SHIVAKI
WALL MOUNTED SPLIT-TYPE AIR CONDITIONERS
SERVICE MANUAL
Models
SSH-I076BE/SRH-I076BE
SSH-I096BE/SRH-I096BE
SSH-I126BE/SRH-I126BE
CONTENTS
1. IMPORTANT NOTICE
2. OPERATION DETAILS·······································3
3. WIRING DIAGRAM
4. EXPLOSION VIEW AND PARTS LIST·············12
No.TE150107
···································2
············· 11
Advertisement
Related Manuals for Shivaki SSH-I076BE
Summary of Contents for Shivaki SSH-I076BE
- Page 1 SHIVAKI WALL MOUNTED SPLIT-TYPE AIR CONDITIONERS SERVICE MANUAL No.TE150107 Models SSH-I076BE/SRH-I076BE SSH-I096BE/SRH-I096BE SSH-I126BE/SRH-I126BE CONTENTS 1. IMPORTANT NOTICE ···································2 2. OPERATION DETAILS·······································3 3. WIRING DIAGRAM ············· 11 4. EXPLOSION VIEW AND PARTS LIST·············12...
- Page 2 Air Conditioner Service Manual IMPORTANT NOTICE This service manual is intended for use by individuals possessing adequate backgrounds of electrical, electronic and mechanical experience. Any attempt to repair the appliance may result in personal injury and property damage. The manufacturer or seller cannot be responsible for the interpretation of this information, nor can it assume any liability in connection with its use.
- Page 3 Air Conditioner Service Manual Operation Details Remote controller TEMP UP button Increase the temperature or time by 1 unit. TEMP DOWN button Decrease the temperature or time by 1 unit. ON/OFF button FEEL SPEED To switch the conditioner on and off. AUTOQUIET COOL POWERFUL...
- Page 4 Air Conditioner Service Manual Electronic controller NOTES: RT-------Room Temperature. IPT------Indoor Pipe Temperature. ST------indoor Setting Temperature. OPT---Outdoor Pipe Temperature. CRT---Compensated Room Temperature 1. Automatic mode 1) The initial RT determines A/C working mode and setting temperature (ST), the mode is determined effective only once unless A/C shut-down then re-started.
- Page 5 Air Conditioner Service Manual RT－ST 1 °C 2 °C 4 °C Figure 1 Cooling automatic airflow When the temperature change leads the fan speed variation, the switch can only be made orderly, and every grade of air flow speed runs 1 minute at least. 2.
- Page 6 Air Conditioner Service Manual During defrosting, the signals of on-off, timing, sleep, fan speed and swing will be responded, but the fan speed and swing should be in accordance with Cold Air Prevention rules. Except the above signal processing during defrosting, no other signals will be dealt with, but only a voice buzz.
- Page 7 Air Conditioner Service Manual runs for 120 min (accumulated), the machine runs into defrosting automatically and last for 10 min. Option 3: Without jumper JC, but with OPT outdoor sensor While heating, when the temperature of condenser is lower than E °C (-4°C), and the compressor runs for 45 min (accumulated), then the machine runs into defrosting and lasts for 10 min.
- Page 8 Air Conditioner Service Manual a. the compressor stops b. RT≥27°C; c. IPT≥50°C d. indoor fan stops。 e. running into sleeping function 5. Fan mode 1) Indoor fan motor is running at setting speed (the speed is same as that of heating). 2) Vane motor control: running according to the setting condition.
- Page 9 Air C Conditioner Se ervice Manual will ring s, after this operation, the auto rest tart function is activated three time 3) To cl ose auto res start function n while it is activated, re epeat proces ss as above 2), the buzz zer will ring four time...
- Page 10 Air Conditioner Service Manual 2) The following table shows the fault protections. When failures happens, the PCB alarms and buzzer rings three times. Failure code appears, and the PCB operates protection procedures. Failure code: For the machine with LED display, the code shows on LED, for machine without LED, the code reflects by the running light.
- Page 11 Air Conditioner Service Manual WIRING DIAGRAM MODEL: SSH-I076BE/SRH-I076BE, SSH-I096BE/SRH-I096BE, SSH-I126BE/SRH-I126BE INDOOR UNIT: OUTDOOR UNIT...
- Page 12 Air Conditioner Service Manual EXPLOSION VIEW Mode: SSH-I076BE, SSH-I096BE, SSH-I126BE INDOOR UNIT:...
- Page 13 Air Conditioner Service Manual Indoor Unit- SSH-I076BE Part No. Part Name Q’ty Remark 1080030003 Installation Plate 1080320807AC Base 1070020017AA Cross Fan 1070100010 Bearing Mount 211205977A Evaporator 1070251833AP Water Drainage Assembly 1070321035 Vertical Vane Assembly 1070251372AE Face Frame 1070321022AC Screw Cover...
- Page 14 Air Conditioner Service Manual Indoor Unit- SSH-I096BE Part No. Part Name Q’ty Remark 1080030003 Installation Plate 1080320807AC Base 1070020017AA Cross Fan 1070100010 Bearing Mount 211205977A Evaporator 1070251833AP Water Drainage Assembly 1070321035 Vertical Vane Assembly 1070251372AE Face Frame 1070321022AC Screw Cover 1070250106 Air Filter 1070252211...
- Page 15 Air Conditioner Service Manual Indoor Unit- SSH-I126BE Part No. Part Name Q’ty Remark 1080030008 Installation Plate 1080320806AC Base 1070020026AA Cross Fan 1070100010 Bearing Mount 1110050067 Evaporator 1070321076AC Water Drainage Assembly 1070321035 Vertical Vane Assembly 1070321678AE Face Frame 1070321022AC Screw Cover 1070320109 Air Filter 1070252211...
- Page 16 Air Conditioner Service Manual EXPLOSION VIEW MODEL: SRH-I076BE, SRH-I096BE,SRH-I126BE OUTDOOR UNIT:...
- Page 17 Air Conditioner Service Manual Outdoor Unit- SRH-I076BE Part No. Part Name Q’ty Remark Optional 1071990038 Grille 1081990014 Top Cover 211200850AA Condenser 1081990018 Outdoor Motor Supporter 1170040062 Outdoor Motor 1070030006A Propeller Fan 1081990011 Left Grille Supporter 1081990016 Front Plate 1071990044 Fan Guard 211206798 Compressor And It Accessories 1120110016...
- Page 18 Air Conditioner Service Manual Outdoor Unit- SRH-I096BE Part No. Part Name Q’ty Remark Optional 1071990038 Grille 1081990014 Top Cover 211201000 Condenser 1081990018 Outdoor Motor Supporter 1170040062 Outdoor Motor 1070030006A Propeller Fan 1081990011 Left Grille Supporter 1081990016 Front Plate 1071990044 Fan Guard 211201021 Compressor And It Accessories 1120110016...
- Page 19 Air Conditioner Service Manual Outdoor Unit- SRH-I126BE Part No. Part Name Q’ty Remark Optional 1071990039 Grille 1080320105 Top Cover 211200353 Condenser 1080050004 Outdoor Motor Supporter 1170040058 Outdoor Motor 1070030051AA Propeller Fan 1080050001 Left Grille Suppoeter 1080320113 Front Plate 1080320112 Fan Guard 1100160012 Compressor And It Accessories 1120110016...
