Tightening Torque - Case 445/M2 Service Manual

36
ENGINES

TIGHTENING TORQUE

COMPONENT
Screw M8 for fastening cylinder barrel lubricating nozzles
Screw M12 for fastening output shaft caps
Screw M8 for fastening camshaft longitudinal retaining plate
Screw M8 for fastening camshaft gear
Screw M11 for fastening connecting rod caps Screw M11 for fastening connecting rod caps
ED. FEBUARY 2003
SECTION 4 − OVERHAUL AND TECHNICAL SPECIFICATIONS
st
1 stage
nd
2 2 stage stage
rd d
3 stage
st
1 1 stage stage
nd d
2 stage
TORQUE
Nm kgm
15 ± 3 1.5 ± 0.3
50 ± 6
5 ± 0.6
80 ± 6 8 ± 0.6
90º ± 5º
24 ± 4 2.4 ± 0.4
36 ± 4 3.6 ± 0.4
60 ± 5 6 ± 0.5
60º ± 5º
