The QuickLock Padlock Manual

Rfid + bluetooth + access control
Hide thumbs

Advertisement

Quick Links

Download this manual
Padlock
RFiD + Bluetooth + Access Control

Advertisement

loading
Need help?

Need help?

Do you have a question about the Padlock and is the answer not in the manual?

Questions and answers

Summary of Contents for The QuickLock Padlock

  • Page 1 Padlock RFiD + Bluetooth + Access Control...
  • Page 2 Package Contents:  Padlock  2 – RFiD Key Cards  1 – RFiD FOB  Micro USB Cable Shackle RFiD Read Target Area “On” Button Blue LED Red LED...
  • Page 3 RFiD – Press the button on the Padlock, and a blue LED will begin to flash.  With the blue LED flashing, place one of the preprogrammed RFiD tags that came with the Padlock up close to the Q-Logo and the Padlock should open.
  • Page 4  There is a free App provided for configuration of your Padlock. There is an App for both iOS and Android phones. To download the App, go to the iTunes Store or the Google Play store, depending on your device, and search for SafeTech and download the SafeTech App.
  • Page 5  To connect the Padlock to the App, press “Add Device” on the App and then press the button on the Padlock. The blue LED will begin to flash on the Padlock and then turn solid when the phone connects to the Padlock.
  • Page 6 Once you have connected the Padlock to the App, it should connect automatically every time. To reconnect, open the App to the Home screen, ensure that Bluetooth is on and press the button on the Padlock. The Padlock will then connect automatically and take you to the Unlock screen. You will not need to press “Add Device”...
  • Page 7 The Padlock can be setup to automatically unlock when it connects with the App. To enable automatic unlocking, press the slide under Auto Unlock. From now on, every time you connect the Padlock to the App, it will unlock automatically. To turn off this feature, press the slide under Auto Unlock again.
  • Page 8 There are a number of settings that can be adjusted on the SafeTech App. To access these settings, connect the Padlock to the App. Once connected, press the settings cog in the bottom right hand corner of the screen and you will be taken to the Settings screen.
  • Page 9  The History Log shows a log of all recent openings of the Padlock using RFID or the App. To access the log, press “History Log” (Note, names will only be visible for App openings and for RFiD tag names stored on the phone being used to view the History Log.
  • Page 10  You can set the amount of time the Padlock latches stays open after it is unlocked. To do this, press “Auto Lock Time,” and change the number of seconds. RFiD Tag Management  RFiD tags can be added to the Padlock using the App. To do this, press “RFID Tag Management” to get to the RFID Tag Management screen and then press “Add New Tag.”...
  • Page 11  You can allow another person to open your Padlock at specific times or for a specific number of openings using a Share Code. To do this press, “Share Code” to open the Share Code screen. To give access a specified number of times, enter an 8-digit code on the top section and select the number of uses allowed.
  • Page 12 You can remove the Padlock from your App. To do this, press “Remove: (Padlock Name)” on the Settings screen. Press “Yes” on the warning pop up and the Padlock will be deleted. To add the Padlock again to the App you will...
  • Page 13 Side Menu Options  There are a few other options available on the side menu. To access these options, press the button in the top left hand corner of the screen and a menu will slide from the left. From this menu you can view the devices you have connected to the App.

  • Page 14: Basic Functions

     The Padlock has a battery that can work for up to 1 year without charging. If the Padlock runs low on battery, it will flash blue and red when you press the button. To charge the battery, remove the rubber plug from the back...
  • Page 15 The manufacturers and sellers of the Padlock are not responsible for theft or damage of the Padlock or any contents secured by the Padlock. The user is warned that it is possible for an unauthorized party to access the Padlock and does not make claims that it is invulnerable to attack.
  • Page 16 a. The licensor has no obligation to support, maintain or update the App or the software, firmware or hardware associated with this App’s connecting hardware i.e. doorlocks, deadbolts, padlocks, lock- boxes, etc. b. The licensor is not obligated to provide training or consulting for this App or the software, firmware or hardware associated with this App’s connecting hardware i.e.

  • Page 17: Frequently Asked Questions

    RPH Engineering. Download the App to get all the features The Padlock has to offer.  What kind of battery does the Padlock have? How long will a charge last before it needs to be recharged? o The Padlock has an internal rechargeable Lithium Polymer battery. The Padlock charge will normally last 1 year before it will need to be charged again.

  • Page 18: Troubleshooting

     No lights come on when I press the button o Make sure the battery is not dead. Plug the Padlock in to charge. The battery will take 2 hours to fully charge o Make sure there is power coming from the charger ...
