4. 4. 4. 4. Configure

Configure Configure Configure
parameters: work mode，source IP, source port， net mask， gateway， UART baud rate， destination IP， destination
port.
Configure command is 24byte length.
Pull down CFG pin change the module into configuration mode when use UART to config.
4.1 4.1 configure configure command command
4.1 4.1 configure configure command command format
Configure mode UART interface: 9600bps,n,8,1
part
prefix
destination IP
destination port
Host IP
Host port
Gateway
Work mode
baud rate
Reserved
checksum
Full example：00 A8 C0 2A 20 07 00 A8 C0 8C 4E C9 00 A8 C0 01 00 C2 01 00 B9
* once in configure mode, the UART parameter change to 9600bps,n,8,1, and a 'U' ascii character is send out to
ensure the control MCU that in the configure mode. If the 24byte command has effect ，a 'K' ascii character is send
back to control MCU. If configure command format error, an 'E' character will be send back to control MCU. If the
error is the checksum not match , the 1byte right checksum will be send back to control MCU also.
Jinan USR Technology Co., Ltd.
RS232 Serial TTL UART TO Ethernet TCPIP convert Module
format format
format
bytes description
2 0x55 0xAA
4 destination IP
2 Destination port
4 The IP module hold
2 TCP/UDP source port
4 Gateway IP
0x01: TCP Client
1 0x00: UDP
0x02: UDP Server
3 UART baud rate
1 Reserved
Sum(destination
destination port, host IP,
1
host port, gateway, work
mode, baud rate, reserved)
example
0x55 0xAA 0x55 0xAA
192.168.0.201 0xC9 0x00 0xA8 0xC0
8234 0x2A 0x20
192.168.0.7 0x07 0x00 0xA8 0xC0
20108 0x8C 0x4E
192.168.0.201 0xC9 0x00 0xA8 0xC0
TCP mode 0x01
115200 0x00 0xC2 0x01
00 0x00
IP,
0xB9 0xB9
Page 10 of 26
www.usr.cn
