, Ground
CARRIER, Rear Bearing
TAPTITE, M5-0.8 x 10
BOLT, M6-1 x 165mm Stator
RECTIFIER, Battery Charge
TAPTITE, M5-0.8 x 30
GROMMET, Rubber
ASSEMBLY, Power Regulator
ASSEMBLY, Brush Holder
TAPTITE, M5-0.8 x 16
COVER, Bearing Carrier
WASHER, #10 Int. Shakeproof
SCREW, M6-1.0 x 16 Wing
SCREW, #10 Self Drilling
NUT, M6 Flange Lock
GROMMET,Tank
HHCS, M6-1.0 x 60, SEMS
VALVE,Tank
BUSHING, Plastic Tank
CAP, Fuel Gauge
TANK, Fuel 7 Gal Assy.
(Includes 41 & 42)
SHIELD, Heat
Item Part # Qty Description
46 92665 1
47 85000 1
48 14353621 1
49 26850 2
51 92982 1
52 96059 2
55 189160 12
57 96060 1
58 92630 1
59 NSP 1
60 22531 2
61 22142 2
62 93826 1
63 77282 1
64 22287 2
65 22097 2
66 22127 2
67 78289 1
68 B96068 1
69 56893 5
Items Not Illustrated:
B2649 1
A8927 1
37806 1
43438 1
72347 1
73111 1
84882 1
65787 1
Battery Tray Components:
22129 2
45771 2
96925 1
96924 2
15453621 1
15553621 1
96923 1
22145 2
58443 4
Optional Accessories Not Included:
84883
17
INSULATION, #2-1/4"
CLIP, Insulation
WIRE, Ground
WASHER, M6 Shakeproof
DECAL, Danger
DECAL, Heat Shield
NUT, 5/16-18 Serrated Flange
DECAL, Control Panel
ASSEMBLY, Control Box
ENGINE
SCREW, 5/16-18 x 1-3/4"
SCREW, 5//16 - 18 x 3/4"
DECAL, Start Instructions
SWITCH, Starter
SCREW, 1/4 - 20" x 3/4"
WASHER, M6 Lock
NUT, 1/4 - 20" Hex
BRACKET, Starter Switch
SHIELD, Heat
CRIMPTITE, 10 - 24 x 1/2
Generator Owner's Manual
Engine Owner's Manual
125V 30A Locking plug
240V 30A Locking plug
Spark plug
Air cleaner element
Spark plug wrench
Battery charge cable
Lockwasher, M8
Hex nut M8
Battery tiedown
J-bolt
Battery cable, positive
Battery cable, negative
Battery tray
Flat washer
Screws, battery tray
Cord Wrap
