AML6210DP A/V Processor User Guide                                                                                                               Version 0.4
AML 6210DP  A/V Processor


AMLOGIC reserves the right to change any information described herein at any time without notice.
AMLOGIC assumes no responsibility or liability from use of such information.
6/7/2010










User's Guide
















AMLOGIC, Inc.
3930 Freedom Circle
Santa Clara, CA 95054
U.S.A.
www.amlogic.com










1/24
AMLOGIC Proprietary

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AML 6210DP and is the answer not in the manual?

Questions and answers

Summary of Contents for AMLOGIC AML 6210DP

  • Page 1 AML 6210DP  A/V Processor  User’s Guide                                      AMLOGIC, Inc.  3930 Freedom Circle  Santa Clara, CA 95054  U.S.A.  www.amlogic.com                      AMLOGIC reserves the right to change any information described herein at any time without notice.  AMLOGIC assumes no responsibility or liability from use of such information.  6/7/2010  1/24  AMLOGIC Proprietary ...
  • Page 2: Table Of Contents

    HARACTERISTICS ..............................15 BSOLUTE  AXIMUM  ATINGS ............................15 ECOMMENDED  PERATING  ONDITIONS PIN­OUT ..................................16 ‐ ................................20 ACKAGE PIN OUT DIAGRAM ................................21 ULTIPLE FUNCTION PINS 5.2.1 Card Reader interface multi­function pins........................21 5.2.2 TCON Multi­Function Pins ..............................21 5.2.3 JTAG interface multi­function pins.............................21 5.2.4 FLASH and m1_* interface multi­function pins......................22 MECHANICAL SPECIFICATIONS ..........................24           6/7/2010  2/24  AMLOGIC Proprietary     ...
  • Page 3 AML6210DP A/V Processor User Guide                                                                                                               Version 0.4  Revision History    Revision Revised Changes Number Date 2008/3/3 bwester Initial release 2008/3/3 Bwester Fix some errors in diagram and text 2009/2/13 Revise pin description 2010/03/25 Revise content   6/7/2010  3/24  AMLOGIC Proprietary     ...
  • Page 4: Introduction

      The core CPU interfaces to the video and audio processing hardware.  It performs advanced digital audio  decoding.  It provides support for all existing audio formats and it also has enough flexibility to accommodate  new audio standards.  Popular audio formats like MPEG Layer I/II/III, LPCM, MP3, WMA, AAC and WAV can  be supported.    JPEG pictures are processed by dedicated picture decoding hardware and the flexible Picture AMRISC    engine.  The hardware and microcode combination is capable of decoding  JPEG pictures with no limits in  picture resolution.  Once decoded, the output pictures are passed to a sophisticated video sub‐system that  performs image analysis, enhancement and scaling functions.  Contrast enhancement, hue adjustment, video  scaling, video interpolation, and zoom are also supported.  The high‐resolution scalar supports both up‐ scaling and down‐scaling of images and video.  The scalar can also mix in multiple graphics and OSD layers for  the final display.  The integrated video encoder supports all digital LCD panel resolutions thru the on‐chip  triple panel DACs.  In addition, a programmable digital LCD TCON is included for the AML6210DP to interface  to digital LCD panels directly.    The AML6210DP also integrated a USB 2.0 High Speed OTG controller/PHY and card‐reader controller.  The  card‐reader controller can support SD/SDHC, MS/MS‐Pro/MS‐Duo/MS‐Pro Duo, MMC, xD and CF cards. FAT  and FAT32 file systems are supported.  The USB controller can be connected to USB hard disk, FLASH drive,  digital cameras and MP3 players.  The AVOS drivers and applications for AML6210DP firmware includes the  basic USB device driver, USB protocol stacks to support bulk and INTR transfer, Hub, Mass‐Storage (MS) class  and Picture Transfer Protocol (PTP).  The AVOS USB firmware also supports multiple file systems and  includes flexible file transfer functions between USB devices.    AML6210DP A/V processor has a set of very flexible clocking circuits that implement the adaptive  AMPOWER‐II power reduction algorithms.  The chip works in conjunction with the AVOS software to reduce  total power consumption based on processing load, type of media streams being processed and the output  requirements.  With AMPOWER‐II, the system can reduce power consumption for portable applications and  helps consumer electronics to achieve the Energy Star rating.  In addition, AMPOWER‐II also provides higher  performance within smaller, thermally constrained environments.    6/7/2010  4/24  AMLOGIC Proprietary     ...
  • Page 5: Features

