Power Bank 6000mAh with FullHD Camera TX-92
The Declaration of Conformity you find here: www.technaxx.de/ (in bar at the bottom
"Konformitätserklärung"). Before using the device the first time, read the user manual
This device has a rechargeable battery. It must be fully charged before first use.
NOTE: Charge the battery of the device every 2–3 month if it is not used!
Service phone No. for technical support: 01805 012643 (14 cent/minute from German
Keep this user manual for future reference or product sharing carefully. Do the same with
the original accessories for this product. In case of warranty, please contact the dealer or
the store where you bought this product. * Warranty 2 years
Features
Charging the most mobile devices (e.g. Smartphone, tablet PC, eBook reader, etc.)
Rechargeable portable 6000mAh lithium ion battery (type 18650) 3.7V/22.2Wh
video recording with 1/4" CMOS camera sensor 2MP & sound
charging external digital devices
vision up to 2m
overcurrent, short circuit, overload, overcharge, overvoltage
by 4 LEDs
Easy handling via remote control
Technical specifications Power Bank
Built-in rechargeable 6000mAh lithium ion battery
Battery type
Power supply input (Micro USB)
Power supply output (USB)
Charging time
Connections
Power consumption
Sound recording
Operating systems
Working temperature
Weight / Dimensions
Technaxx
fixed-line and 42 cent/minute from mobile networks).
Free Email: support@technaxx.de
Backup power on the go, ideal for travelling
18650 3.7V 22.2Wh
DC 5V/1A power adapter** (**not included)
DC 5V/1.5A
~7–9 hours without simultaneous recording
~15 hours with simultaneous recording
1x Micro USB 5V/2A (for power bank charging)
1x USB 5V/1.5A (for charging external device)
1x MicroSD(HC) card slot (max. 32GB)
Only video
Only IR
Built-in non-visible microphone
Windows 7 / 8 / 8.1 / 10 / MacOS
–5°C up to +50°C
187g / (L) 13.8 x (W) 6.2 x (H) 2.1cm
®
* User Manual
carefully.
MicroSD(HC) card slot up to 32GB
DC 3.7V/160mA
DC 3.7V/100mA
USB output 5V/1.5A for
Infrared night
Built-in protection against
Charging status is shown
FullHD
Advertisement
Related Manuals for Technaxx TX-92
Summary of Contents for Technaxx TX-92
- Page 1 Technaxx * User Manual Power Bank 6000mAh with FullHD Camera TX-92 The Declaration of Conformity you find here: www.technaxx.de/ (in bar at the bottom “Konformitätserklärung”). Before using the device the first time, read the user manual carefully. This device has a rechargeable battery. It must be fully charged before first use.
- Page 2 MicroSD(HC) cards up to 32GB (up to Class 6) External storage [has no internal storage] Package Contents: Power Bank 6000mAh with FullHD camera TX-92, Micro USB to USB charging cable, Remote Control with button cell battery (CR2032), User Manual Produkt Overview...
- Page 3 Charge the Power Bank fully before use (~ 7–9 hours) Connect the Micro USB port of the charging cable* (*included) to the Power Bank. Then connect the USB port of the charging cable to the USB port of a AC adapter** (**not included) or to a PC/Notebook (see right picture).
- Page 4 Key (K1) functions and indicator LEDs description Video recording: Long press K1 button, BLUE LED L1&L2 blink 3 times and turn off, it starts recording videos. Save videos: Short press K1, BLUE LED L1&L2 steady on. After 1 minute without any operation the Power Bank will automatically shutdown.
- Page 5 Cleaning: Protect the device from contamination and pollution (use a clean drapery). Avoid using rough, coarse-grained materials or solvents/aggressive cleaner. Wipe the cleaned device accurately. Distributor: Technaxx Deutschland GmbH & Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany Battery Care Information (the battery is NOT replaceable): Rechargeable batteries are only to be charged under adult supervision and are only to be charged by adults.
