Alternatively, wear a discharging Wrist-strap device. (Be sure to remove it prior to applying power--this is an electric shock precaution.) Samsung Electronics...
Page 3
Always inspect for pinched, out- of-place, or frayed wiring. Do not change the spacing between components and the printed circuit board. Check the AC power cord for damage. Make sure that leads and components do not touch thermally hot parts. Samsung Electronics...
2) If tape control signal is not connected to the jig, the VCR must be operated in SP mode. 2-1-2 Servicing Jig Jig Item Part No. Connects the deck ass’y to the main PCB connecting cable. X-5 Chassis Jig 68140-500-013 Samsung Electronics...
Page 5
6. Apply power to the function PCB. touching the start and end sensor LEDs. If the tape still does not load, reset the function PCB by 7. Insert a test tape into the housing assÕy. pressing SW715. Samsung Electronics...
Page 6
CONNECTS TO THE ASS'Y MAIN CN601. CONNECTS TO THE CAPSTAN MOTOR CONNECTOR OF ASS'Y FULL DECK. CONNECTS TO THE LOADING MOTOR CONNECTOR OF ASS'Y FULL DECK. ASS'Y FULL DECK ASS'Y MAIN CN604 CN605 CN603 CN601 1 SCREW (1-3X10) 2 SCREWS (2-3X10) Samsung Electronics...
Page 7
Reference Information 2-2 IC BLOCK 2-2-1 IC601 (HD6473977) Samsung Electronics...
Page 8
Reference Information 2-2-2 IC301 (SS11501M/SS11511M) Samsung Electronics...
Page 9
Reference Information 2-2-3 IC302 (LA7416) Samsung Electronics...
Page 10
Reference Information 2-2-4 IC303 (SS23377M/SS23378M) Samsung Electronics...
Page 11
Reference Information 2-2-5 IC501 (TA1264) Samsung Electronics...
Page 12
Reference Information 2-2-6 IC502 (LA7256) Samsung Electronics...
Page 13
Reference Information MEMO 2-10 Samsung Electronics...
68 dB min (IHF A filter) Frequency response 20Hz-20KHz Power requirement 100~240V (AC 50/60 Hz) Power consumption Approx. 21 watts Operation temperature 41°F-104°F (5°C-40°C) Operation humidity 10%-75% Weight 4.4 Kg (net) Dimensions (W x H x D) 380 x 90.5 x 310 mm Samsung Electronics...
Page 15
Product Specifications and Comparison Chart 3-2 Comparison Chart FUNCTION AUDIO FRONT REAR REMOCON JUST SHUTTLE SLOW DUBBING JACK TYPE MODEL SV-A130B/CIS (SVR-600) MULTI SV-A140B/CIS (SVR-605) MULTI SV-A140B/EIS MULTI SV-A140B/SGE MULTI SV-A140B/ZAMA MULTI Samsung Electronics...
4-1 Cabinet Assembly Note : Disassemble in the order shown. Reassemble in reverse order. 4-1-1 Cabinet Top removal 1. Remove 5 screws and slide the top cabinet to the rear to remove. REMOVE 5 SCREWS Fig. 4-1 Cabinet Top removal Samsung Electronics...
Page 17
REMOVE 2 SCREWS (BH;1-3X12 YELLOW) "A" Lift up the bottom cover in the direction of arrow "A". REMOVE 2 SCREWS (BH;1-3X12 YELLOW) "A" Lift up the bottom cover in the direction of arrow "A". Fig. 4-2 Bottom Cover removal Samsung Electronics...
Page 18
2. Release 4 hooks on the top side and 3 hooks on the bottom side and then, pull the assÕy front panel to remove. RELEASE 4 HOOKS REMOVE KNOB-SHUTTLE (Top view) RELEASE 3 HOOKS (Bottom view) Fig. 4-3 Ass’y Front Panel removal Samsung Electronics...
Page 19
Disassembly and Reassembly 4-1-4 Ass’y Function-Timer removal 1. Release 5 hooks and remove the assÕy function-timder. Note : Take extreme care not to damage the PCB when removing it. RELEASE 5 HOOKS RELEASE 5 HOOKS Fig. 4-4 Ass’y Function-Timer removal Samsung Electronics...
PLAY PLAY STOP STOP MENU MENU Q-PRO Q-PRO SOFTEN SHARPEN TV/VCR SOFTEN SHARPEN TV/VCR SLOW A.DUB SLOW A.DUB PICTURE PICTURE AUDIO ADD BUTTON(AUDIO) TEST BUTTON IS HIDDEN BEHIND OF INLAY. Fig. 5-2 Remote Control Ass’y for X-7/X-8 Chassis Samsung Electronics...
Page 25
5-2-1 The number and position of test point Test point : TP02 (CTL Pulse) TP03 (H’D S/W -Trigger) TP04 (V. Envelope) TP05 (Audio out) AUDIO OUT H’D S/W -TRIGGER CTL PULSE V. ENVELOPE Fig. 5-3 The position of test point (Main PCB-Component side) Samsung Electronics...
Page 26
2) Set the tracking preset using the ÒFINE (Tracking, Fig. 5-4 Tracking preset adjustment TRK) button of remote control. REMOTE 3) After adjustment is completed, press the CONTROL PULSE REMOVE BUTTONS ÒPOWERÓ button to release. PUSH TRACKING TRACKING PUSH Fig. 5-5 Tracking preset adjustment Samsung Electronics...
Page 27
1) Simultaneously press the ÒTESTÓ button and Ò5Ó button in PB mode. This will adjust the tracking center automatically. 2) Set the tracking preset using the ÒFINE (Tracking, TRK) button of remote control. 3) After adjustment is completed, press the ÒPOWERÓ button to release. Samsung Electronics...
1) Insert an SP tape into the housing assÕy. 2) Press the ÒPLAYÓ button. 3) Press the ÒINPUTÓ button and Ò3Ó button simultaneously. 4) This will adjust the head S/W point adjustment automatically. 5) After the adjustment is completed, press ÒPOWERÓ button to release. Samsung Electronics...
Page 29
5. Apply the output of attenuator to the ANT IN ANT IN terminal of VCR. DC Voltmeter TP07 6. Set the channel of VCR to CH 2. 7. Connect DC voltmeter to TP07. 8. Adjust VR401 for DC 3.7 ± 0.1V. VR401 Main PCB (Component side) Samsung Electronics...
Page 30
Eject Cassette IN Cassette IN Unload Unload R. PS R. PS, Z-R. PS R. Slow Pinch Roller off Position Still Still, Slow, F-ADV Play PB, T-Stop, REC, Pause, F. PS, Z-FPS Stop Stop, Power off FF/REW FF, REW Samsung Electronics...
Page 31
Alignment and Adjustment MEMO Samsung Electronics...
ASSY-SH/CASE TOP;SV-A140F,IS-PAL ASSY S/C TOP SP601 AC61-22321A HOLDER-TR;POM,-,-,-,-,- SP602 AC61-22321A HOLDER-TR;POM,-,-,-,-,- Note : Location number 1, 2, 3, 21 are only for model SV-A120G/CIS(SMSC, SALSC, SUSC), SVR-600. Please, refer to the separate information for the other models combind. Samsung Electronics...
Schematic Diagrams Note For schematic Diagram - Resistors are in ohms, 1/8W unless otherwise noted. - Circled numbers refer to waveforms. Special note : Most semiconductor devices are electrostatically sensitive and therefore require the special handling techniques described under the “electrostatically sensitive (ES) devices” section of this service manual. Note : Do not use the part number shown on this drawing for ordering.
