Options Menu
Display
(Factory settings shown)
Contrast:
3
Cond Decimal:
****.*
Averaging
Off
Loop1 Adjust:
4.00 mA
Loop1 Adjust:
20.00 mA
Temp Display:
ºC
Temperature
Comp %: 2.00
Output1 Active:
Low
Test Loop 1:
Test Output 1:
Settings will repeat for Loop 2 and Output 2.
8850-3 Conductivity/Resistivity Transmitter
Adjust the LCD contrast for best viewing. A setting of 1 is lower contrast, 5 is higher. In
general, select lower contrast if the display is in warmer ambient surroundings.
>
Set the decimal to the best resolution for your application. The display will automatically
scale down to this restriction. Select *****., ****.*, ***.** **.*** or *.**** .
>
OFF provides the most instantaneous response to process changes. Select LOW (4 sec)
or HIGH (8 sec) averaging if your process experiences frequent or extreme fl uctuations.
>
Adjust the minimum and maximum current output. The display value represents the
precise current output. Adjustment limits:
>
Use this setting to match the system output to any external device.
>
Select ºC or ºF.
>
Set the percent change in Conductivity caused by a 1ºC change in temperature. May be
from 0.00 to 10.00.
>
Active HIGH: This setting is used to turn a device (pump, valve) ON at the setpoint.
> Active LOW: This setting is used to turn a device OFF at the setpoint.
Press UP and DOWN keys to manually order any output current value from
>
3.8 mA to 21.00 mA to test the output loop.
Press UP and DOWN keys to manually toggle the Open Collector output state.
>
Description
• 3.80 mA < 4.00 mA > 5.00 mA
• 19.00 mA < 20.00 mA > 21.00 mA