    Decodes BMP, PNG, GIF, TIFF and other popular picture formats  Supports zoom in and out, rotation and transition effects    Special Trick Modes:  Pause  Reverse playback  Multiple steps fast forward/backward    Picture Processing  Automatic image analysis and enhancement  Variable steps picture zooming (up to 8x)  On‐Screen‐Display (OSD) capable of supporting 4/16/256 colors or True‐Color  OSD alpha‐blending over video display    TV Encoder / TCON  Digital video output signals especially for digital LCD panels  Programmable tint, brightness and other TV enhancements  Integrated programmable timing controller (TCON) for digital LCD panels    Graphics  Graphics can be scaled independently of the video output  Unified graphics memory architecture for maximum flexibility and system cost savings    Audio Decoding  Full MPEG audio layers I, II and III  Capable of decoding popular audio formats including:  MP3, WMA  and WAV    Audio Post Processing and Output  Integrated a 2‐channel audio DACs  Muting, volume control, etc.    USB Interface  Integrated OTG 2.0 High Speed controller and PHY  Backward compatible with USB 1.1 devices  USB OTG port can be configured as USB device, host or OTG port  6/7/2010  5/24  AMLOGIC Proprietary     ...
  • Page 6 AML6210DP A/V Processor User Guide                                                                                                               Version 0.4  DMA support for data movement for BULK, INTR and ISO transfer  USB device driver, native USB protocol stack supported in AVOS firmware  Integrated support for Mass‐storage class (MS‐Class) and Picture Transfer Protocol (PTP)  USB Hub support  Video, audio and image decoding from USB attached MS‐Class or PTP devices  Connecting to PCs or Apple computers as USB MS‐Class devices    Card Reader Interfaces and Controllers  Support MS, SD/SDHC, MMC, and xD memory card formats  Supports reading and play back of audio and picture multimedia files  AVOS software supports all file operations via file system on each memory card    Core CPU Sub­system  32‐bit core CPU dedicated for user applications  Embedded debug interface using ICE/JTAG  Shared MPEG SDRAM as run time data storage for minimal system cost  Integrated interrupt controller  Integrated general purpose timers and counters  Integrated general purpose DMA controllers  Supports up to 8M bytes of 8‐bit FLASH chip  Supports single SDRAM interface (m1_*).  The SDRAM interface can support 8M or 16M  bytes of SDRAM.     System, Peripherals and Misc. Interfaces  One 27 MHz crystal oscillator for A/V system  AMPOWER‐II power reduction algorithm for portable devices  Numerous programmable GPIO pins for system control and interrupts  Integrated i2c master controllers, remote control input circuitry, quad PWM output pins  1.25 volt and 3.3 volt power supplies  3.3 volt I/O support  144 pins LQFP RoHS package        6/7/2010  6/24  AMLOGIC Proprietary     ...
  • Page 7: External Interfaces

    Tie to 3.3v with 10k resistor for large size NAND flash device that needs 3 ALE pulses Tie to ground with a 10k resistor for small size NAND device that needs 2 ALE pulses     Clocks  The AML6210DP has multiple internal clock domains, but all the internal clock domains are derived from a  single external reference: OSC.  As illustrated below, the crystal/oscillator pin pairs (OSCIN/OSCOUT) can be  connected to a crystal or driven from an external oscillator.  In the typical A/V application, a 27 MHz crystal is  connected to the OSC  pins.  The following diagram depicts a typical crystal circuit; the actual values of the  components depend on the type of crystal used in the application.    6/7/2010  7/24  AMLOGIC Proprietary     ...
  • Page 8: Jtag For Software Development

