E NG I NE S

OIL VAPOUR RECIRCULATING SYSTEM

Figure 3
On the tappet cap (3) there is a valve (1) whose duty is to condense oil vapour inducing these to fall down because of gravity,
to the Tappet cap underneath.
The remaining non−condensed vapours shall be properly conveyed through the breather pipe (2), by suction as an example
(connection towards these vapours shall be designed by the Engineer).
ED. FEBUARY 2003
1. Valve − 2. Breather pipe − 3. Tappet Cap
SECTION 1 − GENERAL SPECIFICATIONS
1
2
3
7
003240t
