  • Page 1 AION CONTROLLER User Manual pdf version of the manual available for download: www.slidekamera.com...
  • Page 2: Table Of Contents

    Before you start your work with the controller SLIDEAION IQ we strongly recommend to read the manual carefully. On the margins you will find information, which complement the Please note that using the controller in a manner inconsistent with contents of the manual. the instructions, any unauthorized repair attempts or any kind of They are not essential for the correct modification of the device can cause a damage the manufacturer...
  • Page 3: Aion Tm Iq Controller

    1. AION IQ controller Front panel of the controller is equipped a joystick and two knobs to adjust: SPEED and DAMPING. SPEED knob allows to adjust speed range, whereas DAMPING knob regulates smooth acceleration and deceleration of movement, ie. the user can adjust the time at which the drive reaches the desired speed or stops.
  • Page 4: How To Operate The Aion

    2. How to operate the AION IQ controller After you switch the power on the startup screen will appear on LCD for about IMPORTANT! 1,5s. Before the first use of the drive it is necessary to perform auto- 2.1. Specifying startup parameters matic calibration of the driving After switching the power on it is necessary to determine the working mode of motor.
  • Page 5: Free (No Limits)

    As soon as the user sets the reference points, a message on LCD appears that the drive is ready for work. After pressing OK (understood as pressing the joystick) the main menu appears on the screen. Driver ready press 2.1.3. FREE (no limits) IMPORTANT! When working with the drive in In case of FREE working mode, there are no limits as to the movement...
  • Page 6: Driving Motor Automatic Calibration

    IMPORTANT! Vin=9.8V L 1276.1mm V”: means that the battery voltage is too low. Replace the battery immediately in order to avoid to a sudden stop of the drive, which may result in damage to the equipment. t”: (Thermal Warning) indicates temperature warning. Turn off the drive immediately so as not to overheat the driving motor.
  • Page 7: Freeride

    2.2.2.1. Free Ride Free Ride mode allows the user to control the speed of the cart using joystick and adjusting knobs. SPEED knob sets the maximum speed desired by the user. DAMPING knob is used to determine the time at which the drive reaches the desired speed or stops, what allows to achieve very smooth acceleration and deceleration of the cart.
  • Page 8: Recording

    FREE Mode FreeRide -271.9 Selecting FREE Mode the user does not determine any reference points, the- refore the position at which the cart stands at that moment is marked as „0” (starting point). From that starting point, any position to the left is determined as a negative number whereas any position to the right, as a positive number.
  • Page 9: Video Loop

    [Recording] Playback > [Playback] No Records When you select [Playback] there will be a message displayed on the screen: Go Home?”. The controller requires the user decision whether the cart should return to the position where the recording of movement started (->...
  • Page 10: Timelapse

    2.2.3. TIMELAPSE TIMELAPSE program is designed for interval shots synchronized with the mo- vement of the cart (Motion Timelapse). Shutter release cable connected to the socket on driving motor enables to synchronize the drive with the camera. After entering TIMELAPSE program the user has to set the parameters below:: Mode –...
  • Page 11: Animation

    71.1 0h10min Shot: 8/250 ACurrent position of the cart [1] Time remaining to the end of the track [2] Number of currently taken shots /number of shots to capture [3] 2.2.4 ANIMATION ANIMATION allows to program track of the cart during which the drive take series of photos (the drive will trigger the shutter release itself through a cable connected to the camera).
  • Page 12 After the user determines the desired starting position, information about cur- rent parameters will appear on the LCD. In order to start, move the joystick in a direction you selected earlier. After the first step, move the joystick again to initiate another steps.
  • Page 13: Terms Of Warranty

    3. Terms of warranty IMPORTANT! All Slidekamera products are covered manufacturer’s warranty for a period of 12 months from the date of sale. Warranty covers any design faults or of PLEASE NOTE: Any package sent at the expense of HET-CNC s.c., the material of the product which resulted in the product malfunctioning.