        TDI  TDI  TMS  TMS  VCC  AOGPIO  TCK  TCK    TDO  TDO  JTAG Controller                        3.1.4 GPIOs  Configurable hardware controllers (e.g. i2c, card‐reader, etc.) and DMAs are integrated into the AML6210DP  device to speed up the common operations and relieve the core RISC for user‐level applications.  Since  hardware controllers and state‐machines cannot cover all possible external devices or system‐level signals,  numerous general‐purpose I/O pins are available on the chip for purpose like Portable Media Player keypads.   Each GPIO pin can be independently configured to be an input or an output.  As indicated in the diagram,  there are various I/O types.  6/7/2010  8/24  AMLOGIC Proprietary     ...
  • Page 9 AML6210DP A/V Processor User Guide                                                                                                               Version 0.4  GPIO PAD TYPES  GPIO I/O Type I   GPIO I/O Type O I/O_O  Read back  Register  Register  GPIO I/O Type OD ‐ (Pull‐up required)  GPIO I/O Type FC ‐ (NO Pull‐up required)  Read back Read back  Register  Register  I/O_O  Register  I/O_EN  I/O_EN  Register  Register      6/7/2010  9/24  AMLOGIC Proprietary     ...
  • Page 10: Memory Interfaces

    3.2.2 FLASH Interface  The FLASH interface can accommodate an 8‐bits FLASH device.  Due to the limited number of I/O pins, the  FLASH interface is shared with the SDRAM (m1_*) interface.  Up to 8M bytes of FLASH is accessible with the  8‐bits wide FLASH interface design.  The FLASH should be connected as indicated in the following diagram:    A[17] M1_BA1 A[16]  M1_BA0 A[15]  M1_CAS_n A[14]  M1_RAS_n A[13]  M1_DQM1 A[12]  M1_DQM0 A[11:0]  M1_A[11:0] D[15:0]  M1_D[15:0]   WE#  M1_WE_n CS#  FLASH_CS_n FLASH_OE_n 8­bit FLASH        3.2.3 NAND FLASH Interface  The NAND FLASH interface can accommodate an 8‐bits or 16‐bits NAND FLASH device.  Due to the limited  number of I/O pins, the FLASH interface is shared with the SDRAM (m1_*) interface.  NAND FLASH has a very  6/7/2010  10/24  AMLOGIC Proprietary     ...
  • Page 11 AML6210DP A/V Processor User Guide                                                                                                               Version 0.4  large capacity that ranges from 32MB to more than 1GB.  The NAND FLASH should be connected as indicated  in the following diagram:    R/B* NAND_R/nB RE*  NAND_nRE CE*  NAND_CE WE*  NAND_nWE CLE  M1_BA1/NAND_CLE ALE  M1_BA0/NAND_ALE   DQ[7:0]  M1_D[7:0]       8­bit NAND FLASH      6/7/2010  11/24  AMLOGIC Proprietary     ...
  • Page 12: Audio Interfaces

    AML6210DP A/V Processor User Guide                                                                                                               Version 0.4  3.3 Audio Interfaces  A pair of audio DACs is provided in the AML6210DP device.   The audio DACs are designed for connecting to  small speaker inside the photo frame or ear buds for external listening.  A simple external amplifier is needed.   Please see the following sample circuit diagram.    Internally, the delta‐sigma algorithm is used to improve the performance and ensure high SNR output.  The  implementation includes a multi‐tap interpolation filter which increases the sample rate of the audio  channels to the modulator rate.  Then the audio stream is passed through a sigma‐delta modulator that  generates the serial PWM data stream.  An internal analog filter is then used for out‐of‐band noise filtering  and analog signal reconstruction.  External amplifier is needed to provide the necessary current to drive the  speakers or head phones.      ADATA_0 (L)  ADATA_1 (R)  AMPIFLER    Circuit  Internal  Stereo ADC             6/7/2010  12/24  AMLOGIC Proprietary     ...
  • Page 13: Video Output Interfaces

