USER MANUAL - RPH8000 HEADPHONE AMP Welcome Thank you for choosing Hill Audio for your sound system. To make sure that this product meets your expectations and provides long-term, reliable performance, please read and follow this instruction manual carefully. Manual Language This user manual is written in English. -
Page 3: Health Advice
USER MANUAL - RPH8000 HEADPHONE AMP Description The RPH-8000 is an 8-way headphone amplifier with 2 inputs assignable to 8 outputs. Each output offers dual front/rear TRS headphone jacks and a direct input, plus a stereo/mono configuration switch. Level meters for all inputs and outputs make the status easily visible. This unit is suitable for a variety of studio and installation purposes. -
Page 4: Controls And Connections
USER MANUAL - RPH8000 HEADPHONE AMP Controls and Connections Connections - Rear Controls - Front PAGE 3... -
Page 5: Functional Description
USER MANUAL - RPH8000 HEADPHONE AMP Functional Description The RPH-8000 is an 8-way headphone amplifier with 8 high-power heapdhone amplifiers assignable to 2 individual inputs. Each ouput has a mono/stereo switch and a LED level meter. Dual front/rear connections and a direct input feature make this unit suitable for a large variety of applications in recording, live sound and installation environments. -
Page 6: Technical Specifications
POWER switch. Switches the unit on and off. Make sure to switch the unit off when not in use. Connections The RPH-8000 uses the below connector types, for which the pin assignment must comply with the following specification. Always make sure to use good connectors and cables to ensure proper opera- tion. -
Page 7: Operation
USER MANUAL - RPH8000 HEADPHONE AMP Operation A. Connections For connecting this unit to AC mains, please note: Check whether the AC mains voltage and frequency is the same as this product is specified for (see rear panel of product). Whenever the specified voltage or your AC plug should not match the local conditions, do NOT plug the AC cord into the wall outlet and contact you dealer immediately. -
Page 8: Ec Declaration Of Conformity
Burnham-on-Crouch, 26.04.2017 Place and date of issuing Authorized Signature www.hill-audio.com Hill Audio products are developed, manufactured and distributed by Adelto Technologies Unit 2A Springfield Road, Springfield Industrial Estate, Burnham-on-Crouch, Essex CM08UA, England www.adelto.com | sales@adelto.com...
