StarBoard
FX-77/FX-63/FX-82W
User's Guide
How to Request a User's Guide
When requesting a separate copy of this user's guide, specify FXEU-051101.
Read this user's guide and carefully retain it for future reference.
Before using this product, carefully read and fully understand the safety instructions.
Store this user's guide nearby for ease of reference.
FXEU-051101

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the StarBoard FX-77 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HitachiSoft StarBoard FX-77

Summary of Contents for HitachiSoft StarBoard FX-77

  • Page 1 StarBoard FX-77/FX-63/FX-82W User’s Guide How to Request a User’s Guide When requesting a separate copy of this user’s guide, specify FXEU-051101. Read this user’s guide and carefully retain it for future reference. Before using this product, carefully read and fully understand the safety instructions. Store this user’s guide nearby for ease of reference.

  • Page 3: Notices

    StarBoard FX-77/FX-63/FX-82W Notices Reproduction or reprinting, without permission, of this manual or any part thereof is prohibited. The contents of this manual are subject to change without prior notice. Every effort has been made to ensure that this manual is complete and correct. However, should any questionable points, mistakes, etc., come to your attention, please inform the vendor.

  • Page 4: Product Assurance Provisions

    StarBoard FX-82W(Wireless) K-W033-021: Floor Stand The StarBoard FX-77 and StarBoard FX-63 and StarBoard FX-82W incorporate eBeam technology licensed from Luidia, Inc. eBeam is a trademark of Luidia Inc. Windows, Windows 98, Windows 98 SE, Windows 2000, Windows Me, and Windows XP are trademarks of Microsoft Corporation (U.S.) and in other countries.
  • Page 5 StarBoard FX-77/FX-63/FX-82W Safe Handling Safe Handling Markings and Symbols Various markings and symbols are used in this user’s guide and on this product, to ensure the safe and correct use of this product and to prevent personal injury and property damage.
  • Page 6 StarBoard FX-77/FX-63/FX-82W Safe Handling Safety Precautions Always comply with them. WARNINGS Securely insert the power plug into the Before moving this product, detach the mains. power plug and the mains lead. If it is not plugged in securely, The mains lead might be...
  • Page 7 StarBoard FX-77/FX-63/FX-82W Safe Handling Safety Precautions Always comply with them. WARNINGS Do not use a mains lead other than the Do not open or alter the cabinet of this accessory mains lead. product. If a mains lead other than the...
  • Page 8 StarBoard FX-77/FX-63/FX-82W Safe Handling Safety Precautions Always comply with them. WARNINGS In the following cases, unplug the product from the mains and ask the dealer. a. After the mains lead or power supply plug is damaged. b. After a liquid is spilled onto the main unit.

  • Page 9: Table Of Contents

    StarBoard FX-77/FX-63/FX-82W Safe Handling Careful thought was given to the cautions on this device and in this user’s guide. However, unanticipated circumstances might occur. When operating this product, users themselves must exercise caution as well as follow instructions. CAUTIONS Caution Details Page(s) Fasten the screws tightly.
  • Page 10 StarBoard FX-77/FX-63/FX-82W Contents Contents Notices ........................1 Disclaimers......................1 Product Assurance Provisions................2 1. Introduction....................1-1 1.1 Parts Check ......................1-1 1.1.1 StarBoard ........................1-1 1.1.2 Stand..........................1-2 1.2 Role of Each Part ....................1-3 1.2.1 StarBoard ........................1-3 1.2.2 Function Area......................1-4 1.2.3 Electronic Pen ......................1-4 1.3 Assembly and Setup....................

  • Page 11: Introduction

    StarBoard Software x.x User's guide (*3) (12) Warranty Sheet (*1) (3),(4),(5) is bundled only if the StarBoard FX-77(Wireless) or StarBoard FX-63(Wireless) or StarBoard FX-82W(Wireless) is purchased. (*2) (6) is bundled only if the Bluetooth Adapter is purchased. (∗3) The term “x.x.” as used in this manual denotes the same version as the software which is included with the accessories.

  • Page 12: Stand

    StarBoard FX-77/FX-63/FX-82W Introduction 1.1.2 Stand (1) Parts Name Qty. Stand vertical support Stand crossbar Stand foot with casters Board receiving bracket (left-hand version) Board receiving bracket (right-hand version) Board fixing bracket Hex socket head cap screw, with collar Hex socket head cap screw...

  • Page 13: Role Of Each Part

    StarBoard FX-77/FX-63/FX-82W Introduction 1.2 Role of Each Part 1.2.1 StarBoard (1) Digitiser (4) USB Cable Connect to the PC (for Wired Models) or Receives information regarding annotations and graphics drawn with the electronic pen, and connect to AC adaptor (for Wireless transmits this data to the PC.

  • Page 14: Function Area

    StarBoard FX-77/FX-63/FX-82W Introduction 1.2.2 Function Area There are the shortcut buttons frequently used in applications (the default settings are shown below), and you can customise the buttons as desired. Please refer to the online help for details. Symbol Description Symbol...

  • Page 15: Fasten The Screws Tightly

    StarBoard FX-77/FX-63/FX-82W Introduction 1.3 Assembly and Setup When setting up the StarBoard, keep the following in mind: • Select a level and stable position. • Do not set it up near equipment that might generate electromagnetic waves and radio frequencies (e.g. radio transmitter, television, copying machine, air conditioner).