    AML6210DP A/V Processor User Guide                                                                                                               Version 0.4  3.4 Video Output Interfaces  3.4.1 Digital Video Output  The AML6210DP integrated internal LCD video scalar and encoder and high‐resolution triple panel DACs  (PDAC) for direct connection to digital LCD panels.  The LCD scale and encoder convert the video images to  the LCD resolution and prepare the image to be displayed.  Then special LCD specific dithering logic and  gamma correction algorithm is applied before the video data is sent to the digital video output.    3.4.2 LCD Timing Controller  The AML6210DP AV processor has a built‐in LCD timing controller (TCON) that works in conjunction with the  digital video output to provide the best video performance on a digital LCD panel.  The TCON and digital video  output drive the digital LCD panel directly without any additional logic.  AML6210DP’s TCON is  programmable and can be used in any small to medium size digital LCD panels.  The LCD TCON also includes a  dedicated VGH/VGL pulse generator for the LCD panel voltage generator.  Together with some simple passive  components, VGH/VGL can be generated.    DV Out   Digital  LCD  Timing  Panel Controller VGH/VGL Control          6/7/2010  13/24  AMLOGIC Proprietary     ...
  • Page 14: Peripherals

    AML6210DP A/V Processor User Guide                                                                                                               Version 0.4  3.5 Peripherals   3.5.1 Card­Reader Interface  The AML6210DP have an integrated hardware controller for SD/MS/MMC/xD card‐reader operations.  The  hardware controller is capable of executing the low‐level card interface protocols, computing the CRC or  checksum, and transferring data to/from SDRAM.  The hardware provides interface for the necessary signals  (e.g. SD_CLK, SD_CMD, SD_D0‐3 for SD cards) but signals like card detect and write‐protect are provided using  GPIO only.      3.5.2 USB Interface  AM6210DP AV processor has integrated one high speed USB 2.0 OTG controller and PHY into the chip.  The  output USB signal (DP/DM) can drive the external USB controller (e.g. Hub, FLASH drive, camera, PC, Mac, etc.)  directly.  The OTG controller can acts as a high speed USB Host or USB Device or a try OTG controller.        6/7/2010  14/24  AMLOGIC Proprietary     ...
  • Page 15: Operating Conditions

    -0.5 ~ 4.6 °C Junction Temperature       4.3 Recommended Operating Conditions  Table 4­3  Recommended Operating Conditions  Symbol Parameter Min. Typ. Unit 1.25V Core Supply Voltage 1.25 1.32 DD(CORE) 3.3V Pads Supply Voltage DD(PADS) °C Operating Temperature           6/7/2010  15/24  AMLOGIC Proprietary     ...
  • Page 16: Pin­out

    30  M1_A_5  M1_A_5  SDRAM1 and/or FLASH  I/O  31  M1_A_6  M1_A_6  SDRAM1 and/or FLASH  I/O  32  VSS  Digital Ground  Digital ground  P  33  M1_A_7  M1_A_7  SDRAM1 and/or FLASH  I/O  34  M1_A_8  M1_A_8  SDRAM1 and/or FLASH  I/O  35  M1_A_9  M1_A_9  SDRAM1 and/or FLASH  I/O  36  M1_A_10  M1_A_10  SDRAM1 and/or FLASH  I/O  6/7/2010  16/24  AMLOGIC Proprietary     ...
  • Page 17 M1_D_1  M1_D_1  SDRAM1 and/or FLASH  I/O  67  M1_D_0  M1_D_0  SDRAM1 and/or FLASH  I/O  68  VDD33  I/O Power 3.3V  Digital I/O power 3.3V  P  69  REMOTE  Remote  Remote Control  I  70  PWM_LCD  LCD PWM  PWM for the LCD ?  I/O  71  GP Output // LCD_PWR_EN  GPO  GPO for LCD_power control  O  72  RESET_N  Reset  Master Reset  I    6/7/2010  17/24  AMLOGIC Proprietary     ...
  • Page 18 XD_WP// SD_WP  Card Reader I/O  Card Reader I/F or GPIO  I/O  103  GPIO// CARD_POWER  Card Reader I/O  Card Reader I/F or GPIO  I/O  104  XD_RE  Card Reader I/O  Card Reader I/F or GPIO  I/O  105  XD_WE  Card Reader I/O  Card Reader I/F or GPIO  I/O  106  XD_RE  Card Reader I/O  Card Reader I/F or GPIO  I/O  107  XD_CE  Card Reader I/O  Card Reader I/F or GPIO  I/O  108  VDD33  Digital I/O Power  Digital I/O 3.3V power  P    6/7/2010  18/24  AMLOGIC Proprietary     ...
  • Page 19 LCD_B3  LCD Video Out  LCD Video Signal Output  O  139  LCD_B4  LCD Video Out  LCD Video Signal Output  O  140  LCD_B5  LCD Video Out  LCD Video Signal Output  O  141  JTAG_TMS// I2C_MASTER_CLOCK  JTAG TMS  JTAG  I/O  142  JTAG_TDI// I2C_MASTER_DATA  JTAG TDI  JTAG  I/O  143  JTAG_TCK// AUDIO_MUTE  JTAG TCK  JTAG  I/O  144  JTAG_TDO// OTG_VBUS  JTAG TDO  JTAG  I/O    6/7/2010  19/24  AMLOGIC Proprietary     ...
  • Page 20: Package Pin­out Diagram

