No. Description
12 Remote entry
Jumper for programming of the remote
13
entry
14 Battery protection fuse

4.1.1 VarioString VS-70

12
Comments
Available as from software version 1.5.22. Allows
the control of a function – to be defined by
programming – by the closing of a dry contact or
by the presence of a voltage across these
terminals.
See sect. 8 – p. 27 in fig. 4.1.1 and 4.1.2. By default,
they are positioned at A-1/2 and B-2/3.
VS-70 : Fuse 100A/80V (sect. 4.2.2.2)
VS-120 : Fuse CF8/150A/58V (sect. 4.2.2.1)
V 2.3 User manual