  • Page 16: This Work Should Be Performed By At Least Two People

    StarBoard FX-77/FX-63/FX-82W Introduction (2) Board Installation Install the board on the stand assembled in step (1). Install the board according to the following procedure. Furthermore, this step should be performed by at least two people. Numbers in the diagram correspond to numbers in the parts list on page 1-2.
  • Page 17 StarBoard FX-77/FX-63/FX-82W Introduction (3) Height Adjustment The StarBoard can be positioned at six height levels. Adjust the height according to the following procedure. Furthermore, this work should be done by at least two people. (a) Remove the triangular knob screw at the bottom of each side.

  • Page 18: Before Installation, Take The Wall Material Into Consideration

    StarBoard FX-77/FX-63/FX-82W Introduction 1.3.2 Wall-Mounting Setup Method (1) Install the mounting brackets. Determine the height at which the board will be installed, and install the brackets at the positions shown in the following diagram. 1108±2mm/ 43.6±0.1inch 107mm/4.2inch Height Floor CAUTION Before installation, take the wall material into consideration.
  • Page 19 StarBoard FX-77/FX-63/FX-82W Introduction (2) Board Installation Connect each mounting bracket to the top square hole in the board receiving bracket located at the back of the board on both sides. CAUTION This work should be performed by at least two people.

  • Page 20: How To Connect When Using Projection Mode

    StarBoard FX-77/FX-63/FX-82W Introduction 1.3.3 How to Connect When Using Projection Mode (1) How to connect when using USB cable (i.e., Wired Mode) Connect the PC, projector, and StarBoard according to the following procedure. RGB Cable StarBoard Projector Power Supply (1) Connect the RGB cable to the projector’s RGB terminal, and fasten with the integral screws.
  • Page 21 StarBoard FX-77/FX-63/FX-82W Introduction (2) How to connect when using the USB wireless receiver (i.e., Wireless Mode) Connect the PC, projector, and StarBoard according to the following procedure (only if the wireless unit is purchased with the StarBoard). RGB Cable Bluetooth adaptor...

  • Page 23: Usage

    StarBoard FX-77/FX-63/FX-82W Usage 2. Usage 2.1 Basic Usage In this chapter, the basic usage of the StarBoard will be explained. Read this section carefully to learn about the StarBoard functions. 2.1.1 Preparation Prepare to use the StarBoard. (1) Insert the battery into the electronic pen.

  • Page 24: How To Use Electronic Pen

    StarBoard FX-77/FX-63/FX-82W Usage 2.1.2 How to Use Electronic Pen (1) When drawing with the electronic pen, apply force sufficient enough to cause the pen tip to sink completely into the electronic pen. When information from the pen is being transmitted normally, a slight buzzing sound is audible from the pen.

  • Page 25: Basic Operation Of Electronic Pen

    StarBoard FX-77/FX-63/FX-82W Usage 2.1.3 Basic operation of Electronic Pen In the default setting of the electronic pen, the pen tip is set to emulate the left click button of a mouse. While Windows is in operation, the following mouse operations can be performed using the pen tip button.

  • Page 26: How To Use Starboard In Projection Mode

    StarBoard FX-77/FX-63/FX-82W Usage 2.2 How to Use StarBoard in Projection Mode 2.2.1 Wired Connection (1) Connect devices following the page 1-10. (2) Power up the projector. (3) Power up PC to start up Windows. (4) Adjust the position of the projector so that the Windows screen projected by the projector is within the pen input active area (see page 1-3).

  • Page 27: Wireless Connection

    StarBoard FX-77/FX-63/FX-82W Usage 2.2.2 Wireless Connection (1) Connect devices following the page 1-11. (2) Power up the projector. (3) Power up PC to start up Windows. (4) Adjust the position of the projector so that the Windows screen projected by the projector is within the pen input active area (see page 1-3).

  • Page 29: Appendix

    StarBoard FX-77/FX-63/FX-82W Appendix 3. Appendix A. System Specifications Item Specification Product name FX-77 (Wired) FX-77(Wireless) FX-63 (Wired) FX-63(Wireless) Model No AH00086 AH00087 AH00088 AH00089 Input methods Infrared and Ultrasonic methods Interface to computer Wired USB 2.0 Wireless Bluetooth 1.1 Effective screen size (mm) 77 inches, 1,573 (W) ×...
  • Page 30 StarBoard FX-77/FX-63/FX-82W Appendix Item Specification Product name FX-82W (Wired) FX-82W (Wireless) Model No AH00090 AH00091 Interface to computer Wired USB 2.0 Wireless Bluetooth 1.1 Effective screen size (mm) 82 inches Wide, 1,831 (W) × 1,030 (H) StarBoard dimensions (mm) 2,051 (W) × 1,070 (H) × 77.5 (D)

  • Page 31: Aa Alkaline Battery

    StarBoard FX-77/FX-63/FX-82W Appendix B. Provisions of Product Warranty 1. During the free warranty service period, if a malfunction occurs during normal use, the malfunction will be corrected without charge, according to the provisions of the warranty. Furthermore, if the customer registration card accompanying the warranty is not returned to our company, the customer information will not be registered;...
  • Page 32 StarBoard FX-77/FX-63/FX-82W Appendix (8) In the event of a malfunction in this product caused by the connection to this product of equipment other than the equipment specified by our company. (9) In the event that there is no abnormality in this product, but a defect in a part other than this product was detected or remedied.