    81  USBA_rext  M1_A_5  30  80  USBA_vdda33t  M1_A_6  31  79  USBA_dm  VSS  32  78  USBA_dp  M1_A_7  33  77  USBA_vssa33t  M1_A_8  34  76  USBA_vss12  M1_A_9  35  75  USBA_vdd12  M1_A_10  74  USBA_vbus  6    73  USBA_id      6/7/2010  20/24  AMLOGIC Proprietary     ...
  • Page 21: Multiple Function Pins

    TCON_STV2 TCON_STV2 LCD_GPIO_27 TCON_VCOM TCON_VCOM LCD_GPIO_31 TCON_OEH TCON_OEH LCD_GPIO_30 TCON_CPH1 TCON_CPH1/2/3 LCD_GPIO_23   5.1.3 JTAG interface multi­function pins    Pin# Package Pin Name JTAG MISC GPIO JTAG_TMS JTAG_TMS I2C_MSTR_CLK JTAG_GPIO_1 JTAG_TDI JTAG_TDI I2C_MSTR_DATA JTAG_GPIO_2 JTAG_TCK JTAG_TCK UART_RX JTAG_GPIO_0 6/7/2010  21/24  AMLOGIC Proprietary     ...
  • Page 22: Flash And M1_* Interface Multi­function Pins

    FLASH_A_18 M1_D_14 M1_D_14 NAND_15 FLASH_A_19 M1_D_15 M1_D_15 NAND_7 FLASH_D_7 M1_D_7 M1_D_7 NAND_6 FLASH_D_6 M1_D_6 M1_D_6 NAND_5 FLASH_D_5 M1_D_5 M1_D_5 NAND_4 FLASH_D_4 M1_D_4 M1_D_4 NAND_3 FLASH_D_3 M1_D_3 M1_D_3 NAND_2 FLASH_D_2 M1_D_2 M1_D_2 NAND_1 FLASH_D_1 M1_D_1 M1_D_1 6/7/2010  22/24  AMLOGIC Proprietary     ...
  • Page 23 AML6210DP A/V Processor User Guide                                                                                                               Version 0.4  NAND_0 FLASH_D_0 M1_D_0 M1_D_0       6/7/2010  23/24  AMLOGIC Proprietary     ...
  • Page 24: Mechanical Specifications

    AML6210DP A/V Processor User Guide                                                                                                               Version 0.4  6 Mechanical Specifications    The AML6210DP A/V processor is packaged using a 144 pins LQFP package.  The mechanical dimensions are  given in millimeters as below:        22.00±0.25  20.00 ±0.10  0.17/0.20/0.27 Amlogic  AML6210DP  0.50 BSC    144 Pin LQFP  20mmx20mm  1.35/1.40/1.45  0.45/0.60/0.75 0.05/0.15   1.00 REF 6/7/2010  24/24  AMLOGIC Proprietary     ...
