- Page 1 ZigBee - Wireless Switch Control Unit User Manual Wireless Switch Control Unit Model: Z831RT Firmware: V1.2 Hardware: V1.1...
-
Page 2: Table Of Contents
4. Installation and Preparation............................4 4-1. Power supply..............................4 4-2. Join ZigBee network............................4 4-3. Permit join...............................4 4-4. Binding................................4 4-5. Factory Setting..............................5 4-6. Product of attribute report..........................5 4-7. ZigBee description............................5 5. Netvox APP Control and Monitor..........................7 6. Related Netvox Device.............................. 9 7. Important Maintenance Instruction..........................9... -
Page 3: Introduction
Z831RT is a smart home, high reliability switching control equipment, 2.4GHz ISM band transceiver, and fully compatible with ZigBee Pro protocol. The Z831RT is used as a router in the network, allowing other devices to join the network as its sub-devices to communicate with the routers, coordinators, and end devices of the ZigBee network. -
Page 4: Product Appearance
Model: Z831RT 2. Product Appearance Network Indicator Status Indicator External input 3 Binding key External input 2 External input 1 DC 5/12V socket Common ground Positive battery power Output + DC 5/12V input - Output - DC 5/12V input +... -
Page 5: Installation And Preparation
(4) For example, to bind 1st channel with other devices. Press binding key for 3 seconds; status indicator will flash once. Release binding key and short press it once and see a flash within 5 seconds. Z831RT will send binding request to devices. -
Page 6: Factory Setting
Model: Z831RT 4-5. Factory Setting Z831RT is capable of storing and saving network routing information. You can join to a new network by simply resetting the device to restore to the factory setting. 4-6. Product of attribute report Cluster ID (0x0006): Report Attribute ID: 0x0000 4-7. - Page 7 Model: Z831RT EP 0x04(Device ID: 0x0002 ) On/off(0x0006) Group(0x0004) Scene(0x0005) Attributes of the Basic Information Identifier Name Type Range Access Default Mandatory / Optional 0x0000 ZCLVersion Unsigned 0x00 – Read only 0x02 8-bit integer 0xff 0x0001 ApplicationVersion Unsigned 0x00 –...
-
Page 8: Netvox App Control And Monitor
1. The device to join the Netvox system, in the APP device management interface search device IEEE, will appear the corresponding equipment information, Z831RT has 4 EP, namely 3 On / Off Switch and an On/ Off Output, as shown in the below figure: 2. -
Page 9: Related Netvox Device
3. Select On / Off Output (EP4) to enter the setting interface (as shown in the below left figure), you can set the identify time, the power output state of the device (as shown in the below right figure), through the control bar under the switch to control the output . 6. Related Netvox Device Switch（Model name: ZB02A/B/C） Remotes（Model name：Z503/Z501B）... -
Page 10: Important Maintenance Instruction
Model: Z831RT Important Maintenance Instruction This device is NOT truly waterproof/ resistant and is for indoor use. Please keep the device in a dry place. Precipitation, humidity, and all types of liquids or moisture can contain minerals that corrode electronic circuits. In cases of accidental liquid spills to a device, please leave the device dry properly before storing or using.
