Page 1: User Manual
CYT-200SC User Manual Document Version 1.0 Web Version 1.1 2011-05-14 Firmware Version 1.01.00, May 17 2011... -
Page 2: Table Of Contents
【Index】 Ⅰ、Hardware Introduction........................1 Ⅱ、Product Overview..........................3 Ⅲ、WEB Login............................4 Ⅳ、Web Function Instruction.......................10 System Setup...........................10 1、Network setting........................10 (1)STATIC IP........................10 (2)DHCP CLIENT.......................11 (3)PPPoE..........................12 Advanced Setup..........................13 1、Operation Mode......................... 13 PORT 1..........................13 (1)TCP Server........................13 (2)TCP Client........................14 (3)UDP..........................15 PORT 2..........................16 (1)TCP Server........................ -
Page 3: Ⅰ、Hardware Introduction
－CYT-200SC－ Ⅰ、Hardware Introduction Appearance Specification Item Specification 16 Bits, 100MHZ Memory 256KB Flash & 2MB SDRAM Watchdog System never halt Ethernet 10/100 Base-T/Tx/, Automatic MSI/MDI-x port Communication Port RS-232, RS-422, RS-485 Connectors DB9(MALE)/RJ-45 RS-232(COM1) TxD, RxD, RTS, CTS, DTR, DSR, DCD,RI,GND... - Page 4 End point - 2 -...
-
Page 5: Ⅱ、Product Overview
Real time operation system and complete TCP/IP protocol enable CHIYU’s CYT-200SC powerful converter not only providing complete system with highly efficiency but also able to link with network. Easy to install and wire. The Web interface of CYT-200SC is simple, easily to operate, and without operation system limitation. -
Page 6: Ⅲ、Web Login
Web browser, and then conduct setting. Preparation Before conducting CYT-200SC setting, please assure the following: PC has connected to CYT-200SC, and PC and CYT-200SC are situated in the same WAN with power supplied. If the default IP address (192.168.168.125... - Page 7 3、 While the IP Search window shows up, it will display all CYT-200SC in LAN, and show Device name, Location, Model Name, Address, Subnet Mark, Gateway, Address. Select particular CYT-200SC, then its related information will appear below the window, as shown: 4、...
- Page 8 Web of CYT-200SC, has two methods: (1) Open IP Search, select and double click particular CTY-200SC, then to enter its webpage. (2) While the internet explorer opened, input CYT-200SC IP address to enter its webpage Remark：...
- Page 9 , open and search for , click Alter Interface Card on the upper-left side. 《Step 2》 Click LAN link, select content, then the LAN settings will be shown, click Internet Protocol(TCP/IPv4), click and input same setting as CYT-200SC, as below figure. - 7 -...
- Page 10 How to login to CYT-200SC Web via web browser 1、Start Web browser ( ig: WIN 7 IE ), input CYT-200SC’s IP Address, for example: use the default CYT-200SC IP Address: http://192.168.168.125 2、If connection failed, should check: If CYT-200SC installed and its power supplied properly ...
- Page 11 3、 If the connection with CYT-200SC is successful, then it will display a message window for User name and Password, the default for user name and Password is: admin/admin, as shown below: 4、While the user name and password entered, a Web setting interface of CTY-200SC will be showed, enter it will then display a “Network setting “...
