EC700-BT Installation Guide
• 1 EC700-BT system unit
• Mounting screws for SATA drive
• Mounting screws for Mini PCIe module
• 1 Quick Installation Guide
• 1 CD disk includes:
- Drivers / Manual
Note:
The CD that came with the system contains an autorun screen to install drivers, utilities, and software
applications required to enhance the performance of the system and a user's manual for your reference.
Insert the CD into a CD-ROM drive. The autorun screen will appear. If after inserting the CD, "Autorun"
did not automatically start, please go directly to the root directory of the CD and double-click "Setup".
Please install all required drivers.
DFI reserves the right to change the specifications at any time prior to the product's release. For the latest revision and for more details
of the installation process, please refer to the user's manual on the website.
