Instructions - Parts List
APEX
Oil Transfer Pump
For pumping non-flammable fluids, including motor oils, hydraulic
fluid, and antifreeze only. Do not use to pump water.
Model 260100, 5.8 gpm (22.0 lpm), 65 psi (.45 MPa, 4.5 bar) 12 VDC
Model 260101, 4.25 gpm (16.1 lpm), 65 psi (.45 MPa, 4.5 bar) 115 VAC
Model 260102, 8.0 gpm (30.3 lpm), 30 psi (.21 MPa, 2.1 bar) 115 VAC
Model 260104, 4.25 gpm (16.1 lpm), 65 psi (.45 MPa, 4.5 bar) 230 VAC
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
Contents
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Mounting Pump on Barrel or Tank . . . . . . . . . . . . 4
Mounting Hose and Nozzle . . . . . . . . . . . . . . . . . 4
12 VDC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Pressure Relief Procedure . . . . . . . . . . . . . . . . . . 5
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Performance Chart . . . . . . . . . . . . . . . . . . . . . . . 11
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 12
Graco Information . . . . . . . . . . . . . . . . . . . . . . . . . 12
Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
Copyright 2005, Graco Inc. is registered to I.S. EN ISO 9001
311305B
Advertisement
Table of Contents
Related Manuals for Apex Digital 260100
Summary of Contents for Apex Digital 260100
-
Page 1: Table Of Contents
For pumping non-flammable fluids, including motor oils, hydraulic fluid, and antifreeze only. Do not use to pump water. Model 260100, 5.8 gpm (22.0 lpm), 65 psi (.45 MPa, 4.5 bar) 12 VDC Model 260101, 4.25 gpm (16.1 lpm), 65 psi (.45 MPa, 4.5 bar) 115 VAC Model 260102, 8.0 gpm (30.3 lpm), 30 psi (.21 MPa, 2.1 bar) 115 VAC... -
Page 2: Warnings
Warnings Warnings The following general warnings are for the setup, use, grounding, maintenance, and repair of this equipment. Additional, more specific warnings may be found throughout the body of this manual where applicable. Symbols appearing in the body of the manual refer to these general warnings. When these symbols appear throughout the manual, refer back to these pages for a description of the specific hazard. - Page 3 Warnings WARNING PRESSURIZED EQUIPMENT HAZARD Fluid from the gun/dispense valve, leaks, or ruptured components can splash in the eyes or on skin and cause serious injury. • Follow Pressure Relief Procedure in this manual, when you stop dispensing and before cleaning, checking, or servicing equipment. •...
-
Page 4: Installation
Installation Installation 3. Apply pipe sealant (not the supplied PVC cement) to the threaded end of the suction tube and then screw the tube into the pump inlet port. Make sure tube is tight. The oil transfer pumps are positive displace- 4. -
Page 5: Electrical Installation 115 Vac And 230 Vac
12 VDC 4. Immediately after dispensing, turn switch to The 12 VDC model (260100) is not shipped OFF position. with a power cord since the installation will determine the length of the power cord. -
Page 6: Troubleshooting
Cause Solution Motor runs but pump will not Motor rotation wrong. Check wiring instructions for prime. (260100 only) possible problems. Dirt under pressure relief valve. Remove pressure relief valve and inspect, clean, or replace if damaged. Worn or damaged gears. - Page 7 Troubleshooting Problem Cause Solution Unit pumps but output flow is Clogged inlet suction screen Clean or replace. low. (used oil). Air leak in suction tube. Check to make sure all joints in suction tube are sealed. Suction tube too close to tank Suction tube must have a 2 in.
-
Page 8: Parts
Parts Parts Model 260100, 12 VDC Model 260102, 115 VAC Model 260101, 115 VAC Model 260104, 230 VAC 311305B... - Page 9 KIT, packing 4, 5 260293 KIT, gear 3, 4, 5 260297 KIT, pressure relief 7, 10a, 11 (models 260100, 260101, and 260104) 260298 KIT, pressure relief 7, 10b, 11 (model 260102) 260300 KIT, suction pipe 18, 19, 20, 21 260495...
-
Page 10: Technical Data
65 psi (0.45 MPa, 4.5 bar) Model 260102: 30 psi (0.21 MPa, 2.1 bar) Output Flow Model 260100: 5.8 gpm (22.0 lpm) Model 260101: 4.25 gpm (16.15 lpm) Model 260102*: 8.0 gpm (30.3 lpm) Model 260104: 4.25 gpm (16.15 lpm) Inlet Size 1 in. -
Page 11: Performance Chart
Technical Data Performance Chart 311305B... -
Page 12: Graco Standard Warranty
Graco Standard Warranty Graco warrants all equipment referenced in this document which is manufactured by Graco and bearing its name to be free from defects in material and workmanship on the date of sale to the original purchaser for use. With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