-
Page 12: Ⅳ、Web Function Instruction
Ⅳ、Web Function Instruction System Setup 1、Network setting (1)STATIC IP Function instruction Function Description Set the IP address of the CYT-200SC ， default setting is IP Address 192.168.168.125 Set the subnet mask of the CYT-200SC ， default setting is Subnet mask 255.255.255.0... -
Page 13: Dhcp Client
(2)DHCP CLIENT Function instruction Function Description Host Name (optional) Fill in the host name , default setting is CHIYU (optional) - 11 -... -
Page 14: Pppoe
Fill in the service name (optional), up to 47 characters Service Name (optional) Default setting is 0 second, the range is from 0 ~ 4294967295 Keep the connection of CYT-200SC and ISP always must set the no Close Connection when Idle Time Over into 0 or the connection with PPPoE will be disabled when Idle time over. -
Page 15: Advanced Setup
The default setting of close connection time is 100 seconds and the range is from 0 ~ 32768 Close Connection When The value must set to be 0 if you want to keep CYT-200SC connect Remote Idle with monitoring side or the connection will be off automatically when remote idle. -
Page 16: Tcp Client
Name is blank There are 2 modes to set TCP connection to server： 1.Start Up：This mode means when CYT-200SC enable, it will build the TCP connection with SERVER immediately. It will automatically build the TCP connection after disable TCP Connection and then re-connect again. -
Page 17: Udp
(3)UDP Function instruction Description Function Set the remote connection port number ，the range is 0 ~ Remote Connection Port Number 65535，default setting is 50000 Remote Host IP Address/Domain Set remote host IP address or domain name，default setting is Name blank Set the local listen port，default setting is 50000 Local Listen Port... -
Page 18: Port 2
The default setting of close connection time is 100 seconds and the range is from 0 ~ 32768 Close Connection When The value must set to be 0 if you want to keep CYT-200SC connect Remote Idle with monitoring side or the connection will be off automatically when remote idle. -
Page 19: Tcp Client
Name is blank There are 2 modes to set TCP connection to server： 1.Start Up：This mode means when CYT-200SC enable, it will build the TCP connection with SERVER immediately. It will automatically build the TCP connection after disable TCP Connection and then re-connect again. -
Page 20: Udp
(3)UDP Function instruction Description Function Set the remote connection port number ，the range is 0 ~ Remote Connection Port Number 65535，default setting is 50000 Set remote host IP address or domain name，default setting is Remote Host IP Address/Domain Name blank Set the local listen port，default setting is 50000 Local Listen Port... -
Page 21: 2、Serial Port Setup
Length (bytes) setting is 1000 Set the transmission data end by identified delimiter and if your transmission data includes the identified delimiter, CYT-200SC will send out packet at Delimiter 1 once. Default setting is disabled. The range is from 0x00 ~ 0xFF ... -
Page 22: Port 2
Length (bytes) setting is 1000 Set the transmission data end by identified delimiter and if your transmission data includes the identified delimiter, CYT-200SC will send out packet at Delimiter 1 once. Default setting is disabled. The range is from 0x00 ~ 0xFF ... -
Page 23: 3、Dynamic Dns Setup
3、Dynamic DNS Setup (1)TZ0 Function instruction Function Description E-mail Address Fill in the E-mail address for DDNS , up to 47 characters ， Fill in the password key for DDNS up to 31 characters Password key Fill in the device DNS name ，... -
Page 24: Dyndns
(2)Dyndns Function instruction Function Description for DDNS ，up to 31 characters Username Fill in the username ，up to 31 for DDNS characters Password Fill in the password Device DNS Name Fill in the device DNS name，for example：hostname.dyndns.org Display the registry IP address，when DDNS is enabled, It will show the Registry IP Address registry IP address Display DNS Serve status，when DDNS server does not enable ,it will show... -
Page 25: Management
Display and set the device management IP address , default setting is Address 192.168.200.200 Device Hostname Fill in the device hostname, default setting is CHIYU Device Location Fill in the device location , default setting is blank User Name：Fill in the user name ... -
Page 26: 2、System Status Monitor
Display the MAC address of CYT-200SC IP Address Display CYT-200SC address, default setting is192.168.168.125 Subnet mask Display CYT-200SC Subnet mask, default setting is 255.255.255.0 Default Gateway Display CYT-200SC Default Gateway, default setting is 192.168.168.254 Primary DNS Display CYT-200SC Primary DNS address, default setting is168.95.1.1... -
Page 27: 3、Backup & Restore Configuration
3、Backup & Restore Configuration Function Instruction Function Description After execution, can save the present system settings as a backup file, and save it in Backup hardware, the sub-name of the saved file is .cfg Restore Browse and select saved file( .cfg ), execute Restore to restore system settings - 25 -... -
Page 28: 4、Firmware Upgrade
4、Firmware Upgrade Function Instruction Function Description Browse and select firmware, execute Upgrade to upgrade firmware Please select a file to Has to assure the possibility of power supply during the process of upgrade upgrading, or severe damage will be caused. What if upgrade different firmware to different products, and it will also cause severe damage. -
Page 29: 5、Ping
5、PING Function Instruction Function Description Source IP Address Display CYT-200SC IP address Destination IP Address Input IP address of Remote Host Packet Number Set up the number of PING package, ranged 1 ~4 , the default 4 Ping Size Set up the size of PING package, the utmost setting 1460 bytes.
