Chapter 4: Battery Test - Midtronics EXP-717 Instruction Manual

The tester will guide you through the steps of selecting your battery test parameters and interpreting
the results. Before you start the test, review the instructions in Chapter 3: Test Preparation.
1. Select the battery LOCATION.
1 OUT OF VEHICLE
2 IN VEHICLE
Press the NEXT soft key to continue. The BACK soft key returns you to the Main Menu at the
start of the test and to the previous screen as you progress.
2. Select the Ah value
Read the value from the battery and confi rm with ENTER. Press the UP/DOWN ARROW or
enter the value with the keypad.
3. Select the BATTERY TYPE.
1 REGULAR
2 VRLA
3 SPIRAL
4 GEL
Press the NEXT soft key to continue.
4. Select the BATTERY STANDARD
1 CCA
2 JIS
3 DIN
4 SAE
5 IEC
6 EN
Press the NEXT soft key to continue.
