- Page 1 RocketStor 6351A Thunderbolt™ 2 Multi-Function Adapter Quick installation Guide V1.00...
-
Page 2: Table Of Contents
4.2 Connecting the RocketStor 6351A (RS6351A) ..6 4.3 Driver installation ..........6 5. Using the Storage disk with RocketStor 6351A ... 11 5.1 Initializing new storage under Mac OS X....11 5.2 Initializing new storage under Windows ....12... -
Page 3: Highpoint Rocketstor 6351A
1. HighPoint RocketStor 6351A The RocketStor 6351A Thunderbolt™ 2 Multi-Function Adapter is the industry's most versatile Thunderbolt™ connectivity solution! Ready for High-Speed Storage & Peripherals - 2x 5Gb/s USB 3.0 ports + 1x 6Gb/s eSATA ports Daisy Chain - Dual Thunderbolt™... -
Page 4: System Requirements
2. System Requirements Apple Mac or PC System with Thunderbolt™ support Operating System: Mac OS X 10.9 or higher Windows 7 or higher 3. RocketStor 6351A Hardware Front side:... -
Page 5: Setup Procedures
Back side: RocketStor 6351A 4. Setup Procedures 4.1 What’s in the box RocketStor 6351A Power Adapter Quick Installation Guide ... -
Page 6: Connecting The Rocketstor 6351A (Rs6351A)
4.2 Connecting the RocketStor 6351A (RS6351A) Steps: 1) Connect the Power Adapter to the RocketStor 6351A. 2) Connect the RocketStor 6351A to the host system using a Thunderbolt™ cable. 4.3 Driver installation 1) Driver Installation: Mac OS X OS X includes driver support for the RocketStor 6351A and will automatically recognize the device after booting up. - Page 7 2) Enable the Apple device charging support RocketStor 6351A can support Apple iPhone or iPad device charging under Mac OS X. To enable the device charging, it is Please visit required to install the driver. http://www.highpoint- tech.com/USA_new/series_RS6351A-resources.htm, download and install the HighPoint RocketStor 6351A Charging Support driver: Double click the .dmg file to extract the package.
- Page 8 Follow the on screen instruction to complete the driver install. Once the installation is completed, the RocketStor 6351A can support Apple device installation now. 3) Driver Installation: Windows a. Boot up the Windows operating system. b. Make sure the host system’s Thunderbolt™ driver has been installed.
- Page 9 USB audio controller and two USB 3.0 controller as shown below: d. Please visit http://www.highpoint- tech.com/USA_new/series_RS6351A-resources.htm the latest Windows driver package. Download and unzip the driver package.
- Page 10 e. Double click the setup program and follow the on screen instruction to complete the installation.
-
Page 11: Using The Storage Disk With Rocketstor 6351A
5. Using eSATA and USB drives with the RocketStor 6351A Any previously used eSATA/USB disk attached to the RS6351A will be recognized automatically. 5.1 Initializing new storage under Mac OS X. 1) After a new disk is installed, OS X will display a pop-up window with options to initialize, Ignore or Eject. -
Page 12: Initializing New Storage Under Windows
After the new storage drive is erased, the new storage volume icon will be found on the desktop and finder as a new disk volume. 5.2 Initializing new storage under Windows After a new disk is installed, open the Windows Disk Management utility. - Page 13 2) Create and format new partition on the new disk. After the New partition is formatted, the new storage drive can be found under My Computer. Note: The RS6351A supports Thunderbolt™ power management. While the RS6351A is connected to the host system using the Thunderbolt™...
-
Page 14: Support Information
6. Support information If you encounter any problems while utilizing the HighPoint RocketStor 6351A, or have any questions about this or any other HighPoint Technologies, Inc. product, feel free to contact our Customer Support Department. Web Support: http://www.highpoint-tech.com/websupport/ Thunderbolt Support: Phone: (408)240-6108 Skype: HighPoint.Thunderbolt...
