- Page 1 PERFORMANCE MADE SMARTER Product Manual 4590 ConfigMate USB communications interface T E M P E R AT U R E I . S . I N T E R FA C E S CO M M U N I C AT I O N I N T E R FA C E S...
- Page 2 6 Product Pillars to meet your every need Individually outstanding, unrivalled in combination With our innovative, patented technologies, we make signal conditioning smarter and simpler. Our portfolio is composed of six product areas, where we offer a wide range of analog and digital devices covering over a thousand applications in industrial and factory automation.
-
Page 3: Table Of Contents
Connection of ConfigMate 4590 to a PR 4000/9000 Device....... . . -
Page 4: Warning
Warning - risk of electrical shock To avoid risk of electrical shock and injury: • Do not disconnect the cable from ConfigMate 4590 while cable is connected to a SYSTEM 3000 device. • Do not remove 4501 while the cable is connected to a SYSTEM 3000 device. -
Page 5: Safety Instructions
Only technicians who are familiar with the technical terms, warnings, and instructions in the manual and who are able to follow these should connect the device. Should there be any doubt as to the correct handling of the device, please contact your local distributor or, alternatively, PR electronics A/S www.prelectronics.com Battery replacement Replace batteries with 3 x 1.5V TYPE AAA (not included). -
Page 6: Application
• The 4590 can operate as a docking station for the 4501/4511 allowing the 4501/4511 to be connected to a PC through a USB interface. The PReset software can be used to upload and download the configuration parameters from a 4501/4511 for backup/restore and documentation purposes, on selected 3000, 4000 and 9000 series devices. -
Page 7: Connection Of Configmate 4590 To A Pc In Docking Mode
Connection of ConfigMate 4590 to a PC in Docking Mode Connection of ConfigMate 4590 to a PR 4000/9000 Device Note: By default, the Programming Display 4501 / Communication Enabler 4511 will display the desired process value when connected to a device, either directly or via ConfigMate 4590. -
Page 8: Adaptor Mode
Technical characteristics The PC program PReset ver. 6.0 or higher supports ConfigMate 4590. To conserve power on a laptop, the USB connector of the 4590 can be connected to an externally supplied hub. The communications connector on the PR device is galvanically isolated from the USB connection on the PC. -
Page 9: Installation Of Preset
Configuration of USB communication in PReset 1. Start the PReset program and choose [Tools] [Select COM port], and the ”Options” window is shown on screen. 2. Select the COM port assigned to 4590 ConfigMate (shown as "USB Serial Port"). Click OK. 4590V101-UK... - Page 10 We are near you, all over the world Our trusted red boxes are supported wherever you are All our devices are backed by expert service and a 5-year business with a global reach. This means that we are warranty. With each product you purchase, you receive always nearby and know your local markets well.
