Supplied items

Before using the sound bar, make sure you have received all of the following items.
Sound bar (ATS-1060)

Preparing the remote control

Remove the battery's insulating strip before
attempting to use the remote control.
Remote control
A CR2025 Lithium battery
has already been inserted
into the remote control.
Owner's Manual

Installation

ATS-1060 Quick Start Guide
Power cable
Battery's insulating strip
Quick Start Guide
(This sheet)
Keys
Optical digital audio cable
Mounting template
Use when mounting the sound bar on a wall
Install the sound bar on the TV stand, etc.
The sound bar can also be mounted on a wall, using the included
mounting template and commercially available screws. Refer to the
Owner's Manual for additional installation instructions.
Caution
• Do not stack the sound bar and a BD player or other device directly on each other.
Doing so may cause a malfunction due to vibrations.
— 1 —
UA
EN
Analog audio cable
(RCA plug (L/R)-3.5 mm
mini plug cable)
Spacers × 2
Use when mounting the
sound bar on a wall
Manual Development Group
© 2016 Yamaha Corporation
Published 06/2016 KS-A0
ATS-1060/UA/qsg
