User Instruction Manual
Large Counter Top
Convection Oven
These instructions cover the Burco Large Convection Ovens
BC 1/1 GN 3kW convection Oven - SKU 444443588
BC 1/1 GN 6kW convection Oven - SKU 444443589
Glen Dimplex Professional Appliances
Stoney Lane, Prescot, Merseyside, L35 2XW
Please read and
keep these
instructions
Tel: 0844 815 3755
www.burco.co.uk
WARRANTY
3 Year Parts
1 Year Labour
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Burco BC 1/1 GN 3.0 kW Convection Oven
Summary of Contents for Burco BC 1/1 GN 3.0 kW Convection Oven
- Page 1 Large Counter Top Convection Oven Please read and keep these instructions These instructions cover the Burco Large Convection Ovens BC 1/1 GN 3kW convection Oven - SKU 444443588 BC 1/1 GN 6kW convection Oven - SKU 444443589 Glen Dimplex Professional Appliances WARRANTY...
-
Page 2: Specifications
INTRODUCTION To ensure you obtain full benefits from your new oven: • Please read this instruction booklet carefully, and follow all instructions. • If you are unsure of any aspect of the installation, use or performance of your oven, please contact the after sales number shown on the back page. SPECIFICATIONS BC 1/1 GN 3.0 kW BC 1/1 GN 6.0 kW... -
Page 3: Connect To The Electricity Supply
European Directives As a producer and a supplier of cooking appliances we are committed to the protection of vironment and are in the compliance with the WEEE directive. All our electric products are labelled accordingly with the crossed out wheeled bin symbol. This indicates, for disposal purposes at end of life, that these products must be taken to a recognised collection points, such as local authority sites/local recycling centres This appliance Complies with European Community Directives (CE) for household and similar elec-... -
Page 4: Warning! This Appliance Must Be Earthed
The oven should be positioned such that it can be loaded and unloaded easily, and the controls can be operated conveniently. Important: DO NOT OBSTRUCT THE VENTILATION SLOTS IN THE BASE /SIDE AND REAR OF THE OVEN. Electrical Connection 3.0kW: Fitting a plug (if applicable) The mains lead of this oven will already be fitted with a BS1363 13A plug. - Page 5 Before Use: Operate the oven for approximately 30 minutes at the highest temperature, to remove any fumes or odour which may be emitted - this is due to oil used during manufacture, or from the oven insu- lation, but is not harmful. If your appliance is fitted with the terminal block below, for multi phase appliances please remove the links from terminals L1, L2 and L3 only.
-
Page 6: Operating The Oven
USER GUIDE DO NOT COVER THE OVEN ELEMENT OR OVEN SHELVES WITH METAL FOIL. DURING USE THE OVEN BECOMES HOT. BE CAREFUL NOT TO TOUCH HOT SURFACES. TURN OFF THE POWER SUPPLY AND REMOVE THE PLUG WHEN NOT IN USE, BEFORE CLEANING, AND BEFORE REPLACING ANY PARTS OPERATING THE OVEN Once the green ‘on’... -
Page 7: Oven Shelves
SETTING THE 120MINUTE MINDER The appliance is fitted with a 120minute timer. The timer does not control any function and its sole purpose is to notify the user that their desired time has elapsed. To set the minute minder, turn the timer control knob clockwise to your desired time. Once your set time has finished a bell will sound. -
Page 8: Troubleshooting
WARNING: IF THE THERMAL CUTOUT HAS TRIPPED, THE REASON FOR OVERHEATING MUST BE IDENTIFIED AND REMEDIED BEFORE PUTTING THE UNIT BACK INTO SERVICE. Trouble-shooting: Fault Possible Cause Remedy No power to the oven. Check supply socket is switched on. Check fuse and circuit breaker. -
Page 9: Wiring Diagram
WIRING DIAGRAM COUNTER TOP CONVECTION OVEN BURCO 3.0kW CONVECTION OVEN Wiring colour code: Bk=Black, Bn=Brown, Bu=Blue, Gn=Green or Green/Yellow, Or=Orange, W=White, Y=Yellow. COOK & HOLD POWER ON COOK & HOLD TIMER SWITCH SWITCH M.O. STAT. NEON C.&.H. NEON LIGHT SWITCH WATER M.O. - Page 10 BURCO 6.0kW CONVECTION OVEN Wiring colour code: Bk=Black, Bn=Brown, Bu=Blue, Gn=Green or Green/Yellow, Or=Orange, W=White, Y=Yellow. COOK & HOLD TIMER COOK & HOLD FIXED T‘STAT COOK & HOLD SWITCH M.O.STAT. NEON T/STAT Operating Relay C.&.H. NEON WATER SWITCH MANUAL RESET...
- Page 11 Please keep this handbook for future reference, or for anyone else who may use the appliance.
-
Page 12: Customer Helpline
Customer helpline For spares and after-sales service please contact Burco on: T: 0844 815 3755 F: 0844 815 3748 info@gdha.com Glen Dimplex Professional Appliances (A Division of Glen Dimplex Home Appliances) Stoney Lane, Prescot, Merseyside L35 2XW www.burco.co.uk 083443801 © 12.2014...
