DELIVERY ACCESS

First, locate the dimensions of your spa on the following chart. The
dimensions shown are the measurements of the spa in the vertical
position, laid on its side.
Next, contact your dealer to find the height and width added by
the delivery cart which the dealer will use to deliver your new
spa. Use the height of the cart plus the dimension shown as H to
determine the vertical clearance required to pass the spa and cart.
Use the width of the cart, or dimension W, whichever is greater, to
determine the maximum width of clearance necessary.
NOTE: It may be necessary to allow for additional over-head
clearance if the spa will be rolled up or down an incline or moved
up or down a short flight of stairs.
Use the information below to determine the requirements for
access to your desired location.
Model
Excursion
Solstice
Accent
Calistoga
™
Azure
Tristar
Cascina
™
Monterey
How is your width clearance?
Check all gates
Protruding electric meters
Gas meters
A/C units
Do you have sufficient
overhead clearance?
Check low roof eaves,
overhanging branches,
rain gutters
Is the path clear?
Move away branches, dog
houses, firewood, etc.
If there is a 90 turn, can we
clear it? (The spa will not bend)
No more than 6 consecutive
stairs without a landing
x
Width W
34"
34"
33"
34¼"
33"
31"
31¾"
34"
BACK YARD
Page 3 Page x
Length L
6'5"
6'5"
5'3"
6'6"
5'3"
6'
5'2"
6'5"
HOUSE
STREET
Pre-Delivery Instructions
Height H
7'3"
7'3"
6'9"
6'6"
6'9"
6'
5'10"
7'3"
x
