Binatone Terrain 850 User Manual

Private mobile radio (PMR) with twin charger
Antenna

LCD Screen

- Displays the
current channel
selection and other
radio symbols.
PTT (PUSH to
TALK) button
- Press and hold to
transmit.
CALL button
- Press to send
ringing tone to
other PMR units.
MENU button
- Press to change
to switch between
modes.
UP/Down buttons
- Press to change
channels, volume and
to select settings
during programming.
1. LCD Screen
Displays Channel Number, or FM frequency.
TX Displays when transmitting a signal.
RX Displays when receiving a signal.
DCM Displays when the Dual Watch function is turned On.
DCS Displays when the Digital Code System is turned On.
CTCSS Displays when a CTCSS sub-channel is set.
VOX Displays when the VOX feature is enabled.
SC Displays when the PMR is scanning all channels.
Displays when the Key Lock feature is activated.
Mon-Fri from 8.00am to 8.00pm
Sat from 8.30am to 2.00pm
0844 557 9677 (UK only - Calls cost 7p per minute plus
your telephone company's access charge.)
/ 0818 762092 ROI or send email to us:
enquiries@binatone-support.co.uk
Channel Number. Changes from 1 to
8 as selected by the user.
CTCSS (01-38) or DCS (01-83) Codes,
as selected by the user.
Indicates the Battery charge level.
(Recharge when bars turn off).
www.binatoneglobal.com
Terrain 850
USER GUIDE
PWR (POWER)
button
- Press and hold to
turn the unit ON
or OFF.
Power charge
socket (
Headset socket (
- micro-USB socket
for charging
installed batteries
- 2.5mm headset
socket
MIC (Microphone)
Speaker
) &
)
