Congratulations on your decision to purchase a Freeflow spa.
Welcome to the growing family of Freeflow spa owners.
Pre-Delivery Instructions
Please take the time to read this booklet carefully, as it will provide you with the information you will need to ensure
the safe, secure, and timely installation of your new spa. The following sections are guidelines on how to prepare for
delivery and set-up of your new spa. Specifically covered are site selection, delivery access, ground preparation, and
Remember to carefully review the Owner's Manual that accompanies your spa, and to register the spa's warranty
within 10 days of delivery at freeflowspas.com/warranty.php The Owner's Manual can be found in the Owner's
Package which has been attached to the filter ring of your spa.
Watkins Manufacturing Corporation reserves the right to change features, specifications and design without
notification and without incurring any obligation.
DATE PURCHASED: _________________________________________________________________
DATE INSTALLED: ___________________________________________________________________
DEALER: ___________________________________________________________________________
ADDRESS: __________________________________________________________________________
TELEPHONE: _______________________________________________________________________
In most cities and counties, permits will be required for the installation of electrical circuits or the construction of
exterior surfaces (decks and gazebos). In addition, some communities have adopted residential barrier codes which
may require fencing and/or self-closing gates on the property to prevent unsupervised access to a pool (or spa) by
children under 5 years of age. Your spa is equipped with a locking cover that meets the ASTM F1346-91 Standard
for Safety Covers and as a result, is usually exempt from most barrier requirements. As a general practice, your local
Building Department will inform you of any applicable barrier requirements at the time a permit is obtained for the
installation of an electrical circuit. Your dealer can provide information on which permits may be required.
x
Freeflow Spa Pre-Delivery Instructions
Page x
x

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Excursion and is the answer not in the manual?

Questions and answers

Summary of Contents for Freeflow Spas Excursion

  • Page 1 Congratulations on your decision to purchase a Freeflow spa. Welcome to the growing family of Freeflow spa owners. Pre-Delivery Instructions Please take the time to read this booklet carefully, as it will provide you with the information you will need to ensure the safe, secure, and timely installation of your new spa.
  • Page 2 Site Selection and Preparation IMPORTANT: Site selection and preparation are your responsibility. Carefully read these instructions and consult your authorized dealer if you have any questions. You probably have a spot picked out for your new spa, whether it’s indoors or outdoors, on a patio or on a deck. Just make sure you check the following: • Always put your spa on a structurally sound, level (within ½" per 10') surface. A filled spa can weigh a great deal.
  • Page 3 Use the information below to determine the requirements for access to your desired location. Model Width W Length L Height H Excursion 34” 6'5” 7'3” Solstice 34” 6'5” 7'3”...
  • Page 4 It may be necessary to remove a gate, part of a fence, or other movable obstructions in order to roll the spa to its installation site. About ten percent of the time, a crane is the only way to install the spa by lifting it to its final destination. If the spa has to be taken off of the cart to go over a wall (either because the entry area is too narrow, the eaves are too low, the corner is too tight, or the stairway is too steep), a crane will be required.
  • Page 5 Excursion, Solstice & Monterey Excursion Dimensions NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions. (Front view) 34” DOOR 24” 2” 21” ELECTRICAL 25” DRAIN 50.5” 54.5” 6’5” (Bottom view) 7’3” DOOR SIDE Page 5...
  • Page 6 Accent & Azure Dimensions NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions. (Front view) 33” DOOR 25” 3” 10” ELECTRICAL 15.5” DRAIN 33” 36” 5’3” (Bottom view) 6’9” DOOR SIDE Page 6 Page x Pre-Delivery Instructions...
  • Page 7 CALISTOGA Calilstoga Dimensions NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions. (Front view) 34 1/4” DOOR 25” 2” 4” 4” DRAIN ELECTRICAL 25.5” 6’6” (Bottom view) DOOR SIDE Page 7 Page x Pre-Delivery Instructions...
  • Page 8 Tristar Tristar Dimensions NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions. (Front view) 31” DOOR 25” 3” ELECTRICAL DRAIN 4.5” 4” 25.5” (Bottom view) 2’10” DOOR SIDE Page 8 Page x Pre-Delivery Instructions...
  • Page 9 Cascina CASCINA Dimensions NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions. (Front view) 31¾” DOOR 22” 13” ELECTRICAL 28” DRAIN 49” 54” 5’10” (Bottom view) 5’2” DOOR SIDE Page 9 Page x Page x Pre-Delivery Instructions...
  • Page 10 ELECTRICAL REQUIREMENTS To ensure you will have an opportunity to use your spa soon after delivery, it is very important that the required electrical service has been installed. Unless otherwise stipulated by your dealer, THIS IS YOUR RESPONSIBILITY. IMPORTANT: All electrical circuits must be installed by a qualified, licensed electrician. Freeflow spas‚ are available as 110/230 volt convertible heating systems. These models come standard from the factory with 110 volt heating systems;...
  • Page 11 A licensed electrician should install a four-wire electrical service (two line voltages, one neutral, one ground) from the main electrical service panel to the subpanel, and from the sub-panel to the spa per the appropriate wiring diagram as illustrated below. Your electrician should mount the subpanel in the vicinity of the spa but it should not be closer than five (5) feet from the spa water edge (NEC 680-38 to 41-A-3).
  • Page 12 SERVICES AVAILABLE FROM YOUR SPA DEALER Service Cost Pre-Delivery site inspection _____________ Deliver spa to installation site _____________ Unwrap spa and haul away packaging material _____________ Set up _____________ Fill the spa with water _____________ Connect the spa to its power source (110 volt models) _____________ Explain and test the spa’s operation •...
  • Page 13 CONTRACTOR SUGGESTIONS Electrician Name: ______________________________________________________________________________ Telephone: ______________________________________________________________________________ Name: ______________________________________________________________________________ Telephone: ______________________________________________________________________________ Masonry Name: ______________________________________________________________________________ Telephone: ______________________________________________________________________________ Name: ______________________________________________________________________________ Telephone: ______________________________________________________________________________ General Name: ______________________________________________________________________________ Telephone: _____________________________________________________________________________ Name: _____________________________________________________________________________ Telephone: _____________________________________________________________________________ Page 13 Page x Page x Pre-Delivery Instructions...
  • Page 14 THIS PAGE LEFT INTENTIONALLY BLANK Page 14 Page x Page x Pre-Delivery Instructions...
  • Page 15 Height Effective Heater Water Filled Dead Electrical Dimension Filter (Watts) Capacity Weight Weight* Weight* Requirements Area 110 volt, 15 amp Excursion 7'3" x 6'5" 34" 1,000 452 lbs. 4,129 100 lbs square gallons lbs. per sq. Recommended- GFCI protected feet 4,000 foot circuit...
  • Page 16 ® WATKINS MANUFACTURING CORPORATION 1280 Park Center Drive Vista, California 92081 (888) 961-7727 ©2014 Watkins Manufacturing Corporation. Part #62914.14 Rev. A (1/14) Page x...
